SELECTRONIC™
PROXIMITY URINAL FLUSH VALVE
0.5 & 1.0 GPF
Certified to comply with ASME A112.19.2M
© 2008 AS America, Inc.
M968567 Rev. 1.2
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Faucets visit our website at: www.americanstandard-us.com
or U.S. customer's e-mail us at: faucetsupport@americanstandard.com
For Parts, Service, Warranty or other Assistance,
1-800-442-1902 (In Canada: 1-800-387-0369)
please call
Exposed Flushometer
for 3/4" Top Spud Urinals
CLOG RESISTANT
• Self-cleaning piston valve prevents clogging and reduces maintenance.
ONE SENSOR FITS ALL
• Only 1 sensor for entire Selectronic™ line of faucets, urinals, and flush valves.
• Range can be adjusted manually or with optional remote control.
• Sensor Features Low Battery Indicator.
(In Toronto Area only: 1-905-3061093)
(In Toronto Area only: 1-905-3061093)
MODEL NUMBERS
6063.510
6063.051
6063.505
6063.101
Advertisement
Related Manuals for American Standard Selectronic Proximity Urinal Flush Valve 6063.051
Summary of Contents for American Standard Selectronic Proximity Urinal Flush Valve 6063.051
- Page 1 M968567 Rev. 1.2 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Faucets visit our website at: www.americanstandard-us.com or U.S. customer's e-mail us at: faucetsupport@americanstandard.com For Parts, Service, Warranty or other Assistance,...
- Page 2 M968567 Rev. 1.2 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Faucets visit our website at: www.americanstandard-us.com or U.S. customer's e-mail us at: faucetsupport@americanstandard.com For Parts, Service, Warranty or other Assistance,...
-
Page 3: General Description
Fig. 1 Roughing-in Dimensions 72mm (2-7/8) 116mm (4-5/8) MANUAL OVERRIDE BUTTON 115mm-134mm (4-1/2 TO 5-1/4) 293mm (11-1/2) FOR 3/4" TOP SPUD FIXTURES RECOMMENDED TOOLS; Fig. 2 Teflon Tape Flat Blade Screwdriver (For adjusting Supply Stop) Adjustable Wrench Tape Measure Hacksaw Tubing Cutter File For Sweat Connection;... - Page 4 INSTALL SWEAT SOLDER ADAPTER; Fig. 3 Turn water supplies off CAUTION before beginning Note: Install Optional Sweat Solder Adapter (Supplied) for copper pipe supply line. Fig. 3. 1. Measure the distance (A) from the finished wall to the center of the inlet spud on the fixture. 2.
- Page 5 FLUSH OUT SUPPLY LINES; Fig. 6 1. Remove COVER (1) from SUPPLY STOP (2). 2. With a flat blade screwdriver open SUPPLY STOP (2). 3. Turn on water supply to flush line of any debris or sediment. 4. Close SUPPLY STOP (2) and replace COVER (1). 4 LEFT OR RIGHT HAND INSTALLATION;...
- Page 6 INSTALL FLUSH VALVE; Fig. 8a & 8b 1. As shown in Fig. 8a, insert the side INLET FLANGE (1) on the FLUSH VALVE (2) into the SUPPLY STOP (3). Lubricate the INLET FLANGE O-RING (4) with water if necessary. Lightly tighten COUPLING NUT (5). Fig. 8a. Important: Do not use lubricants (other than water) or any type of thread sealing paste or tape.
- Page 7 If these items do need replacement they must be purchased separately or order the complete flush valve assembly from American Standard. 1. Remove COVER (1) from SUPPLY STOP (2) if installed. Fig. 10.
- Page 8 HOW TO SET DETECTION RANGE HOW TO SET DETECTION RANGE (If Required) ; Fig. 13 & 14 (If Required) ; Fig. 13 Note: The detection distance is preset and is ideal for most installations. Should an adjustment be required follow the steps below. 1.
- Page 9 M968567 Rev.1.2...
-
Page 10: Model Numbers
A906680-0070A BONNET NUT M962663-0070A PISTON ASSEMBLY M962666-0020A MANUAL VALVE M962665-0020500A COVER ASSEMBLY FOR FLUSH VALVE WITH 0.5 gpf (BATTERY INCLUDED) M962665-0021000A COVER ASSEMBLY FOR FLUSH VALVE WITH 1.0 gpf (BATTERY INCLUDED) A923654-0070A BATTERY 6VCR-P2 M962664-0070A SOLENOID ASSEMBLY A955066-0020A ADJUSTABLE TAILPIECE M952263-0020A 3/4"...
