Independent Use With
the Supplied Cradle
The HVR-MRC1 can be used as an external
recording unit, just like the HVR-DR60, by attaching
the supplied cradle that has an i.LINK connector,
battery attachment, and DC power input. When
the HVR-MRC1 is connected to a computer via
an i.LINK (IEEE1394) cable, it is recognized as an
external drive and can be used to access files.
When connected to a video device (such as a VTR
or NLE system) via an i.LINK, it can be used to
input/output a HDV/DVCAM/DV stream.
Battery (L series) Slot
DC Power Input
✜
File Name and Folder Structure
In the HVR-MRC1, all files are stored in one folder.
Each file is named in line with the following format:
File Transfer
CF
CompactFlash card
HVR-MRC1
CF
CompactFlash card
Playback from the HVR-MRC1
+
HVR-MRC1 HVR-Z5U
i.LINK
connection
HVR-MRC1on the supplied
HVRA-CR1 cradle
Note: Interruptions in video out put may appear between recordings during playback thorough the connected HDV/DVCAM/DV device.
HVRA-CR1
i.LINK Connector
(6pin)
CF
CompactFlash card
CF card reader(USB)*
*Not supplied.
HVR-MRC1
on the supplied HVRA-CR1 cradle
Video output
*
HDV or DVCAM VTR / Camcorder
*For DVCAM recording
xx_nnnn_YYYY-MM-DD_HHMMSS.extension
(e.g., 01_0001_2007-10-01_134510.M2T)
xx:
This is a two-digit number (00 - 99) that you can
set via the "CAM No." menu of the HVR-MRC1. This
prefix number is useful when multiple CF cards are
used.
nnnn:
This is a sequential clip number. It is incremented by
one as each new recording begins.
YYYY-MM-DD_HHMMSS:
These numbers refer to the date and time of the
recording (which are derived from the date and
time data settings of the camcorder)*
Any subsequent files, divided by FAT32, will have
new time data, but retain the same clip number.
*11 The date and time digits of the file name will be listed as
"0000-00-00_000000" if the i.LINK
signal comes from any of the
following devices:
VIDEO
• A camcorder that doesn't
have date and time setting
• A camcorder or VCR that is
playing back a recorded tape
01_0001_2007-10-01_134510.M2T (4GB)
which doesn't contain data
01_0001_2007-10-01_140510.M2T (3GB)
and time data
01_0002_2007-10-03_100530.M2T (1GB)
01_0003_2007-10-03_102415.AVI (2GB)
• Other devices that don't
01_0004_2007-10-03_111030.AVI (4GB)
output date and time data via
01_0004_2007-10-03_113030.AVI (4GB)
an i.LINK stream
The folder structure and file name
created by the Memory Recording Unit
PC with CF card slot
USB connection
PC with USB interface
i.LINK connection
PC with i.LINK(IEEE1394) connector
Video output
HVR-MRC1K Features
