Summary of Contents for Vax HF86-FM-T
- Page 1 Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 1 Bagged cylinder Vax model number: V-102E Please read carefully before using this cleaner. www.vax.co.uk Always fully extend the mains cable before use. Retain for future reference.
-
Page 2: Parts Overview
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 2 www.vax.co.uk 1. Diagram V-102E Fig.1/1 1 Hose inlet 8 Pre-motor filter 15 Hard floor tool 2 On/off button 9 Post-motor filter 16 TurboTool 3 Variable power 10 Disposable dust bag 17 TurboBrush... -
Page 3: Safety Information
If the supply cord or plug is vacuum cleaner. damaged, return the vacuum cleaner to a Vax Authorised Service Agent or suitably qualified IMPORTANT: Cleaning filters improves vacuum person for examination, repair or adjustment. -
Page 4: How To Assemble
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 4 www.vax.co.uk 3. How to Assemble Fit the combination floor head by pushing onto the extension tube (Fig.3/4). IMPORTANT: Always unplug the vacuum cleaner from the electrical outlet before assembling or removing the accessories. -
Page 5: How To Operate
Vax V-102E User Guide v6.qxd 15/8/07 16:25 Page 5 V-102E 4. How to Operate 5. Accessories Cord Release The accessories can be attached directly to the handle by Fully unwind the power cord. A yellow mark on the power removing the telescopic tube and pushing in the desired cord indicates the recommended cord length. -
Page 6: Dust Bag And Filters
Lift out the pre-motor filter situated at the back of the compartment (Fig.6/2. Fig.6/5 When the post-motor filter becomes clogged or discoloured, it should be replaced. Vax recommends that this filter is replaced every 9-12 months. Fig.6/2 dirt container & filters... -
Page 7: Clearing Blockages
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 7 V-102E 7. Clearing Blockages Removing debris from the TurboBrush The brushbar will stop rotating if it is blocked during WARNING: To reduce the risk of electric shock, operation by vacuuming up foreign objects, or is strands of the power cord must be disconnected before carpet are wrapped around it. -
Page 8: Storage / Troubleshooting
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 8 www.vax.co.uk 8. Storage 9. Troubleshooting WARNING: To reduce the risk of personal injury, IMPORTANT: Always unplug the vacuum cleaner unplug the vacuum cleaner before performing from the electrical outlet and rewind the power maintenance or troubleshooting checks. - Page 9 Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 9 V-102E 10. Service & Help PROBLEM: Dust escaping from the vacuum cleaner. Cause: Dust bag full. www.vax.co.uk Solution: Empty dust bag. Cause: Dust bag not installed correctly. Solution: Review dust bag replacement.
-
Page 10: Technical Specification
Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 10 www.vax.co.uk 11. Technical Specification Voltage: 220-240V ~50Hz Wattage: 2000W Capacity: 3.5 litres approx Filters: Fibre pre-motor filter HEPA pleated post-motor filter Cord length: 6.5m approx Weight: 7.1kg approx Subject to technical change without notice. - Page 11 Vax V-102E User Guide v6.qxd 15/8/07 16:26 Page 11 V-102E This page has been left intentionally blank...
- Page 12 16:26 Page 12 EEC STATEMENT OF COMPLIANCE Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the V-102E SIRRUS bagless cylinder is manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive EMC: 2004/108/EC Electromagnetic Compatibility Directive Waste electrical products should not be disposed of with household waste.
