  • Page 2 Today we market our patented speaker systems worldwide and the high quality of the Bazooka brand is well respected by consumers and dealers of all nationalities. When properly installed, Bazooka subwoofer speaker systems will give you years of clean uninterrupted sound reproduction.

  • Page 3: Table Of Contents

    CONTENTS HELPFUL HINTS BEFORE YOU BEGIN VEHICLE PLACEMENT RECOMMENDATIONS PG 5-6 MOUNTING THE BAZOOKA PG 7-9 WIRING DIAGRAMS SPECIFICATIONS PG11-12 FEATURES ADJUSTING CROSSOVER/SETTING LEVEL USING REMOTE CONTROL TROUBLESHOOTING 16-17 WARRANTY 18-19...

  • Page 4: Helpful Hints Before You Begin

    Locate an area in the rear of the vehicle where you would like to place the Bazooka speaker systems. The location you have selected must meet the following requirements in order for the Bazooka to be properly installed in the vehicle: 1) The woofer (grill end) should be facing into a corner.

  • Page 5: Vehicle Placement Recommendations

    VEHICLE PLACEMENT RECOMMENDATIONS TRUCK INSTALLATION tube size is exaggerated for emphasis HATCHBACK INSTALLATION tube size is exaggerated for emphasis SEDAN INSTALLATION tube size is exaggerated for emphasis...
  • Page 6 BOAT PLACEMENT RECOMMENDATIONS BOW RIDERISKI BOAT tube size is exaggerated for emphasis • Under passenger console • Under seat storage compartment SPORTYAOIT tube size is exaggerated for emphasis • Under bed storage compartment • Under seat storage compartment...

  • Page 7: Mounting The Bazooka

    G THE BAZOO Figure 1 Logo should face up With the topside of the buckle facing up (see figure 1), lace the strap through the mounting base as illustrated in figure 2 Figure 2 <: 2. After the strap is completely laced through the mounting base, make a loop with the strap, where it runs across the middle of the base as illustrated in figure 3.
  • Page 8 Figure 4 3. Place each mounting base under the Bass Tubes® enclosure so that the apex at the bottom of the tube sits inside the mounting base as in figure 4. - - - - - - - - - - - - - - - - - - - - - - - - 7 I - - , "...
  • Page 9 See Model Size I. . . For Lengt Remove any slack in the strap by feeding it out of the mounting base on the loose end of the strap opposite the buckle. 8. Place the Bass Tubes® enclosure on the mounting bases and fasten the buckles as illustrated in figure 7.

  • Page 10: Wiring Diagrams

    BTA6250D/8250D/10250D 8250D-DE/10250D-DE WIRING DIAGRAM OTE ONE: BTA6250D:fuse 20A BTA8250D/8250D-DE/1 0250D/1 0250D-DE:fuse 30A...

  • Page 11: Specifications

    ENGLISH NOTE ONE: BTA8250D-DE/10250D-DE: fuse 30A AMPLIFIED TUBE SPECIFICATIONS BTAI0250DiDE BTA6250D BTA8250D/DE lO'l 8" Woofer Size Voice Coil Size high power./high temp. high power./high temp. high power./high temp. Magnet Size 38 oz. 38 oz. 38 oz. response* Frequency 35-250 hz.
  • Page 12 MODEL FEATURES = = = = = Feature Patented Bass Tubes" enclosure design Optimized for (orner loading Water resistant enclosure Fits in all vehicles Upgrades any 12 volt sound system Perfed for leased vehicles Home audio quality sound New and improved cosmetics Dual voice coil inputs large oversized edge roll Oversized magnet and motor structure...

  • Page 13: Features

    SHOULD I USE HIGH OR LOW LEVEL INPUTS? If the source unit has only speaker outputs, use the high-level inputs of the Amplified Bazooka subwoofer. If the source unit has both high and low level outputs, we recommend using the high level inputs over the low level inputs, due to the configuration of the Amplified Bazooka subwoofer's balanced input circuit.
  • Page 14 If your source unit only has low-level RCA phono jack output, use only the low-level inputs of the Amplified Bazooka. Connect the low-level RCA phono jack inputs of the Amplified Bazooka subwoofer to the source with a shielded RCA patch cord. To avoid possible noise problems, be sure to run the patch cord away from all power wires and factory wire harnesses.

  • Page 15: Adjusting Crossover/Setting Level

    Remote Level and Crossover Control. These Remote Controls are accessories that are available from your Bazooka dealer or directly from Bazooka. Be sure to check out other optional accessories for your Bazooka at...

  • Page 16: Troubleshooting

    When one of the Amplified Bazooka1s High-level Input channels is out of phase electrically with the other High-level Input channel, your Bazooka will sound as if it has little or no output and any output that is produced may sound distorted. If you...
  • Page 17 If the Bass Response increases, the Phasing is correct and you can repeat this process on the next Bazooka. If the level of the Bass Response drops, the Phasing is incorrect and you should reverse the speaker connections to this Bazooka®...

  • Page 18: Warranty

    5. Any product that has been altered or modified without SAS' consent. How to obtain warranty services: 1. You are responsible for delivery of the product to an authorized BAZOOKA® dealer or contact SAS at 1-800-THE TUBE for a Return Authorization number.
  • Page 19 PLEASE RETURN THIS PORTION IMMEDIATELY MODEL# SERIAL# PURCHASE DATE DEALER PURCHASED FROM DEALER ADDRESS TELEPHONE PURCHASERS NAME STREET ADDRESS CITY STATE TELEPHONE E-MAIL...
  • Page 20 · u...
