Connecting Another External Device

You can connect another external device (such as a phone dial-
er or an alarm system) instead of an external siren. Use Type
CL2, 22-gauge wire to connect a device to the alert's
terminals. If the beam path is interrupted with the mode switch
set to , the alert activates the external device.
ALARM
Cautions:
• The device must be rated at 12 VDC, 0.5A or less, and it
must have its own power supply.
• Do not connect a jumper wire to the OUTPUT 10–18 VDC
0.5A terminals.
Note: You cannot connect both an external siren and a dialer
(or an alarm system) to the alert.
1. Separate about 2 inches of one end of the two-conductor
wire.
2. Use a wire stripper to remove about
from the end of each conductor, then twist the loose
strands.
3. Use a Phillips screwdriver to loosen the
screws, and insert the stripped ends under
minals, then tighten the screws.
4. Insert the other conductor of the wire into the hole under
the terminal between the
the screw.
14
1
/ inch of insulation
4
or
N.O N.C
N.O
or terminals, then tighten
N.O N.C
Installation
or
N.O N.C
terminal
or ter-
N.C
