iPort FS-23 Instruction Manual

Hide thumbs Also See for FS-23:
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction Manual
FS-23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-23 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iPort FS-23

Summary of Contents for iPort FS-23

  • Page 1 Instruction Manual FS-23...
  • Page 2 — and connect it to your audio/ video system, your computer, or directly to your TV. Before installing and using the iPort, please read and follow all of the instructions in this manual carefully. iPort FS-23 Box Contents...

  • Page 3: System Capabilities

    The iPort FS-23 is designed for use in normal interior environments. When selecting a location for the system, please consider the following: • Do not use the iPort outside or in a humid or wet environment. The iPort is not waterproof, nor is it water-resistant. •...
  • Page 4 AV component. The 3.5mm video cable connects to the iPort’s Component video output. : Has L/R RCA plugs for connecting to any analog audio processor (such as a TV or AV udio outPut receiver). The 3.5mm audio cable connects to the iPort’s Audio output.
  • Page 5 FS-23 System Connections The iPort FS-23’s unbalanced audio and video outputs are designed for use in a local-zone sys- tem where the audio/video equipment is located less than 30 feet (9m) from the iPort. For longer distances, the iPort Balanced Audio Kit (part #70122, not included) and Balanced Video Kit (part #70123, not included) are available.
  • Page 6 To control To Ethernet jack system IR output MM CABLE OPTIONAL NOT INCLUDED THERNET CABLE OPTONAL NOT INCLUDED To wall outlet power iPort FS-23 supply dock To L/R OMPONENT VIDEO UDIO CABLE audio input CABLE INCLUDED INCLUDED To component component...

  • Page 7: Docking Your Ipod

    (see Figure 3). After it is docked, the dock adapter can remain in the iPort docking well. To dock the iPod, gently slide it down into the iPort docking well, as shown in Figure 4. Do not force the iPod down into the dock, as you may damage the multi-pin connector in the iPort base.
  • Page 8 If you need to change the video format of your iPort to match your TV, un-dock the iPod, then press and hold the button on the remote control for five seconds. The iPort’s video format will change, then you can re-dock the iPod to try again.
  • Page 9 Viewing an iPod’s stored photos on a connected TV requires the iPod to be in General mode. General mode lets you control the iPod directly using its scroll wheel or touch screen (iPod touch). To control the iPod directly using the iPod’s controls, from the iPort’s m , select...

  • Page 10: Playing Music Or Video

    Playing Music or Video Press Menu on the remote control to open the iPort’s Main Menu. Figure 7: m Highlight m to play music, or highlight v to play video, then press S (remote control’s uSic ideo elect center button). The menu displays the same information that is shown on the iPod display when listening to music or watching video.
  • Page 11 Press + and – on your iPort or Apple remote to highlight your choices, then press S to make elect your selections (just as you would use the iPod’s scroll wheel and center button). Figure 10: P layback controls Play/Pause...
  • Page 12 (Figure 12) appears, where you can select the submenu you want to adjust. • l : You can select the anGuaGe language of the iPort’s menus. • S : You can set the iPod ound equalizer setting, shuffle mode, repeat setting, sound check, audiobook speed, and volume control.
  • Page 13 Although you can still use the iPhone’s telephone functions while it is docked in the iPort, they do not function through the iPort itself. Dock the iPhone into the iPort dock. The iPhone screen displays the message shown in Figure 13.

  • Page 14: Installing And Setting Up The Software

    Windows XP (32-bit) or higher, MAC OS X v10.4.x (PPC version) or higher, or MAC OS X v10.4.4 (Intel version) or higher • 10/100 Ethernet network connection between the iPort and the computer Installing and Setting Up the Software Download the iPortNetSync software from iportmusic.com.
  • Page 15 Syncing with iTunes If the iPort is not connected to your network or a computer, connect it now using an Ethernet cable. On one of your networked computers, click S tart roGramS To run iPortNetSync software in Mac OS X, click the iPortNetSync icon in the Finder.

  • Page 16: In Case Of Difficulty

    Technical Assistance department or returning the iPort to your dealer. You may be able to correct the problem yourself with a minimum of inconvenience. If, after trying all of the applicable solutions, your iPort still seems to not be working properly, call your dealer or follow the directions on page 18. Component...

  • Page 17: Specifications

    • Status indicator: Blinks during network activity. Cleaning Your iPort Clean the iPort only with a damp cloth. Do not use any cleaners, chemicals, or solvents. Be careful with the docking connector so that it does not get wet or damaged.
  • Page 18 Technical Assistance Department at (800) 582-0772 or (949) 492-7777; from 7 a.m. to 5 p.m., Pacific Time, Monday – Friday. If your iPort should need repair or service, contact your iPort Authorized Dealer for help, or use the following procedure: Prior to calling, note the product’s model number, serial number (visible on the bottom of...

  • Page 19: Warranty Coverage (U.s. Only)

    purchase.
  • Page 20 | 888 . 45 . iPort | www.iportmusic.com 33-5171 121609aFinal ZDA001U...
