iPort FS-1 Instruction Manual

Free-standing docking system
Hide thumbs Also See for FS-1:
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction Manual
(ver. FS)
FS-1
FS-2
FS-3
FS-4
FS-5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iPort FS-1

Summary of Contents for iPort FS-1

  • Page 1 Instruction Manual (ver. FS) FS-1 FS-2 FS-3 FS-4 FS-5...
  • Page 2 System Components and Capabilities This manual covers five iPort free-standing systems (FS-1 – FS-5). Each system has different capabilities and includes different components. Except where noted, connections and installation are the same for all five systems.
  • Page 3 FS-2 System Capabilities: • All FS-1 capabilities PLUS: • Allows control of track playback or iPod volume via buttons on the iPort free-standing unit • Allows line-of-sight IR remote control of iPod functions — requires optional iPort Standard (part # 70031) or EX (part # 70032) remote control unit, or a compatible 3rd-party remote...
  • Page 4 • Allows extensive long-distance RS-232 control of iPod functions with 2-way communication (requires compatible 3rd-party controller) FS-4 System Box Contents: (1) iPort Dock (with Multi-Function Buttons and IR control capability) (1) Advanced Connection Box (with RS-232 capability) (1) iPort Balanced Audio Sender Wallplate (1) iPort Balanced Audio Receiver Wallplate (1) 6.5 foot (2-Meter) Double Cable...
  • Page 5 The iPort free-standing systems are designed for use in normal interior environments. When selecting a location for the system, please consider the following: • The iPort is not waterproof, nor is it water-resistant. Do not use the iPort outside or in a humid or wet environment.

  • Page 6: Connections And Controls

    ( Fixed position) the Multi-Function Buttons act as Track Skip buttons. Note: On the FS-1 this switch acts as a brightness switch for the Status Indicator: The front position is dim ; the rear position is bright .
  • Page 7 DC power supply. IR Jack: 3.5mm mini jack connects to a compatible IR control system.* Audio Connector: RJ-45 jack connects to the iPort Audio Sender Wallplate via Cat5 cable. Multi-Pin Connector: Connects to the iPort Dock using the supplied Double Cable.
  • Page 8 25 feet from the iPort Basic Connection Box. In FS-1 systems the iPod is controlled only from its front panel; in FS-2 systems the iPod can be controlled from its front panel, from the Multi-Function Buttons on the iPort Dock (see above), or from an optional iPort Standard or EX remote control (or a compatible 3rd-party remote).
  • Page 9 Figure 5: iPort FS-1 and FS-2 System Connections iPort FS-1/FS-2 Dock Double Cable Powered Speaker System Local-Zone Audio System i Po r t ve r. F S +15V DC Power Supply Line Out Power To iPort Basic (Front) (Rear) Connection...

  • Page 10: Block Diagram

    500 feet from the iPort. FS-5 systems have balanced video output designed for use with video equipment that is locat- ed up to 250 feet from the iPort.
  • Page 11 Po r t ve r. F S Cat5/RJ-45 Cable Wiring All RJ-45 cables used in iPort installations must be wired according to the T568A (“Straight-Through”) Standard, with cables wired identically at both ends. To prepare Cat5/RJ-45 cables for iPort installations: 1.
  • Page 12 8. Normally, the iPort system’s +15V DC power supply will plug into a wall outlet in the iPort Room and connect to the Advanced Connection Box (see Step 13 and Figure 10 ). If this is not possible, you can use a wall outlet in the Audio Equipment Room, as shown in Figure 8 .
  • Page 13 Figure 8: iPort FS-3 – FS-5 Audio Wallplate Connections i Po r t ve r. F S I n s t r u c t i o n M a nu a l...
  • Page 14 Connection Box and the RJ-45 jack on the Video Sender Wallplate, as shown in Figure 10 . 12. If the IR and/or RS-232 control system is local to the iPort On-Desk System, connect them direct- ly to the their respective jacks on the Advanced Connection Box, as shown in Figure 10.
  • Page 15 Figure 10: iPort FS-3 – FS-5 System Connections iPort FS-3/FS-4/FS-5 Dock Double Wall +15V DC Power Supply Outlet Mono Mini Plug From Local IR Control System* *Not normally used. See instructions iPort Audio Sender Wallplate i Po r t ve r. F S...

  • Page 16: Docking And Undocking

    Undock the iPod only when the iPort Status Indicator is white , indicating that the iPort is in the Music Stream (listening) mode. To undock the iPod while the Status Indicator is red (iPort is in the Data Transfer mode), you should issue an eject command via the computer’s music transfer software.
  • Page 17 Windows (other than Windows XP) will display an error message. (Windows XP permits ‘hot’ connection/disconnection via USB.) When you re-dock the iPod there will be a slight delay before you can use it while the iPort software re-synchronizes with the iPod. See Function Selector/Status Indicator , on page 6, for more information.
  • Page 18 • Third-generation iPod models only respond to the following IR commands: Play/Pause, Next Track, and Previous Track. For iPort IR remote control commands, please see the instruction manual accompanying the remote. RS-232 Control Notes: • When the iPod is in the RS-232 control mode its screen will appear as in Figure 13 . When the iPod is in the normal operation mode its screen will appear as in Figure 14 .

  • Page 19: Specifications

    Note: Do not over-tighten the screws. 4. Replace the top cover. • Two top covers are supplied. Use the one that places the iPort logo right-side up. Specifications Maximum signal input: Power supply: i Po r t ve r. F S...

  • Page 20: Technical Assistance And Service

    IMPORTANT: YOU MUST HAVE PRIOR AUTHORIZATION TO RETURN YOUR iPort! 3. If you’re directed to return the unit to iPort for repair, pack the unit in its original shipping carton. If needed, you can obtain replacement packaging from us for a small charge. Note: it is best if you place the box into an additional outer “overcarton”...

  • Page 21: Warranty Coverage (U.s. Only)

    otherwise.

  • Page 22: In Case Of Difficulty

    If your iPort doesn’t seem to be working properly, before calling iPort or returning the unit to the store, please read-through the following section. You may be able to correct the problem yourself with a minimum of inconvenience. If, after trying all of the applicable solutions your iPort still seems not to be working properly, call your dealer or call us at 888 45-IPORT.
  • Page 23 1) Insure that the audio output connections from the wallplate to the amplifier are securely connected. 2) Insure that the iPod is fully seated into the iPort. 3) Insure that the Cat5/RJ-45 cables used between the iPort and wallplates are wired identically (”straight-through”) 4) Insure all connections to/from the included Connection Box are securely made.
  • Page 24 | 888 . 45 . iPort | www.iportmusic.com 33-3873 09/05...
