Instructions for Installation and Use
Gainsborough II
Note: Timer must be set to 'Time of Day' and 'Manual'
before the ovens can be used.
Note: Ensure that the oven is securely fixed to the
cabinet before use.
To the Installer
Before installation fill in the product details on the back cover of this
booklet. The information can be found on the rating plate.
To the User
You must read the instructions prior to installing and using the
appliance and then retain them for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gainsborough II and is the answer not in the manual?

Questions and answers

Related Manuals for Creda Gainsborough II

Summary of Contents for Creda Gainsborough II

  • Page 1 Instructions for Installation and Use Gainsborough II Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the ovens can be used. Note: Ensure that the oven is securely fixed to the cabinet before use. To the Installer Before installation fill in the product details on the back cover of this booklet.
  • Page 2 For more information on our exciting product range ring Creda Answer Centre 08701 54 64 74 Visit us on the NET at http://www.creda.co.uk interactive cookbook product selector. Our site invites you to make use of our browse our product range bubbling away Feel free to to see what’s...

  • Page 3: Table Of Contents

    CONTENTS Introduction For Your Safety – Always For Your Safety – Never Features Controls Oven Timer Operation Know Your Timer Electronic Clock & Automatic Oven Timer Operation 11-14 Grill Pan and Handle Using The Grill Guide To Grilling Successfully Using the Oven as a Fan Oven Using the Oven for Other Functions Oven Temperature Charts 25-26...

  • Page 4: Introduction

    INTRODUCTION Your new cooker is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. To help make best use of your cooking equipment, please read this booklet carefully.

  • Page 5: For Your Safety - Always

    FOR YOUR SAFETY When used properly, your appliance is completely safe but as with any electrical product there are certain precautions that must be observed. PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. ALWAYS Always make sure you remove all packaging and literature from inside the oven and grill compartments before switching on for the first time.

  • Page 6: For Your Safety - Never

    FOR YOUR SAFETY NEVER Never leave children unsupervised where a cooking appliance is installed as all cooking surfaces will be hot during and after use. Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach. Never remove the oven shelves whilst the oven is hot.

  • Page 7: Features

    FEATURES OVEN TEMPERATURE OVEN PILOT & FUNCTION CONTROL CLOCK & OVEN TIMER GRILL SETTING CONTROL REMOVABLE ROOF PANEL GRILL ELEMENT STAY CLEAN LINER GRILL PAN INNER DOOR GLASS GRILL DOOR OVEN LIGHT OVEN FAN OVEN SHELF STAY CLEAN LINER MEAT PAN MAIN OVEN DOOR RATING PLATE –...

  • Page 8: Controls

    CONTROLS MAIN OVEN TEMPERATURE AND FUNCTION GRILL SETTING CONTROL CONTROL TIMER CONTROL MARKINGS Control Description Function Knob Grill Setting Control Selects the heat at which the grill will cook the food. 1 – 4 Grill Settings Control: 1 = Low, 4 = High Main Oven Temperature &...

  • Page 9: Oven Timer Operation

    OVEN TIMER OPERATION Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the ovens can be used. AUTOMATIC COOKING The Oven can be controlled by the automatic timer. When the timer control has been set for one oven, it is possible to use the other oven only during the same automatic cooking programme.

  • Page 10: Know Your Timer

    KNOW YOUR TIMER CLOCKFACE The timer incorporates a 24 hour clock. Ensure correct time of day is always set, before using your cooker. PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00 HOURS AND 06.00 HOURS TO PREVENT GLARE. However, should you operate the timer during these hours the display will return to normal brightness for a few seconds and then dim again.

  • Page 11: Electronic Clock & Automatic Oven Timer Operation

    ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is turned on. Minute Cook Time Manual Minder Period Step 3 When switched on the display will show 0.00 and Auto symbol will be flashing intermittently.
  • Page 12 ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION AUTO COOKING PROGRAMMES There are two Auto Cooking programmes that can be selected using your timer:– (a) To set the timer to switch the oven(s) On and Off Automatically (b) To set timer to switch on immediately and OFF automatically after a set cook period. a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY This allows you to cook at a specified time for a chosen period before the oven switches off Automatically.
  • Page 13 ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing the Cook Period button. Note 2 When cooking automatically the End Time can be checked at any time by simply pressing the End Time button.
  • Page 14 ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION TO CANCEL AN AUTO COOKING PROGRAMME BEFORE THE COOK PERIOD HAS FINISHED. Step 1 Turn the oven control(s) to the OFF position. Step 2 Press and hold in the “Cook Period” button. Minute Cook Time Manual Minder...
  • Page 15 OPERATION WHEN USING THE GRILL TOP OVEN SHELF POSITIONING FOR GRILLING The shelf can be inserted in two different ways for grilling. The grilling chart will indicate the correct orientation Orientation A Orientation B The grill pan handle is detachable from the pan, to facilitate cleaning and storage. The grill pan handle can be fixed as follows: Step 1 Step 2...

  • Page 16: Using The Grill

    OPERATION WHEN USING THE GRILL TOP OVEN SHELF POSITIONING FOR GRILLING Do not place food / utensils directly on the oven floor. There should always be at least 25mm (1 inch) between the top of the food and the grill element. NOTE: Ensure oven timer is set to Manual.
  • Page 18 USING THE OVEN FOR FAN COOKING Since a circulaire fan oven heats up more quickly and generally cooks food at a lower temperature than a conventional oven, pre-heating is often unnecessary. For guides on “pre-heating”, “cooking temperatures” and “cooking times” see “Oven Temperature Charts”...

  • Page 19: Using The Oven For Other Functions

    USING THE OVEN FOR OTHER FUNCTIONS FAN ONLY SETTING Only DEFROSTING FROZEN MEAT & POULTRY Joints of meat and whole birds should be defrosted slowly, preferably in a refrigerator (allowing 5-6 hours per lb.) or at room temperature (allowing 2-3 hours per lb.). Frozen meat or poultry must be completely defrosted before cooking in the oven.
  • Page 20 USING THE MAIN OVEN FOR OTHER FUNCTIONS “SLOW” SETTING This is used for slow cooking, keeping food warm and warming plates for short periods. Extra care should be taken when warming bone china, as it may be damaged in a hot oven. DO NOT place food or plates directly on the oven floor as this could damage both the oven lining and the plates which are being warmed.

  • Page 21: Temperature Conversion Scale

    TEMPERATURE CONVERSION SCALE Main Main Conventional Convection Mark Oven Oven Oven – – –...
  • Page 22 OVEN TEMPERATURE CHART – MEAT Main Fan Oven Cooking Food Note: Up to two shelves may be used in this oven. The position of these is not important providing they are evenly spaced. Pre- Temperature Time Meat heat (approx.) 20-25 mins per 450g (1lb) Beef 160/180 + 20 mins extra...

  • Page 23: Oven Temperature Charts

    OVEN TEMPERATURE CHART – BAKING Main Fan Oven Cooking Baking Note: Up to two shelves may be used in this oven. The position of these is not important providing they are evenly spaced. Pre- Temperature Food Time heat Scones 9-12 mins Small Cakes 15-20 mins approx Victoria Sand-...

  • Page 24: Cooking Results Not Satisfactory

    COOKING RESULTS NOT SATISFACTORY GRILL Uneven cooking front to back Ensure that the grill pan is positioned centrally below the grill element. Fat splattering Ensure that the grill pan is not lined with foil. Ensure that the grill setting control (A) is not set too high. If Solarplus grill –...

  • Page 25: Care & Cleaning

    CARE AND CLEANING Warning: Before cleaning, please ensure that the electricity supply to the appliance is switched off and the appliance is fully cold. 1. “CREDACLEAN” OVEN LINERS (a) How "Credaclean" works. TOP OVEN SIDE LINERS The surfaces of the "Credaclean" oven liners are treated with a special vitreous enamel which absorbs cooking soils.

  • Page 26: Care And Cleaning

    CARE AND CLEANING 2. CLEANING GRILL AND OVEN (a) Base & Rear of Grill Compartment and Base of Main Oven. REMOVABLE GRILL ROOF PANEL (NOT ALL MODELS OR MODELS FITTED WITH SOLARPLUS GRILL) Wipe out the oven with a damp soapy cloth. For more stubborn stains on the base of the oven use a well soaped fine steel wool soap pad.
  • Page 27 CARE AND CLEANING 3. OVEN DOORS (a) Control Panel CONTROL PANEL Regularly wipe with a clean, damp cloth and polish with a clean, dry cloth. (b) Trims It is advisable to clean the trims regularly to prevent any build up of soiling which may detract from the appearance of the cooker.

  • Page 28: Care & Cleaning

    CARE AND CLEANING TO CLEAN THE INSIDE OF OUTER AND INNER GLASS PANELS Warning: Always switch your appliance OFF at the mains supply and allow to cool before cleaning. 1. Position top or main oven door as shown in fig. 1. Fig.

  • Page 29: Installation

    INSTALLATION ELECTRICAL REQUIREMENTS For your own safety, we recommend that your cooker is installed by a competent person such as one who is registered with NICEIC (National Inspection Council for Electrical Installation Contracting). The cooker should be installed in accordance with the latest edition of the IEE Regulations. Warning: This appliance must be earthed.
  • Page 30 INSTALLATION 1. GENERAL The appliance is designed to be mounted on a floor between two adjacent cabinets. The cabinets must be securely fixed to the wall and the cooker securely fixed to the cabinets. This cooker must not be used free standing. 3.
  • Page 31 INSTALLATION 597mm min 720mm min 565mm 150mm min 170mm max A minimum distance of 25mm should be maintained between the front face of the cabinet side and the front face of the plinth.
  • Page 32 INSTALLATION Wall Fixing Bracket Cooker 1mm min Cabinet Doors Top View Double pole control switch Hob Cable 2.5mm Cable size to heat resistant suit current cable to rating of BS 6141 Table 15 appliance/s Connector Cable...

  • Page 33: Something Wrong

    SOMETHING WRONG? Before calling a Service Engineer, please check through the following lists. THERE MAY BE NOTHING WRONG. Problem Check Nothing works. (a) Check If you find :- Display is blank. Then it is likely that there is no electricity supply to your oven. Check: (i) That the main cooker wall switch is turned on.

  • Page 36: Service

    Key Contacts Service Creda has the largest appliance manufacturer’s service team in Europe, trained specialists directly employed by us to ensure your complete confidence. Repair Service UK: 08709 066 066 Republic of Ireland: 1850 302 220 You will be asked for the following information:- Name, address and postcode.
