- Page 1 H250E Installation & Users Instructions You must read these instructions prior to using the appliance and retain them for future reference.
- Page 2 For more information on our exciting product range ring Creda Answer Centre 08701 54 64 74 Visit us on the NET at http://www.creda.co.uk interactive cookbook product selector. Our site invites you to make use of our Feel browse our product range...
-
Page 3: Table Of Contents
Introduction Installation For Your Safety - Always For Your Safety - Never Features Control Panel Hotplate General Information Notes Temperature Conversion chart Grill Guide to Grilling Oven Timer Operation Know Your Timer Clock & Automatic Timer Operation Top Oven Cookery Notes Main Oven Cookery Notes Care &... -
Page 4: Introduction
Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. To help make best use of your cooking equipment, please read this booklet carefully. The cooker is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. -
Page 5: Installation
Installation WARNING – THIS APPLIANCE MUST BE EARTHED. MAINS CONNECTION Your cooker should have been checked to ensure that the voltage corresponds with your supply voltage, this is stated on the rating plate, which is situated on the rear panel.The cooker must be connected by a competent person such as a NICEIC registered contractor to suitable double- pole control unit with a minimum rating of 45A and a minimum contact clearance of 3mm, which should be fitted adjacent to the cooker, in accordance with IEE regulations. -
Page 6: Safety Information
When used properly your appliance is completely safe but as with any electrical product there are certain precautions that must be observed. PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. Always Remove all packing from the appliance before switching on for the first time. Understand the controls prior to using the appliance. -
Page 7: For Your Safety - Never
Never Never stare at Halogen heating units Never leave children unsupervised where a cooking appliance is installed as all surfaces will be hot during and after its use. Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach. -
Page 8: Features
Features RATING PLATE (ON REAR PANEL) MODEL/SERIAL NO. CONTROL PANEL RIGHT REAR HOTPLATE 1800W RIGHT FRONT HOTPLATE 1100W TOP OVEN CREDA- CLEAN SIDE PANEL TOP OVEN REMOVEABLE ROOF TOP OVEN/GRILL ROD SHELF MAIN OVEN CREDACLEAN SIDE PANEL MAIN OVEN ROD SHELF... -
Page 9: Control Knobs
Control Panel Hallmark TIMER REAR LEFT FRONT RIGHT TOP OVEN HOTPLATE HOTPLATE CONTROL CONTROL CONTROL FRONT LEFT REAR RIGHT GRILL CONTROL MAIN OVEN HOTPLATE HOTPLATE CONTROL CONTROL CONTROL CONTROL KNOBS The knobs for the grill and hotplates can be rotated in either direction to provide variable heat control, the oven knobs can only be rotated clockwise from the Off position. -
Page 10: Hotplate General Information Notes
Hotplates General Information Notes USE OF HOTPLATES Under no circumstances should the hob be used with aluminium foil in contact with the hob surface. Turn the control to H for fast cooking. To cook more slowly or simmer, turn the control to a lower setting according to the size of the saucepan and the amount of liquid. - Page 11 Hob General Information CHOICE OF UTENSILS Every Electric Hob deserves the right choice of utensils. We recommend for optimum performance the use of good quality utensils. PANS SHOULD NOT Be concave (bowed in) Be convex (bowed out) Be rimmed Be deeply ridged But essentially Flat Always Use good quality flat-based...
-
Page 12: Temperature Conversion Chart
Temperature Conversion Chart Mark Main Convection Convection Oven – – Main Oven Oven –... -
Page 13: Grill
Setting the Grill Door in grilling position Grill pan handle Grill CAUTION – ACCESSIBLE PARTS WILL BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. GRILLING SHOULD NOT BE UNDERTAKEN WITH THE GRILL DOOR CLOSED. Never line the grill pan with aluminium foil. The grill control is designed to provide variable heat control of the grill element. -
Page 14: Grill Chart
Pre - heat the grill for 5 minutes on maximum control setting before grilling GRILL CHART Food Toasting of Bread Products Small cuts of meat, sausages, bacon Chops, etc. Gammon steaks Fish: whole fillets fingers Pre-cooked potato products Pizzas Browning of food The settings in the above guide have been developed to cook food successfully without Guide To Grilling Shelf Position... -
Page 15: Automatic Cooking
The oven timer offers you the following features: Time of Day Automatic Cooking Minute Minder AUTOMATIC COOKING The Top Oven and Main Oven can be controlled by the automatic timer. When the timer control has been set for one oven it is possible to use the other oven only on the same automatic cooking programme. -
Page 16: Timer Functions
Minute Minder “OFF” position Display Window KEY: ORANGE FINGER : START TIME SETTING YELLOW FINGER : MINUTE MINDER SETTING TIMER FUNCTIONS Time of Day Main Clockface Ensure correct time of day is always set. Minute Minder Yellow Finger / Small Dial Here you can set a time period of up to 55 minutes, that will count down. -
Page 17: Clock & Automatic Timer Operation
Clock & Automatic Oven Timer Operation TO SET & RE-SET THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is switched on. Step 3 Pull knob (B) and turn clockwise until the correct time of day is Step 4 Ensure that the yellow minute minder finger remains at the TO SET THE TIMER FOR MANUAL OVEN OPERATION Step 1 Turn the upper knob (A) clockwise (without pulling) until the... -
Page 18: Auto Cooking Programmes
Clock & Automatic Oven Timer Operation AUTO COOKING PROGRAMMES There are two Auto Cooking programmes that can be selected using your timer:– (a) To set the Timer to switch the oven(s) ON immediately and OFF at a preset time - Up to 180 minutes. - Page 19 Clock & Automatic Oven Timer Operation b) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY Step 1 Check that the correct time of day is set, if not follow instructions Step 2 Place food onto the correct shelf position in the oven and close the Step 3 Turn the upper knob (A) (without pulling), clockwise, until the Step 4 Set the orange finger to the "Start"...
- Page 20 Clock & Automatic Oven Timer Operation TO CANCEL AN AUTO COOKING PROGRAMME BEFORE COOK PERIOD HAS STARTED Step 1 Turn the oven control(s) to their OFF position. Step 2 Turn (without pulling) the upper knob (A) clockwise until the Step 3 Pull and turn the upper knob (A) clockwise until the orange finger Step 4 Turn the upper knob (A) clockwise (without pulling) until the TO CANCEL AN AUTO COOKING PROGRAMME ONCE THE AUTO COOK PROGRAMME HAS STARTED...
-
Page 21: Top Oven Cookery Notes
Top Oven - Cookery Notes TOP OVEN COOKING The Top Oven is used in exactly the same way as the main oven to cook all types of food. It can either be used alone, to cook small quantities of food, or in conjunction with the main oven to provide additional cooking space, so often necessary when entertaining. -
Page 24: Main Oven Cookery Notes
Oven Control To prepare meat for roasting in your electric oven Oven With the oven door closed, heating of the oven is achieved by turning the control clockwise to the required ‘oven temperature’ scale on the control panel, as recommended in the temperature charts. - Page 25 Temperature and Time Meat pan and rod shelves Oven Cookery Notes The secret of succulent, tender meat, is not to roast quickly at too high a temperature. Best results are obtained when roasting is carried out at low temperatures. When a lower temperature is used, the joint loses less weight, is more ten- der (too high a temperature causes meat to be tough and dry), and the splashing of fat onto oven interior is reduced.
-
Page 28: Oven Doors
Care and Cleaning WARNING Turn off the main switch before cleaning. Before switching on again, ensure that all con- trols are in the off position. Never use biological washing powder, harsh abrasives, scouring pads, aerosols cleaners or oven chemical cleaners of any kind. CONTROL PANEL Wipe with a damp cloth wrung out in warm soapy water and polish with a dry cloth. -
Page 29: Care & Cleaning
HOW ‘CREDACLEAN’ WORKS The surface of the ‘Credaclean’ oven liners are treated on the mottled face with a special vitreous enamel which absorbs cooking soils. At temperatures of 220°C (425°F) or above, the special sur- face enables these soils to be slowly destroyed. The higher the temperature the more effective it is. -
Page 30: Cooking Results Not Satisfactory
Cooking Results Not Satisfactory GRILL Uneven cooking front to back Fat splattering BAKING GENERAL Uneven rising of cakes Sinking of cakes Over/undercooking TOP OVEN BAKING Uneven cooking front to back Uneven rising Overcooking Food is taking too long to cook May we wish you many years of carefree successful cooking and remember our Home Economics Department is always available for advice if you write to: Ensure that the grill pan is positioned centrally below... -
Page 31: Something Wrong
Before calling a Service Engineer, please check through the following lists. Problem Nothing works. Clock is working but has lost time. Main & Top Ovens do not work, but the Grill works. Top Ovens and Grill do not work, but the Main Oven works. Grill does not work. -
Page 32: Extended Warranty
Genuine Parts & Accessories For further product information All Creda Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
