- Page 1 RF Power Amplifiers Models PA10W and PA100W Owner’s Manual SpinCore Technologies, Inc. http://www.spincore.com...
- Page 2 SpinCore Technologies, Inc. makes every effort to verify the correct operation of the equipment. This equipment version is not intended for use in a system in which the failure of a SpinCore device will threaten the safety of equipment or person(s).
-
Page 3: Table Of Contents
TTL Control Input Connector..................7 DC Power Input Connector ..................9 4. Configuration Options....................9 1. PA10W RF Module with deblanking circuitry, no enclosure........9 2. PA10W RF module with enclosure..............10 3. PA10W RF module enclosure with Preamplifier Option........12 5. Higher RF output power...................12 III. - Page 4 RF Power Amplifiers IV. Contact Information.................21 V. Document Information................21 http://www.spincore.com 2010-07-30...
-
Page 5: Precautions
Make sure the following considerations have been made before applying power to the amplifier. 1) Be sure your load can appropriately dissipate the maximum power being applied by the amplifier. 2) When applying an RF signal, work with low duty cycles to limit the power being dissipated. http://www.spincore.com 2010-07-30... -
Page 6: Pa10W - 10 W Power Amplifier Module
MRI system. See the “Configuration Options” section later in this document for more information. The use of a low pass (or band pass) filter at the output of the PA10W is recommended to reduce high frequency noise and improve performance. -
Page 7: Connector Information
TTL signal source capable of sourcing at least 10 mA. A logical high signal is required to deblank (enable) the PA10W. The deblanking bit must be set at least 3 ms prior to sending the RF signal or optimal power will not be achieved. - Page 8 RF Input RF Output Figure 3: Representation of the deblanking and RF input and output signals to the PA10W. The PA10W requires at least 3.0 ms of deblanking time prior to the RF pulse for full output power. http://www.spincore.com 2010-07-30...
-
Page 9: Dc Power Input Connector
RF Power Amplifiers DC Power Input Connector The PA10W RF power amplifier has a 4-pin input power connector. The input is for use with a standard PC ATX power supply connector. The pin arrangements for this connector are shown below in Figure 4. -
Page 10: Pa10W Rf Module With Enclosure
RF Power Amplifiers 2. PA10W RF module with enclosure The PA10W RF power amplifier can be delivered in various external enclosures which protect the RF power amplifier circuitry and include an AC/DC power supply, internal RF cables and output low-pass (or band-pass) filter (please specify your operating frequency at the time of purchase). - Page 11 -High quality 80 Watt AC input switching power supply. -Dimensions are approximately 11” x 7” x 6.75” (28 x 18 x 17 cm). Figure 7: PA10W RF power amplifier – enclosed with iSpin system. iii) PA10W in Lightweight aluminum enclosure (Figure 8) Small aluminum enclosure additional specifications include: -Lightweight aluminum enclosure.
-
Page 12: Pa10W Rf Module Enclosure With Preamplifier Option
RF Power Amplifiers 3. PA10W RF module enclosure with Preamplifier Option The enclosure can also include input preamplifiers (approx 45 or 60 dB of gain – please specify when ordering) to the RadioProcessor board. This option is perfect in combination with the iSpin- Mini system to provide a complete mobile NMR system (see Figure 9). -
Page 13: Pa100W - 100 W Power Amplifier Module
- see the “Configuration Options” section later in the document for more information. 2. Specifications DC Electrical Specifications Parameter Specification Units Max DC Input Voltage V (DC) Max RF input power Max. continuous RF output power W (RMS) Table 2: Basic electrical specifications for the PA100W power amplifier module. http://www.spincore.com 2010-07-30... -
Page 14: Rf Specifications
SMA jack on the left hand side (top view) of the circuit (RF in). The SMA jack on the right hand side (top view) is the RF output from the power amplifier (RF out). See Figure 10 (next page) for details. http://www.spincore.com 2010-07-30... -
Page 15: Ttl Control Input Connector
RF pulse. The end of the deblanking signal coincides with the end of the RF pulse. See Figure 12 (next page) for details. Figure 11: 10-pin IDC connector (Digi-Key part A33159-ND). Mates with Digi-Key part HKC10H-ND or similar. http://www.spincore.com 2010-07-30... -
Page 16: Dc Power Input Connector
The RF power amplifier has a 5-pin screw-terminal input power connector. The pin arrangements for this connector are shown below in Figure 13 (top view). Figure 13: Top view of the 5-position power input connector (Molex part 38720-6305). http://www.spincore.com 2010-07-30... -
Page 17: Configuration Options
DB-9 input connectors. The active TTL signal needs to be connected to pin 4, with the corresponding ground line connected to pin 8. Available enclosure configurations are listed on the next page and they include the following: a single bay enclosure, a rack mount enclosure, and an enclosure with adjustable DC power supply. http://www.spincore.com 2010-07-30... - Page 18 -High quality quiet +24 V linear power supply. -Built-in 12 x 12 cm quiet cooling fan. -Dimensions are approximately 17.7” x 17.3” x 7” (45 x 44 x 18 cm). Figure 16: PA100W RF power amplifier – rack-mount enclosure with integrated power supply http://www.spincore.com 2010-07-30...
- Page 19 -Dual LED displays for output Volts & Amps. -.02% Line & .01% +15mV Load regulation, <1mV RMS ripple. -Dimensions are approximately 13” x 10.25” x 6.25” (28 x 18 x 17 cm). Figure 17: PA100W RF power amplifier – enclosed with DC power supply. http://www.spincore.com 2010-07-30...
-
Page 20: Typical Set-Up For Nmr Experiments
RF Power Amplifiers 5. Typical Set-Up For NMR Experiments Figure 18 shows a typical connection diagram in which both the PA10W and PA100W are used with SpinCore's iSpin-NMR system to run NMR experiments. Figure 18: Typical NMR setup with iSpin-NMR, PA10W, and PA100W with enclosure. -
Page 21: Iv. Contact Information
4631 NW 53rd Avenue, SUITE 103 Gainesville, Florida 32653 Telephone: +1-352-271-7383 Web: http://www.spincore.com/ V. Document Information Document Title: RF Power Amplifier Manual Document Number: DA-45 For more information on revision history please contact SpinCore Technologies, Inc., at the address above. http://www.spincore.com 2010-07-30...
