- Page 1 GINREI MONO POWER AMPLIFIERS OWNER’S INFORMATION...
- Page 2 CONTENTS 1) IMPORTANT SAFETY INFORMATION 2) CE DECLARATION OF CONFORMITY DISPOSAL POWER REQUIREMENTS 3) INTRODUCTION 4) OVERVIEW UNPACKING AND INSTALLATION 5) VALVE INSTALLATION 8) CONNECTION 9) OPERATION 10) TECHNICAL SPECIFICATIONS 11) WARRANTY INFORMATION CONTACT INFORMATION...
- Page 3 ! IMPORTANT SAFETY INFORMATION ! RISK OF SHOCK OR ELECTROCUTION! INTERNAL OPERATING VOLTAGES ARE LETHAL! Do not remove top cover, unless specifically instructed to do so in the user manual. This unit contains fuses and other safety components in accordance with BS60065 requirements.
- Page 4 BS EN 60065 in accordance with the regulations 73/23/EEC, 89/336/EEC (from 1 January 1997) CE 94 Peter Qvortrup, Director Audio Note (UK) Limited 25 Montefiore Road Hove East Sussex BN3 1RD United Kingdom...
- Page 5 INTRODUCTION Thank you for purchasing this Audio Note (UK) product. With the correct care it should give you many years of pleasure and enjoyment. Please take the time to read all of the information in this manual before connecting your new component to an electrical supply or your system, to ensure both your safety and satisfaction.
- Page 6 211 triode valves per chassis, producing a level of performance that is radically superior to the vast majority of current designs. They use a similar circuit design and topology to the legendary Audio Note (UK) GAKU-ON amplifiers. However, where the GAKU-ON power amplifiers use silver wherever possible, such as for all transformer windings, the GINREI instead use copper for the primary windings and silver for the secondary windings.
- Page 7 VALVE INSTALLATION The amplifiers are shipped without the valves installed. It is necessary to install the valves prior to operation. It is essential that the valves are installed correctly or serious damage that is not covered by the warranty will result. We recommend that your dealer perform this procedure for you if you are in any way unsure.
- Page 8 VALVE INSTALLATION continued… Inspect a 211 valve and you will notice that there is a small ‘pin’ protruding from one side of the valve base; this locating pin ensures that the valve can only be correctly inserted into the amplifier in one way. Also examine the two large apertures in the top plate of the amplifier, located...
- Page 9 VALVE INSTALLATION continued… Looking from the back of the amplifier, insert the 5R4WGB valves into the two empty sockets located on the left, situated between the black rectangular transformer covers and the loudspeaker connection binding posts. Locate the rib on the central pin of the valve and align with the valve base (it can only be inserted one way due to this locating rib) and with gentle but firm pressure insert the valve.
- Page 10 (also marked “ + “) on the speaker. Mains The GINREI use an IEC 320 mains inlet socket for each chassis. Use the supplied mains cables to connect the units to the local mains supply. The mains fuses are located in separate fuse holders located on the rear panel of each chassis.
- Page 11 Once all the connections are completed and checked, ensure that the volume control of your preamplifier / source is at the minimum setting. Turn on all components in the signal chain BEFORE the GINREI; they should always be the LAST components to be switched ON, and the FIRST to be switched OFF.
- Page 12 TECHNICAL SPECIFICATIONS 600 Ohm, XLR / Balanced line level INPUT IMPEDANCE 45 watts (approximate) per channel into 4 MAXIMUM OUTPUT or 8 Ohm loads +/- 0.3dB CHANNEL BALANCE 2 x 5R4WGB VALVE COMPLIMENT 2 x 211 (PER CHASSIS / AMPLIFIER) 1 x 6V6GT UNIT WEIGHT 27.5KG...
- Page 13 Audio Note (UK) warrants this product to be free from defects in materials and workmanship for two years from the original date of purchase from an appointed Audio Note (UK) dealer, and agrees to cover the cost of parts and associated labour required to correct such defects, subject to terms & conditions.
- Page 14 CONTACT INFORMATION If in the future your Audio Note (UK) product requires servicing, or if you require technical support or have any questions regarding this or any of our other products, please contact your local Audio Note (UK) dealer. Alternatively, please feel free to contact us directly: -...
