Multi-Graphics
Support for AMD CrossFire
Š
Technology
Storage Interface Š Chipset:
- 1 x M.2 PCIe connector
- 1 x SATA Express connector
- 6 x SATA 6Gb/s connectors
( M.2, SATA Express, and SATA3 4/5 connectors can only be used one at a time.
The SATA3 4/5 connectors will become unavailable when an M.2 SSD is installed.)
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
USB Chipset:
Š
- 6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
- 8 x USB 2.0/1.1 ports (2 ports on the back panel, 6 ports available through
the internal USB headers)
Internal 1 x 24-pin ATX main power connector
Š
Connectors 1 x 8-pin ATX 12V power connector
Š
1 x M.2 PCIe connector
Š
1 x SATA Express connector
Š
6 x SATA 6Gb/s connectors
Š
1 x USB 3.0/2.0 header
Š
3 x USB 2.0/1.1 headers
Š
1 x CPU fan header
Š
1 x water cooling fan header (CPU_OPT)
Š
3 x system fan headers
Š
1 x front panel header
Š
1 x front panel audio header
Š
1 x serial port header
Š
1 x Trusted Platform Module (TPM) header
Š
1 x S/PDIF Out header
Š
1 x Clear CMOS jumper
Š
Back Panel 1 x PS/2 keyboard/mouse port
Š
Connectors 1 x D-Sub port
Š
1 x DVI-D port
Š
1 x HDMI port
Š
4 x USB 3.0/2.0 ports
Š
2 x USB 2.0/1.1 ports
Š
1 x RJ-45 port
Š
6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker
Š
Out, Line In, Line Out, Mic In)
I/O Controller iTE I/O Controller Chip
Š ®
technology
™
- 11 - Hardware Installation
