18" ELECTRIC FIREPLACE HEATER
OWNERS MANUAL
Model BYCH-18
ONLY use this insert as described in this manual. Any other use is not recommended
by the manufacturer, and may cause fire, electric shock, or other personal injury.
WARNING! Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could result in fire,
electric shock, serious personal injury, or death.
WARNING! INDOOR use only! NEVER use this product outdoors!
SAVE THESE INSTRUCTIONS!
CAUTION! Keep this owner's manual for future reference. If you sell or give this product
away, make sure this manual accompanies this product.

Advertisement

Table of Contents
loading

Related Manuals for Vendor BYCH-18

Summary of Contents for Vendor BYCH-18

  • Page 1 Meijer.com 18” ELECTRIC FIREPLACE HEATER OWNERS MANUAL Model BYCH-18 ONLY use this insert as described in this manual. Any other use is not recommended by the manufacturer, and may cause fire, electric shock, or other personal injury. WARNING! Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product.

  • Page 2: Important Safety Information

    Meijer.com IMPORTANT SAFETY INFORMATION! WARNING  ALWAYS keep electric cords, home furnishings, drapes, clothing, papers, or other combustibles at least 3 feet (0.9m) away from the front of this insert, and away from the bottom, sides, and rear of this insert. ...
  • Page 3 Meijer.com WARNING  Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside!  ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace.  ALWAYS store this insert in a dry location. NEVER use the fireplace if it has become wet. ...
  • Page 4 Meijer.com PREPARATION A complete electric fireplace heater should consist of two parts; the wooden mantle and the fireplace heater. Each is packed in a separate carton. Always use the fireplace heater with the wooden mantle. Remove all parts from the carton and place them on a clean, soft, dry surface. Check the parts list to make sure nothing is missing.
  • Page 5 Meijer.com ASSEMBLY You will need: x 14 x 28 REAR STEP 1. Thread two frame screws (2) through each plastic connector (1) and into pre-drilled holes in panels C, C, D, and E. Secure with Phillips screwdriver. DO NOT OVER-TIGHTEN. You will need: REAR STEP 2.
  • Page 6 Meijer.com You will need: REAR STEP 3. Thread a frame screw (2) through each plastic connector on side panels (C) and into pre- drilled holes in front panels D and E. Secure with Phillips screwdriver. DO NOT over-tighten. You will need: REAR STEP 4.
  • Page 7 Meijer.com You will need: STEP 5. Align joiner plates (3) of header panel (F) with panel assemblies (C/D and C/E). Thread a frame screw (2) through each joiner plate hole and into pre-drilled holes in front panels. Secure with Phillips screwdriver. DO NOT over-tighten. You will need: STEP 6.

  • Page 8: Insert Installation

    Meijer.com INSERT INSTALLATION ALWAYS unplug this fireplace insert before installing, cleaning, or relocating it. Failure to do so could result in electric shock, fire, or personal injury. You will need: STEP 1. Slide electric fireplace insert carefully into mantel from behind until flange is flush with mantel wall and insert is centered in front opening.

  • Page 9: Operation

    Meijer.com OPERATION Read and understand this entire owner’s manual, including all safety information on pages 2 and 3, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. Power Make sure the ON/OFF switch, located on the control panel, is in the OFF position.

  • Page 10: Temperature Limiting Control

    Meijer.com When the insert is first turned on, a slight odor may be present. This is normal and NOTICE should not occur again unless the insert is not used for a long period of time. The light bulbs may become loose during shipping. If the flame effect does not NOTICE operate properly, check the light bulbs to make sure they are properly secured in the sockets.

  • Page 11: Changing The Light Bulbs

    Meijer.com Changing the Light Bulbs There are two (2) 40W Type B-10 light bulb located under the log bed. ALWAYS use care when handling glass! Although this is safety glass it may break if bumped, struck or dropped. NEVER operate this product with missing or broken glass. 1.

  • Page 12: Limited Warranty

    Damage from use as a primary heat source; Other misuse or abuse not specifically listed herein. This product is not intended to be used as a primary heat source. VENDOR DEVELOPMENT GROUP, INC.(HEREAFTER, VDG), ITS DIRECTORS, OFFICERS, OR AGENTS, WILL NOT BE LIABLE TO THE PURCHASER OR ANY THIRD PARTY, WHETHER IN...
