ELECTRIC FLAT PANEL FIREPLACE HEATER
OWNERS MANUAL
For use with Models EF27B / SHWALL-35
Only use this heater as described in this manual. Any other use is not recommended
by the manufacturer, and may cause fire, electric shock, or other personal injury.
WARNING! Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could result in fire,
electric shock, serious personal injury, or death.
WARNING! INDOOR use only! NEVER use this heater outdoors!
CAUTION! Keep this owner's manual for future reference. If you sell or give this product
away, make sure this manual accompanies this product.
Advertisement
Table of Contents
Related Manuals for Vendor EF27B
Summary of Contents for Vendor EF27B
- Page 1 ELECTRIC FLAT PANEL FIREPLACE HEATER OWNERS MANUAL For use with Models EF27B / SHWALL-35 Only use this heater as described in this manual. Any other use is not recommended by the manufacturer, and may cause fire, electric shock, or other personal injury.
-
Page 2: Important Safety Information
Meijer.com IMPORTANT SAFETY INFORMATION! WARNING ALWAYS keep electric cords, home furnishings, drapes, clothing, papers, or other combustibles at least 3 feet (0.9m) away from the front of this heater, and away from the bottom, sides, and rear of this heater. DO NOT place the heater near a bed because objects such as pillows or blankets can fall off the bed and be ignited by the heater. - Page 3 Meijer.com WARNING Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside! ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace. ALWAYS store this heater in a dry location. NEVER use the fireplace if it has become wet. NEVER use this heater in bathrooms, laundry rooms, or any other location where the heater could fall into a bathtub or pool, become damp or come in contact with water.
-
Page 4: Parts & Hardware
Meijer.com PREPARATION This carton includes a GLASS panel! Always use extreme caution when handling glass. Failure to do so could result in personal injury or property damage. Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Check to make sure nothing is missing. - Page 5 Meijer.com PARTS & HARDWARE Air Vent Panel, Hardware, Remote Control Decorative Stones 2 – M4x8 Machine WS – White Stones ( set ) Screws ( 2 ) RC – Remote Control ( 1 ) RC Battery ( 1 ) CS – Clear Faux Stones ( set ) Wall Hanging Hardware 3 –...
-
Page 6: Assembly Instructions
Meijer.com ASSEMBLY INSTRUCTIONS Minimum clearance: 2 inches (5 cm) from Wall or other edge of glass objects at side Wall or other objects at side Minimum clearance: 2 inches (5 cm) from edge of glass Minimum clearance: 11¾ inches (30 cm) from bottom edge Floor or other surface... - Page 7 Meijer.com AVOID INJURY and DAMAGE! Four screws should be screwed directly into wall studs. If that is not possible, at least two screws must be screwed directly into wall studs, AND four additional screws must also be screwed into the drywall anchors. STEP 3.
- Page 8 Meijer.com STEP 5. If only one wall stud is available, the wall mount bracket must be secured to the wall with two M5x40 wood screws (3) though the two center post holes AND four M4x30 drywall screws (4) through one other set of bracket holes. DO NOT attach the wall mount bracket to the wall studs with one of the outer sets of holes as the bracket will not be stable.
- Page 9 Meijer.com STEP 8. Thread the two M5x40 wood screws (3) through the center post holes, into the pilot holes, and into the wall stud. Partially tighten. Make sure the bracket is level. Thread the four M4x30 drywall anchor screws (4) through the wall mount bracket and into drywall anchors. DO NOT OVER- TIGHTEN as this may loosen the anchors or damage the drywall.
- Page 10 Meijer.com WS/CS STEP 10. Arrange the white stones (WS) and clear faux stones (CS) along the inset window ledge at the front of the firebox. Use care when moving the fireplace as the stones may shift positions. The next step requires installation of a GLASS panel! The manufacturer recommends that two adults install the glass panel.
-
Page 11: Temperature Limiting Control
Meijer.com OPERATION Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. Power Make sure the ON/OFF switch, located on the control panel, is in the OFF position. Plug the power cord into a 110~120 Volt 15 Amp grounded outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3). -
Page 12: Control Panel Operation
Meijer.com Control Panel Pilot Lights Flame Effect Backlights Control Panel Operation (Each symbol means Press Button Once) BUTTON FUNCTION PRESS and INDICATION Beep. ON. Flame effect, heaters, The ON/OFF switch must be ON for the lights, and fans remain OFF. flame and heater functions to operate. -
Page 13: Remote Control Operation
Meijer.com Remote Control Operation (Each symbol means Press Button Once) BUTTON FUNCTION PRESS and INDICATION Beep. Flame effect – High intensity. The CONTROL PANEL switch must be ON to use the REMOTE CONTROL. All other functions are now enabled. The POWER button turns on the flame Beep. -
Page 14: Remote Control Information
Meijer.com Remote Control Information NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be... -
Page 15: Care And Maintenance
Meijer.com CARE AND MAINTENANCE Cleaning ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury. -
Page 16: Limited Warranty
Damage from use as a primary heat source; Other misuse or abuse not specifically listed herein. This product is not intended to be used as a primary heat source. VENDOR DEVELOPMENT GROUP, INC.(HEREAFTER, VDG), ITS DIRECTORS, OFFICERS, OR AGENTS, WILL NOT BE LIABLE TO THE PURCHASER OR ANY THIRD PARTY, WHETHER IN...
