FOR INDOOR USE ONLY
120VAC 15 AMP DEDICATED CIRCUIT
The Infrared Heater works with your in‐home furnace to provide supplement heat. Carefully and
thoroughly read this manual before using the Infrared Heater for the first time. We recommend
keeping this manual for regular review and future reference. Heater is intended for residential use.
Infrared Heater
User's Manual
Model#WI-0035
1
Advertisement
Table of Contents
Related Manuals for Westpoint WI-0035
Summary of Contents for Westpoint WI-0035
- Page 1 Infrared Heater User’s Manual Model#WI-0035 FOR INDOOR USE ONLY 120VAC 15 AMP DEDICATED CIRCUIT The Infrared Heater works with your in‐home furnace to provide supplement heat. Carefully and thoroughly read this manual before using the Infrared Heater for the first time. We recommend...
-
Page 2: Important Instructions
Introduction Infrared Heaters utilize the latest infrared heat technology. Infrared Heaters provide a safe, convenient, clean, and economical way to distribute heat throughout your home or business without producing deadly fumes or monoxide gases. Our heating system produces therapeutic infrared heat that can potentially relieve symptoms of cardiovascular conditions and inflammatory diseases. -
Page 3: Heater Specifications
Use heater only as described in this manual. Any other use is not recommended by the manufacturer as it may lead to fire, electric shock, and/or series physical injury or death. Heater Specifications Heater Model# WI-0035 Carton Size: 18.5 in x 17.1 in x 18.6 in Thermostat: Electronic Analog Heater Size: 16.5 in L x 16.5 in W x 15 in H... -
Page 4: Operating Instructions
B. An AC Cross Flow Fan pushes air over these Infrared Quartz Bulbs. Cross Flow Fans create a wide flow of air using a cylindrical-shaped impeller. Air is drawn inside the Infrared Heater, flows along the circumference of the chamber and over the Infrared Quartz Bulbs, and is blown out laterally creating a uniform flow of warm air. - Page 5 Adjust TIME / TEMP with down arrow or adjust F settings. 1) Plug the power cord directly into a conventional 120V 15 amp outlet and press the MASTER POWER switch on the rear of the portable heater. Then press the POWER button on the front control panel or on the remote to start the unit.
- Page 6 5 seconds later the value switches to ambient temperature 4) Again, the default set temperature displayed on the LED display is 72 F. By pressing the TEMP button, the LED display will switch to the temperature status and flash. You must press the HI/LOW/UP button or F/DOWN button once again within (5) seconds to set the desired temperature.
-
Page 7: Care, Maintenance, And Storage
your room is that cooler or that the heater is not heating. If your heater’s display and your external temperature read-out mechanism (thermometer, wall thermostat, etc.) are within a 5 to 6 degree difference, it is completely normal. Recommendations for Maximum Performance 1. -
Page 8: Troubleshooting
Troubleshooting 1. PROBLEM: a. If the Heat Emitter is broken or damaged b. If the Control Panel is not responding, the temperature reading is above 86 F/30 C, or there is a burning odor coming from the portable heater c. Or if the power cord is damaged SOLUTION: Contact the manufacture immediately. -
Page 9: Warranty Information
SOLUTION: Contact the manufacturer immediately. DO NOT attempt to operate the portable heater as this may cause electric shock, fire, and/or injury. Warranty information 1. Warranty period is 12 months from the purchased date. 2. This warranty is void if the Portable Heater has been altered, misused, or has been repaired by an unauthorized dealer, or it is not installed according to stated instructions.
