15˝ LCD Touch Screen Monitor
Installation & User's Manual
* Important Notice: Please read this manual carefully
All brand names and trademarks are the property of their respective owners

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15? LCD Touch Screen Monitor and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Synaps 15? LCD Touch Screen Monitor

  • Page 1 15˝ LCD Touch Screen Monitor Installation & User’s Manual * Important Notice: Please read this manual carefully All brand names and trademarks are the property of their respective owners...
  • Page 2: Table Of Contents

    Table of Contents Precautions............................3 Package Contents ........................... 4 Hardware Setup ..........................4 Installation ............................5 Quick Installation Guide for Touch Screen ................6-7 Calibration for Touch Screen ......................8-9 Mouse Emulator ..........................10 Menu Control Buttons........................11 OSD Menu Mode..........................12 Display Modes ..........................
  • Page 3: Precautions

    Precautions 1. Read all of these instructions and save this manual for later use. 2. Follow all warnings and instructions on the product. 3. Do not cover or block the ventilation holes in the case. 4. Do not insert sharp objects or spill liquid into the LCD monitor through the cabinet slots; this may cause accidental fire, electric shock or failure.
  • Page 4: Package Contents

    Package Contents 15” Touch Screen LCD Monitor External Univ15 pin D-sub Audio connector : stereo (RGB Analog) input signal cable Phone Jack Power Cord USB Cable User’s Manual Screws & Washers & Driver CD Hardware Setup Handle the LCD monitor with care. Turn off the LCD’s and PC’s power before beginning setup. Follow the installation instructions step by step.
  • Page 5: Installation

    Installation Important note for Windows User’s Before attaching your new LCD monitor to your computer, please make sure that your resolution and refresh rates are set correctly in order that your monitor works properly. The recommended resolution is 1024 x 768 at 75Hz. You can adjust these settings by right clicking your desktop, select “Properties”, then “Settings”.
  • Page 6: Quick Installation Guide For Touch Screen

    5. Plug the USB cable to the USB In port port at the rear of the monitor. 6. Power on the computer and the monitor. Quick Installation Guide for Touch Screen Monitor Driver The Driver CD included with your Touch Screen monitor supports the following operating systems: Windows 98 SE, ME, 2000, XP, and iMac.
  • Page 7 Or click on Start -> Run to browse the Driver CD. Browsing the Driver CD and selecting Setup.exe. 3. Click on the [Next >] button to continue installation. Installing the setup program. 4. You will be prompted with the check box for the PS/2 touch controller is to be installed. Leave the checkbox unchecked. Then Press [Next >] to continue installation.
  • Page 8: Calibration For Touch Screen

    5. Select the appropriate folder where set-up files will be installed. Then Press [Next >] to continue installation. Choosing the destination location. Selecting the program folder. 6. Windows will copy the driver files to your hard drive and the setup is complete. It will request for you to re-boot the computer.
  • Page 9 3. Please follow the guide on your monitor screen to touch and hold the blinking X symbol in the calibration window until it stops blinking. This will assure that the utility can gather essential location data for computation to take place. You may notice that a time line bar is shown in the bottom of the window to indicate the time elapsed from the moment you touch the X.
  • Page 10: Mouse Emulator

    Draw Test This function is used for an accuracy and performance check. Draw straight lines with your finger tip to see if the touch screen is recording your touch contact points in the exact location. If the location is off, please redo the Linearization process.
  • Page 11: Menu Control Buttons

    Menu Control Buttons Symbol Function 1. Auto-adjust. 2. Move the selector highlight bar upward. 1. Open the OSD (On Screen Display). 2. Move the selector highlight bar downward. 1. Turns the power on / off. 2. LED indicator glows green when power is ON, POWER orange in stand by mode.
  • Page 12: Osd Menu Mode

    On Screen Display (OSD) Menu Press the “M” button to access the OSD menu. “ ” Select the desired function menu, by pressing or the “M” button. “ ” Use the “+” and buttons to adjust the selected setting’s value(s). Adjusts the brightness of the display.
  • Page 13: Display Modes

    Display Modes Display Mode Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) 640x480 31.47 59.94 640x480 37.86 72.81 640x480 37.50 75.00 800x600 35.16 56.25 800x600 37.88 60.32 800x600 48.08 72.19 800x600 46.88 75.00 720x400 31.47 70.09 1024x768 48.36 60.00 1024x768 56.48 70.07 1024x768 60.02...
  • Page 14: Specifications

    Specifications LCD Panel Type 15.0” TFT Active Matrix LCD Display Viewing Angle H:140° , V:130° Contrast Ratio 450 : 1 (Typical) Brightness 250 cd/m (Typical) Response Time 8 ms Display Colors 16.2M colors Max Resolution 1024 X 768 Pixel Pitch 0.279mm(H)x0.279mm(V) Aspect Ratio 4 : 3...
  • Page 15: Troubleshooting

    Troubleshooting LCD Pixel Criteria Normally, a 15" SXGA (1024 X 768) display has nearly 4 million sub-pixels. There may be up to 8 non-performing pixels on the LCD screen, which is only 0.0002% of the total sub-pixels. This percentage is acceptable for any inspection specifications.
  • Page 16: Maintaining Your Monitor

    Maintaining Your Monitor Periodically cleaning the exterior of your monitor can reduce the chance of dust being collected, blocking the ventilation holes; hence, prolonging the life of your monitor. Please refer to the instructions below for cleaning your monitor: 1. Unplug the power Unplug the LCD monitor from the wall outlet before cleaning the monitor.
  • Page 17: Fcc And Ce Radiation Norm

    FCC and CE Radiation Norm This equipment has been tested and complies with limits for Class B digital devices pursuant to Part 15 of Federal Communications Commission (FCC) rules. This equipment has been tested and complies with the limits of the European Council Directive on the approximation of the law of the member states relating to electromagnetic compatibility (89/336/EEC) according to EN 55022 Class B.
  • Page 18 Tabla de Contenidos Precauciones ..........................19 Contenidos de Paquete......................... 20 Configuración de Hardware......................21 Instalación............................21 Instalación del Driver de la pantalla Touch Screen ...............22-23 Guía de Calibración para la pantalla Touch Screen...............24-25 Emulador de Ratón ........................26 Menú de Botones de Control......................27 Modo del Menú...
  • Page 19: Precauciones

    Precauciones 1. Lea todas las instrucciones y guarde este manual para uso en el futuro. 2. Siga todas las precauciones e instrucciones de este producto. 3. No cubra o bloque los hoyos de ventilación del monitor. 4. No inserte objetos metálicos o derrame liquido en el monitor LCD por las aberturas; esto puede causar fuego, o sacudida eléctrica o dañar el producto.
  • Page 20: Contenidos De Paquete

    Contenidos de Paquete Monitor LCD TFT 15” Cable de Señal Externo Conectador de Audio: Univ15-pines D-Sub estéreo (RGB Analógico) Cable de Alimentación Cable USB Manual de Usuario Y Tornillos Y Arandelas CD del Driver Configuración de Hardware Use el monitor LCD cuidadosamente. Apague el monitor LCD y la computadora antes de instalarlo. Siga las instrucciones de instalación paso a paso.
  • Page 21: Instalación

    Instalación Nota para los Usuarios con Windows Antes de conectar su nuevo monitor LCD a su computadora, favor de asegurarse que la resolución y el promedio de refrescar están configurados apropiadamente, para que este monitor funcione adecuadamente. La resolución recomendada es de 1024 x 768. Usted puede ajustar estas configuraciones haciendo un clic con el botón derecho del ratón en el escritorio principal, seleccionando “Properties”, luego “Settings”.
  • Page 22: Instalación Del Driver De La Pantalla Touch Screen

    5. Conecte el cable USB al puerto USB en la parte de atrás del monitor. 6. Encienda su computadora y el monitor. Instalación del Driver de la pantalla Touch Screen El CD del Driver incluido con su Monitor Touch Screen es compatible con los siguientes sistema operativo: Windows 98 SE, ME, 2000, XP, y iMac.
  • Page 23 O haga clic en Start -> Run para y seleccione el CD-ROM. Seleccionando el archivo Setup.exe del CD del Driver. Haga un clic en el botón de [Next >] para continuar con la instalación. Instalando el programa. 4. La siguiente ventana le aperecerá en pantalla preguntándole que chequee la caja para instalar el conductor PS/2. Asegurese que no tenga marca en la caja.
  • Page 24: Guía De Calibración Para La Pantalla Touch Screen

    5. Seleccione la ubicación del archivo donde usted lo va instalar. Luego oprima [Next >] para continuar con la instalación. Escojiendo la ubicación del archivo. Seleccione la carpeta del programa. 6. Ahora Windows copiara los archivos del driver al disco duro. El sistema requiere que usted re-incie la computadora para completar la instalación.
  • Page 25 intermitente. Esto asegura que la utilidad pueda congregar la ubacaión esencial de dato para la calculación del tacto. Usted puede notar una línea de tiempo en la parte de abajo de la ventana, esta línea indica el tiempo transcurrido del momento que usted oprimio el símbolo de la X.
  • Page 26: Emulador De Ratón

    Examén de Dibujar (Draw Test) Esta función se utiliza para presición y chequear el funcionamiento. Dibuje líneas rectas con el extremo de un dedo para ver si la pantalla touch screen está registrando sus puntos de contacto del toque en la ubicación exacta. Si la ubicación está...
  • Page 27: Menú De Botones De Control

    Menú de Botones de Control Símbolo Función 1. Ajuste automático. 2. Mueve la barra de seleccionar hacia arriba. 1. Muestra el menú principal del OSD. 2. Mueve la barra de seleccionar hacia abajo. POWER 1. Enciende o apaga el equipo. 1.
  • Page 28: Modo Del Menú Osd

    Modo del Menú OSD - Oprima el botón de “M” para entrar al menú OSD. “A” - Seleccione la opción del menú deseado, oprimiendo el botón o “M”. “ ” - Use el botón de “ ” o para ajustar el valor de la configuración seleccionada. BRILLO Ajusta el brillo de la imagen CONTRASTE...
  • Page 29: Modos De Imagen

    Modos de Imagen Modo de Imagen Resolución Frecuencia Horizontal (KHz) Frecuencia Vertical (Hz) 640x480 31.47 59.94 640x480 37.86 72.81 640x480 37.50 75.00 800x600 35.16 56.25 800x600 37.88 60.32 800x600 48.08 72.19 800x600 46.88 75.00 720x400 31.47 70.09 1024x768 48.36 60.00 1024x768 56.48 70.07...
  • Page 30: Especificaciones

    Especificaciones Panel de LCD Tipo Panel de LCD de 15.0‘’ TFT Activa Matricial Angulo de Vista H:140° , V:130° Proporción de Contraste 450 : 1 (Típico) Brillantez 250 cd/m2 (Típico) Tiempo de Reacción 8 ms Colores de Exhibición 16.2M colores (color real) Resolución Max.
  • Page 31: Solucionando Problemas

    Solucionando Problemas Criterios de Píxel LCD Normalmente, un monitor de 17" SXGA (1280x1024) contiene alrededor de 4 millones sub-píxeles. Pueden haber hasta 8 píxeles que no tienen rendimiento en la pantalla LCD, cual solamente es un 0.0002% del total de sub-píxeles.
  • Page 32: Manteniendo Su Monitor

    Manteniendo Su Monitor Limpiando el exterior de su monitor periódicamente puede reducir la comulación de polvo, bloqueando los hoyos de ventilación; por lo tanto, extendiendo la vida de su monitor. Para limpiar su monitor, favor de leer la siguiente instrucciones. 1.
  • Page 33: Norma De Radiación Fcc Y Ce

    Norma de Radiación FCC y CE Este equipo se ha probado y es docil con los límites para los dispositivos digitales de la clase B conforme a la parte 15 de reglas federales de la Comisión de las comunicaciones (FCC). Este equipo se ha probado y es docil con los límites del Directorio del Consejero Europeo sobre la aproximación de la ley de los estados miembro de la compatibilidad electromágnetica (89/336/EEC) de acuerdo a la Clase B EN 55022.
