Specification
LBPBSHD
Model
Pick up Element
1/3" SONY Super HAD CCD II
Effective Picture Elements
NTSC:768(H)×494(V) PAL:752(H)x582(V)
(H×V)
600TV Line
Horizontal Resolution
0.001Lux
Minimum Illumination
More than 50dB
S/N Ratio
2:1 interface
Scanning System
Internal, Negative sync.
Synchronous System
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Auto Electronic Shutter
0.45
Gama Characteristic
1Vpp, 75Ω
Video Output
Auto
Auto Gain Control
DC12V(+/-10%)/150mA
Power/Current
3.7mm Taper Pinhole Lens
Lens
￠20 x 62(H)
Dimension (mm)
200
Weight (g)
-30~+60℃ RH95% MAX
Storage Temperature
-10~+45℃ RH95% MAX
Operating Temperature
Packing List
No
Name
1.
LBPBSHD
Bullet Color Camera
2.
User Guide
LBPBSHD
Franchiser：
Model
Number
1
1
LBPBSHD Color Camera
Bullet Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
