Summary of Contents for Pyle Pro PADH879
- Page 2 • Clean using a damp cloth. Make sure that no moisture contacts the drivers. You can use a hand vacuum to clean the carpet. • Do not attempt to service the unit. Refer service to a certified Pyle Pro technician.
-
Page 3: Amplifier Requirements
There is a flush mounted 35mm speaker stand adapter on the bottom side of the cabinet. Connections Your PADH series speaker has an extremely flexible connection panel. There are two Speakon jacks as well as two ¼” jacks. You can also hookup your speaker cabinet using the “Quick Connect”... - Page 4 choosing an amplifier to drive your PADH series speaker. While it is true that an amplifier with a higher power rating can damage the drivers, under- powering can be even more dangerous. When an amplifier is overdriven and starts distorting, it generates transient frequencies that are much louder than the program material.
-
Page 5: Troubleshooting
Troubleshooting No Sound: Check connections Try a different speaker cable Check levels on amplifier Confirm amplifier is getting a signal (check signal LED, or use headphone output) Intermittent Output: Check connections Try a different speaker cable Weak Bass: Check the polarity of the speaker connection. It may be reversed. Listen with headphones to confirm the amplifier is being sent a good signal. - Page 6 Typical Setup Parallel Setup...
- Page 7 Recommended Accessories ) & , - .) & " & " # $ 1 " 2 3 % & ) & " ) & , - .) & & " & 1 " 2 3 % & ) & " "...
