Visonic POWERART Installation Instructions Manual

POWERART™ POWERART™
POWERART™ POWERART™
Wireless Alarm Control Panel for Artwork Protection

TABLE OF CONTENTS

TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS
1. INTRODUCTION .......................................................... 2
2. SPECIFICATIONS ..................................................... 2
2. 1 General Data .......................................................2
2. 2 RF Section...........................................................2
2. 3 Electrical Data .....................................................2
2. 4 Communication ...................................................3
2. 5 Physical properties ..............................................3
3. INSTALLATION .......................................................... 3
3. 1 Unpacking the Equipment ...................................3
3. 2 Supplying Power to the Unit ................................3
3. 3 Programming.......................................................4
3. 4 Mounting the Bracket ..........................................4
3. 5 Wiring ..................................................................5
3. 6 Attaching the Control Panel to the Bracket .........6
3. 7 Connecting the AC Transformer..........................6
3. 8 PowerArt-Compatible Detectors..........................7
3. 9 PowerArt-Compatible Transmitters .....................7
3. 10 Mounting the RS232 Module.............................8
3. 11 Installing an Optional X-10 Siren.......................8
The PowerArt™ control panel is supplied with 3 instruction manuals:
" Installation Instructions (this manual - for your exclusive use)
" Programming Guide (for your exclusive use)
" User's Guide (for your use during installation only. Must be handed over to the master user after testing the system).
Appendices A and B to the installation instructions will help you prepare an installation plan. Please take time to fill out
the forms - your job will become much easier and confusion will be prevented. Filling out the forms will also help you
create a list of detectors and transmitters that must be obtained for the particular application. Compatible detectors and
transmitters are listed and described briefly in Paragraphs 3.8 and 3.9 of this manual.
Remember - it is advisable to power up the control panel temporarily after unpacking and program it on the work bench,
in accordance with the installation plan. Paragraph 3.3 of this manual refers you to the programming guide.
The programming flow charts in the programming guide show all options available for each parameter. Factory defaults
are marked with a dark box to their right, and other options (those that can be selected instead) are marked by clear
boxes. This method allows you to put a checkmark in the appropriate clear box whenever you deviate from the factory
defaults.
To increase the backup time provided by the Ni-Cd battery (which is 4 -6 hours), we recommend the use of 6 size AA
Ni-Mh cells with a capacity of 1600 mAh (produced by GP). Under AC failure conditions, these batteries provide up to
20-hour backup with no alarms, and up to 16 hours if an alarm occurs.
Although setting the correct time and date is one of the user tasks, we recommend that you set the time and date in the
course of programming. Access to the "User Settings" is possible through item 9 on the installer's menu (see User's
manual for exact procedure).
When you are through programming, proceed to install the system as detailed in the Installation Instructions, from
paragraph 3.4 onward.
DE5458
4. TESTING PROCEDURES .......................................... 8
5. MAINTENANCE .......................................................... 9
APPENDIX A. DETECTOR DEPLOYMENT AND
APPENDIX B. X-10 UNIT ASSIGNMENTS ................... 13
FCC STATEMENTS ....................................................... 14
DECLARATION OF CONFORMITY............................... 15
MESSAGE TO THE INSTALLER

Installation Instructions

4. 1 Preparations ....................................................... 8
4. 2 Diagnostic Test................................................... 8
4. 3 Keyfob Transmitter Test ..................................... 8
4. 4 Appliance ON/OFF Test ..................................... 9
4. 5 Emergency Transmitter Test .............................. 9
4. 6 SPD-1000 Wireless ........................................... 9
5. 1 Dismounting the Control panel ........................... 9
5. 2 Replacing the Backup Battery ............................ 9
5. 3 Fuse Replacement ........................................... 10
TRANSMITTER ASSIGNMENTS ............................. 11
A. 1 Detector Deployment Plan ............................... 11
A. 2 Keyfob Transmitter List .................................... 11
A. 3 Emergency Transmitter List ............................. 12
A. 4 SPD-1000 Wireless Detector List .................... 12
A. 5 Non-Alarm Transmitter List .............................. 13
