Klutch 17085 Owner's Manual

Cordless impact driver with 12v li- ion battery
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C O R D L E S S I M PA C T D R I V E R W I T H 1 2 V
L I - I O N B AT T E R Y
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Item# 17085

Advertisement

Table of Contents
loading

Related Manuals for Klutch 17085

Summary of Contents for Klutch 17085

  • Page 1 L I - I O N B AT T E R Y OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 17085...

  • Page 2: Intended Use

    For technical questions please call 1-800-222-5381. INTENDED USE The Klutch™ 12V 1/4in. Impact Driver delivers compact cordless power with high torque to loosen and tighten nuts and bolts for auto repair, equipment maintenance and home construction projects.

  • Page 3: Important Safety Considerations

    this product, but must be supplied by the operator. SAVE THESE INSTRUCTIONS IMPORTANT SAFETY CONSIDERATIONS 1) WORK AREA: a) Keep work area clean and well lit. Cluttered and dark areas invite accidents. b) Do not operate impact drivers in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.
  • Page 4 instructions and in the manner intended for the particular type of impact driver, taking into account the working conditions and the work to be performed. Use of the impact driver for operations different from intended could result in a hazardous situation. g) Both tools and workpieces can heat up considerably during the drilling operation.

  • Page 5: Operation

    OPERATION INSERTION AND REMOVAL OF RECHARGEABLE BATTERY After ensuring the correct orientation between the battery and the battery compartment, insert the rechargeable battery into the machine. Do not apply force when inserting the battery. Insertion can be achieved easily and without resistance. The battery must be inserted completely until the battery retention clips on the sides of the battery compartment automatically lock it into place.
  • Page 6 Up to 30 min. in cooling time may be required depending on ambient temperature and operation being performed. Overcurrent Protection Should the battery be overloaded and the maximum current draw be exceeded, the battery will temporarily stop working to protect the internal components. The battery will resume to normal operation once the excessive current draw has returned to normal safe level.

  • Page 7: Maintenance

    Inserting screw or driver bits Important! Always remove the battery before you change the screw bit to avoid unintentional starting of the machine. Pull back on the quick-release chuck, insert the screw or driver bit into the chuck and release. Make sure the bit is secure in the chuck before operating.

  • Page 8: Diagram & Parts List

    DIAGRAM & PARTS LIST Part# Description Qty. Quick Release Chuck Left/Right Rotation Switch Battery Battery Release Button On/Off Switch Integrated LED Light For replacement parts and technical questions, please call 1-800-222-5381. Page of 9...

  • Page 9: Warranty

    WARRANTY One-Year Limited Warranty WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: •...
