Summary of Contents for Audio Technica SpectraPulse mtu201
- Page 1 SpectraPulse ® Ultra Wideband Wireless Microphone System Wireless XLR Desk Stand mtu201 Set-up and Operation...
- Page 2 Please note that your SpectraPulse system operates in a frequency band in a way which ® This device complies with Part 15 of the FCC rules. may make its use subject to certain FCC and other regulatory agency restrictions and licensing requirements. No changes or modifications may be made to this equipment Operation is subject to the following conditions: except by the expressly approved responsible party for compliance.
- Page 3 Contents 3. Connect an Engineered Sound gooseneck microphone with 3-pin XLRM-type output to ® the XLRF-type input on the mtu201 XLR Desk Stand Transmitter. What’s in the box Page 4 4. Turn on the power switch on the bottom of each mtu201. The Power LED on the top of mtu201 Installation & Operation Page 4 the base will glow blue. (See Power On/Power Off, page 6.) mtu201 Controls Page 6 5. Confirm link status. If the mtu201 XLR Desk Stand Transmitter is properly linked, the Link Specifications Page 8...
- Page 4 mtu201 5. Power LED and Low-battery Warning The Power LED on the top of the desk stand transmitter glows blue to indicate the XLR Desk Stand Transmitter Controls power is on. 1. Battery Selection and Installation When battery performance is low, the Power LED will blink as a warning. When the system The mtu201 Wireless XLR Desk Stand Transmitter operates on two AA batteries is linked, a bottom orange LED on the corresponding aci707 channel will illuminate to (standard alkaline or rechargeable).
-
Page 5: Specifications
Specifications Input connector XLR-female low impedance intended for use with Audio-Technica gooseneck microphone of Engineered Sound series. Bias voltage to The mtu201 delivers 11.5V DC to the XLR connector in order to mic feed power any of the A-T Engineered Sound series microphones. Battery type Two 1.5 volt AA alkaline batteries are included. Rechargeable SANYO brand NiMH AA batteries are recommended; they are included with the available cei007 Charging/Encryption Interface. Battery life Approximately 9 hours depending on battery type and use Current 180 mA at 3V DC Consumption Average RF power 40 nanowatts Weight 612 g (1.35 lb.) Dimensions 82.6 mm (3.25") W x 131 mm (5.19") D x 63.0 mm (2.48") H Optional AES level 3, 128 bit Encryption Audio-Technica U.S., Inc.
