B
ASE VIEW
# Icon Item
1 Battery bay
2 Battery release latch
Memory
compartment
3
Hard disk bay
Ventilation and
4
cooling fan
24
1
2
3
Description
Houses the computer's battery pack.
Releases the battery for removal. Insert a
suitable tool and slide to release.
Houses the computer's main memory.
Houses the computer's hard disk (secured
with screws).
Allows the computer to stay cool.
− Do not cover or obstruct the openings.
4
