IQAir GC Series Getting Started

Getting Started with Your IQAir® GC™ Series
Thank you for choosing IQAir for your air cleaning needs. These instructions will assist you in getting started with
your IQAir system in a matter of minutes. Simply follow the instructions below. To access some of the more advanced
features of your IQAir system, such as the timer, please refer to the user manual. We recommend that you familiarize
yourself with the safety instructions in the user manual before first use.
Your IQAir system is supplied with the following items:
User manual
•
User DVD
•
Certificate of performance (individually numbered and hand-signed)
•
Technical support and warranty registration card
•
IQAir referral program card
•
Power cord
•
Remote control (incl. battery)
•
Set of 4 casters
•
Set of 4 post-filter sleeves (inside the air cleaner in the F2 chamber)
•
Set of 4 cartridges (delivered in a separate box)
•
Setting Up Your IQAir System
1
A) Unpacking
To unpack your IQAir system, open the top of the box and remove the top foam piece. Lay the box on its side and
pull the air cleaner out by its top handle. Place the system in its upright position and remove all packaging
materials. All related accessories are supplied in a separate top foam piece contained in the box. Cartridges are
supplied and shipped in a separate box (see D below).
B) Installing the casters
Installing the casters is not necessary to operate the system; however, it may facilitate moving the air cleaner
from room to room. Please refer to the user manual for caster fitting and removing instructions.
C) Choosing a suitable location
Your IQAir system should be placed in the room where air cleaning is needed most. It should be located ideally
one foot (30 cm) away from the nearest vertical surface to allow for maximum air circulation.
D) Installing the cartridges (set of 4)
Your cartridges have come in a separate box in order to avoid shipping damage to the system. Remove the
plastic bag from each cartridge. Use a damp cloth if necessary to remove carbon dust. You may want to wear
rubber or plastic gloves and protect clothing and other surfaces while handling. To install the cartridges, open
the system and remove the diffuser and top two frames. Pull one filter sleeve over each cartridge until it is
completely covered. Insert each cartridge into the base plate by turning it clockwise. Replace frames with the
cartridges, the other frame, and the diffuser. Close the system. For more details, refer to the user manual or the
leaflet supplied with the cartridges.
E) Connecting to the power supply
Plug the connector-end of the power cord into the base of the system. Locate a suitable wall socket and
connect the power cord. Your IQAir system is now in standby mode ready to be switched on.
Using the Electronic Control Panel
2
A) Switching your IQAir system on and off
To switch the system on or off, simply press the POWER button, located on the far left of the control
panel. The system is intended to run continuously when users are present. Operating the system 24
hours per day will not harm the system.
B) Regulating the fan speed
To select the desired fan speed, simply press the ARROW button on the control panel. When the top
speed has been reached, the display will start again at the lowest fan speed.
(over)
