In-Ground Basketball System
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
• 3 People
• Carpenter's Level
• 15' Tape Measure
• Shovel & Post Hole
Digger
• Wood Board (scrap)
• Masking Tape
• Marker
Internet Address: http://www.hydra-rib.com
REQUIRED TOOLS AND MATERIALS:
• (2) Stepladders 8 ft. (2.4 m)
• Safety Goggles
• (2 each) Wrenches and/or Socket Wrenches and
Sockets (Deep-Well Sockets are Recommended).
3/8"
1/2"
9/16"
3/4"
3/8"
1/2"
9/16"
3/4"
1
A Huffy Sports Company
Write Model Number
From Box Here:
•
• Container to Mix
15/16"
• Drill
• Optional: Large &
Small Adjustable
Wrenches
15/16"
10/05
P/N 21144607
Advertisement
Table of Contents
Related Manuals for HYDRA-RIB In-Ground Basketball System
Summary of Contents for HYDRA-RIB In-Ground Basketball System
-
Page 1: Owners Manual
A Huffy Sports Company In-Ground Basketball System Owners Manual Customer Service Center • N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A. Write Model Number From Box Here: REQUIRED TOOLS AND MATERIALS: WARNING! • 3 People • (2) Stepladders 8 ft. (2.4 m) •... -
Page 2: Safety Instructions
IMPORTANT! WRITE MODEL NUMBER FROM BOX ONTO PAGE 1 OF THIS OWNERS MANUAL SAFETY INSTRUCTIONS WARNING FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY RESULT IN SERIOUS INJURY, PROPERTY DAMAGE AND WILL VOID WARRANTY. Owner must ensure that all players know and follow these rules for safe operation of the system. - Page 3 Ensure ground is level with playing surface, then dig pole hole. PLAYING WARNING SURFACE CONTACT UTILITIES BEFORE DIGGING. 24" (61 cm) AVERTISSEMENT ADVERTENCIA 36" (91.4 cm) AVVERTENZA GROUND SURFACE ATENÇÃO !WARNUNG XG02.EPS WAARSCHUWING HR83001. 2” Install nut (2) to J-bolt (1) 2111560 (5.08 cm) as shown.
- Page 4 Fill hole with concrete. Tamp down concrete to release air pockets and build drainage hill. Insert J-bolts (1) from mounting plate (3) into cement as shown. Move assembly around to HR83005.EPS release any air pockets in cement, then rest 211560 mounting plate on cement drainage hill.
- Page 5 WARNING THREE PERSON MINIMUM REQUIRED AVERTISSEMENT FOR THIS PROCEDURE. FOLLOWING RECOMMENDATION MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY ADVERTENCIA DAMAGE. Upright pole (5). Assemble lower pole flange onto AVVERTENZA protruding J-bolts (1) as shown. The flange will then rest on the nuts (2) from Step 2. Install pole cap (6).
- Page 6 Insert caps (8) into end of each support arm (9 & 10) as shown. Tap firmly in position. WARNING Apply logo label (11) to lower support arms (10) THREE PERSON MINIMUM REQUIRED as shown. Repeat for opposite side. AVERTISSEMENT THIS PROCEDURE.
- Page 7 Secure H-frame board assembly to support arms (9 & 10). WARNING IMPORTANT! At this time, completely THREE PERSON MINIMUM REQUIRED tighten upper and lower AVERTISSEMENT THIS PROCEDURE. support arms. FOLLOWING RECOMMENDATION MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY DAMAGE. ADVERTENCIA IMPORTANT! Do not over tighten.
-
Page 8: Rear View
Secure jack brackets (17 & 18) to lower holes in pole as shown. REAR VIEW IMPORTANT! HOLD HERE Position U-joint of crank jack (20) as shown. Where tubes on crank jack join, hold steady to keep both tubes from rotating. Rotate handle clockwise on crank jack to the fully extended position. - Page 9 WARNING THREE PERSON MINIMUM REQUIRED AVERTISSEMENT THIS PROCEDURE. FOLLOWING RECOMMENDATION MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY DAMAGE. ADVERTENCIA AVVERTENZA Install crank jack (20) U-joint to lower set of support arms (10) as shown. ATENÇÃO !WARNUNG WAARSCHUWING ADVARSEL ADVARSEL VARNING WARNNG.EPS REAR VIEW...
- Page 10 WARNING THREE PERSON MINIMUM REQUIRED AVERTISSEMENT THIS PROCEDURE. FOLLOWING RECOMMENDATION MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY DAMAGE. ADVERTENCIA Rotate jack handle clockwise to raise H-frame (13) to AVVERTENZA approximately 7’ (2.1 m) from ground. Secure crank jack (20) to jack brackets (17 &18) as shown. ATENÇÃO NOTE: Some adjustment will be necessary to align the lower crank jack bushing to jack brackets (17 &...
- Page 11 Attach rim assembly and foam pad (22). For rim assembly see instructions included with rim. WARNING TWO PERSON MINIMUM REQUIRED FOR THIS PROCEDURE. AVERTISSEMENT FOLLOWING RECOMMENDATION MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY ADVERTENCIA DAMAGE. AVVERTENZA ATENÇÃO !WARNUNG Rim Assembly WAARSCHUWING ADVARSEL ADVARSEL...
- Page 12 Check leveling at this time. Pole should be level in all directions. NOTE: If adjustment is necessary, adjust system by rotating the nuts (2) between mounting plate (3) and pole flange. (Refered to in Step 6.) After system is leveled, completely tighten nuts (7) above pole flange.
- Page 13 ADDING HEIGHT INDICATORS Add height adjustment decal (24) A. LOWER BACKBOARD UNTIL RIM IS 7 FEET OFF THE GROUND. B. APPLY THIN WHITE STRIP TO BOTTOM EDGE OF OUTER CRANK TUBE AS SHOWN. C. APPLY LARGE DECAL TO BACK OF POLE SO THAT 7 FOOT MARK ON LARGE DECAL IS LINED UP WITH THIN WHITE STRIP.
-
Page 14: Height Adjustment
Secure pole pad (25) as shown. NOTE: Pole pad may NOT be included in this model. MHE19.EPS 206239 Height Adjustment Rotate crank handle to raise and lower backboard. NOTE: If height adjustment is difficult to operate, you may have over tightened the areas indicated. Refer to Step 10 and Step 14. -
Page 15: Hardware Identifier
PARTS LIST Item Qty. Part No. Description Item Qty. Part No. Description 200573 J-Bolt, 5/8”-11” 214057 Nut, Hex, Black Zinc, 5/8”-11” 214050 Bolt, Hex, Black Zinc, 1/2”-13 x 7.25” 920880 Mounting Plate 213627 Bolt, Hex Head, Black Zinc, 1/2”-13 x 4” 214046 Washer, Flat, Black Zinc, 901656...
