Power Wheels Super Talk! BARBIE Sun Jammer Owner's Manual With Assembly Instructions

Power Wheels Super Talk! BARBIE Sun Jammer Owner's Manual With Assembly Instructions

Model 76960
Hide thumbs
Table of Contents

Advertisement

Quick Links

TM
Product features may vary from the picture above.
CAUTION
ELECTRIC TOY: Not recommended for children under 3 years of age.
As with all electric products, precautions should be observed during
handling and use to prevent electric shock.
Super Talk!
™
BARBIE
™
Sun Jammer
™
4x4
Owner's Manual
with Assembly Instructions
Please read this manual and save it with your original sales receipt.
For Model 76960
Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver, Hammer, Safety Scissors.
Use only with Power Wheels
Type H (9.5 Amp/hr.) Batteries, Power Wheels
30 Amp Fuses and
®
®
Power Wheels
Type H 12 Volt Charger (all included).
®
Requires three "AAA" (LR03) alkaline batteries (not included) for the phone.
