Eurotech VoIP2 ALL Series User Manual

Sim server up to 512 sim cards
Hide thumbs Also See for VoIP2 ALL Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
VOIP²ALL SERIES
SIM Server User Guide
Up to 512 SIM cards
Connecting to the Cellular
with Remote SIM
Version 5.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VoIP2 ALL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eurotech VoIP2 ALL Series

Summary of Contents for Eurotech VoIP2 ALL Series

  • Page 1 VOIP²ALL SERIES SIM Server User Guide Up to 512 SIM cards Connecting to the Cellular with Remote SIM Version 5.6...

  • Page 2: Table Of Contents

    Contents CONTENTS INTRODUCTION TO THE VOIP²ALL SIM SERVER ..............3 1.1. The VoIP²ALL Solution Overview ................3 1.2. About this Manual ....................4 1.3. Terminology ......................4 INSTALLATION AND SETUP ....................5 2.1. Installation overview ....................5 2.2. Check Your Package Items ..................5 2.3.

  • Page 3: Introduction To The Voip²All Sim Server

    VoIP²ALL SIM Server 1. INTRODUCTION TO THE VOIP²ALL SIM SERVER Eurotech Communication team is glad you have chosen to use the Eurotech’s VoIP2ALL Gateway for your needs. We will do our best, to make your installation efforts as well as day-to-day configuration and monitoring tasks, to be as pleasant as possible.

  • Page 4: About This Manual

    Introduction To the VoIP²ALL SIM Server 1.2. ABOUT THIS MANUAL This manual is for use with the VoIP²ALL SIM Server. Our VoIP stand-alone unit product range is:  2ch- For SOHO and SMB’S  4ch- corporate  8ch- enterprise  16ch-24-32ch -Enterprise and heavy duty traffic All of the above units are compatible for use in our SIM Server System.

  • Page 5: Installation And Setup

    Installation and Setup 2. INSTALLATION AND SETUP This section will guide you through the installation and setup process, including basic configuration and a system test to ensure that all components are working properly. These steps are MANDATORY to run the VoIP²ALL, unless otherwise indicated. 2.1.

  • Page 6: Sim Installation

    Installation and Setup 3U SIM Server - The SIM Server cards are set from card 1 to card 8 from left to right, where card 1 is the closest to the master of the SIM Server. (* future expansion to 16 cards 512 SIMs) 1U SIM Server - The SIM Server cards are set from card 1 to card 6 from bottom left to top right, where card 1 is the closes to the master of the SIM Server.

  • Page 7: Connecting The Cables

    Installation and Setup 2.3.3. CONNECTING THE CABLES Connect the following:  LAN cable - The LAN cable is used to connect the system to the internet network, connect the LAN line to the left RJ-45 marked LAN (the right RJ-45 that marked LAN are not in use). ...
  • Page 8 Installation and Setup  To install the VoIP²ALL Management Software on a MS-Windows PC : 1) Insert the VoIP²ALL Management installation CD into the CD drive of the PC. 2) In Windows Explorer, navigate to the installation CD drive 3) Double click to install the Management Application.

  • Page 9: Operating The Sim Server

    Operating the SIM Server 3. OPERATING THE SIM SERVER Overview At the core of every VoIP²ALL unit there is a DSP processor. The processor runs on a Linux operating system. Run the v2g_2 program which operate the unit and a sim_server program which operate the internal SIM Server.

  • Page 10: Replacing Sims

    Operating the SIM Server 2) Click on the toolbar. The Selected Connection window will open. 3) Enter in the Host Address the IP Address of the SIM Server (The default IP address is 10.16.2.245). 4) Enter in the Port Number the connection to GUI port of the SIM Server (The default port is 2007). 5) Enter in the 'Password' the password of the VoIP²ALL gateway (The default password is admin).

  • Page 11: Appendix A: Com Port

    Appendix A: Com Port 4. APPENDIX A: COM PORT The Com Port connection, gives you direct access to the Linux based operating system files of the DSP. 1) Connect the Com Cable from the gateway to the PC RS232 Com Port. 2) Connect the Hyper Terminal press Disconnect then Properties.
  • Page 12 Appendix A: Com Port 8) When restarting the gateway you will see the initialization process, wait until it is finished. 9) Press the Enter button. On screen you will see #. 10) To see the IP settings write the command ifconfig and press Enter. On screen you will: The IP Address of the gateway is marked in a red circle.

This manual is also suitable for:

Voip2 all 3uVoip2 all 1uVoip2 all 192 1u
