Page 1: Important Safety
Spa Owner’s Manual www.dreammakerspas.com This Manual Contains IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS “SAVE THESE INSTRUCTIONS”... - Page 2 We appreciate your business and our sincere desire is that you receive years of pleasure and therapy from your Dreammaker Spa. Please call your local Dreammaker Spa Dealer if you have any questions or problems. If they are unavailable, please feel free to call the Dreammaker Spas Customer Service Group at:...
- Page 3 LOCATING THE SERIAL NUMBER There is a black plate located to the right or left of the access door SERIAL #...
-
Page 4: Table Of Contents
Jet Wrench ....................................17 Glossary of Terms ................................... 18 An important WARNING sign is packed with your Dream Maker Spa. This sign must be posted in a prominent place in close proximity to the spa installation site immediately upon completion of spa installation. -
Page 5: Important Spa Safety Instructions
When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: 1. READ AND FOLLOW ALL INSTRUCTIONS 7. Danger Risk of Injury. The suction fittings in this spa are sized to match the specific 2. Warning water flow created by the pump. Should the need arise to replace the suction To reduce the risk of injury, do not permit children to use this product unless fittings or the pump, be sure that the flow rates are compatible. -
Page 6: Important Safety Precautions
DO NOT : Do not use electrical appliances in or around your spa. Do not use glass or other breakable items in or around your spa. Do not remove spa cabinet panels and attempt to make repairs. Do not attempt electrical repairs. Retain a certified licensed electrician. -
Page 7: Selecting A Location
1. Check to be sure that the drain valve is closed and that the drain safety cap is securely in place. ( See page 5 and 9 ) 2. Remove filter cartridge and place garden hose end through opening (inside filter area), fill the spa with cold (never warm or hot) water 6” to 8” (150 to 200 mm) below the top edge of the spa. - Page 8 X-SPA X-CAL...
-
Page 9: Locating Electrical Plug & Drain X-Spa And X-Cal Series
LOCATION OF ELECTRICAL CORD & DRAIN The spa equipment requires a 15 amp outlet, dedicated to the spa. The use of any extension cord will void your warranty. Carefully read all of the safety requirements before plugging in the spa. -
Page 10: Jets & Air Adjustment For X-Spa And X-Cal Series
SYSTEM OPERATION X-SPA and X-CAL The spa is equipped with massage jets, an anti-vortex main drain and an automatic skim filter. ADJUSTING MASSAGE JETS The massage jets may be adjusted for both volume and direction. To adjust the jet for direction simply rotate the jet’s eyeball fitting in the direction desired. - Page 11 ECLIPSE TRIDENT / FANTASY GALAXY / ODYSSEY...
- Page 12 X-100 / ESCAPE / X-TREME X-400 X-500...
-
Page 13: Locating Electrical Plug & Drain
Figure 2 Figure 3 The spa drain valve assembly consists of a garden hose connector with a twist on/off valve and a safety drain cap. It is located outside at the bottom of the spa. EACH TIME BEFORE FILLING THE SPA Drain Every Three Months 1. -
Page 14: System Operation
Light Open sensor. Call your dealer or service center. Press the pad to turn the spa light on and off. If left on, the light will automatically turn off after 4 hours. Spa Water Maintenance This function enables you to program the amount of water filtration time. -
Page 15: Jets & Air Adjustment
SYSTEM OPERATION CONTINUED The spa is equipped with massage jets, two anti-vortex main drains and an automatic skim filter. ADJUSTING MASSAGE JETS The massage jets may be adjusted for both volume and direction. To adjust the jet for direction simply rotate the jet’s eyeball fitting in the direction desired. -
Page 16: Spa Water Chemistry
SPA OPERATION / WATER CHEMISTRY Spa water chemistry (or water balance) affects the safety of your equipment as well as the appearance of your spa water. Water balance has five factors: pH, total alkalinity, calcium hardness, temperature and total dissolved solids. pH is the most critical but total alkalinity and calcium hardness must also be watched closely. - Page 17 3. Clean filter and cartridge periodically according to manufacturer’s instructions. 4. Keep the spa covered when not in use to reduce the loss of heat and to keep our leaves, dirt, and other foreign materials from settling in the water.
-
Page 18: Freeze Protection
FREEZE PROTECTION DO NOT ALLOW THE SPA TO FREEZE If the spa is to be stored or transported in temperatures 32°F (0°C) or lower, it is critical that the unit be fully winterized. 1. The spa itself must be completely emptied. -
Page 19: Most Frequently Asked Questions
3. Why is my spa hotter than it is set for? If your spa is set for 101 degrees but it reads 103 degrees most likely your filter cycle is set too high. Adjust your filter cycle down to the next lower setting or F0. -
Page 20: Troubleshooting Guide
AUSE ACTION ....... Ensure that valve is fully open. See page 4 or 8. ACTION ....... Have a licensed electrician check the voltage to spa. #2 ..Dirty filter or suction drain cover grate. #2# ..Control box fuse blown. -
Page 21: Tool Instructions And Recommended Use
2. Insert the long part of the jet wrench and turn 1. Insert a flat screwdriver between the jet face and counter clock wise until there is no tension. the spa shell. Twist the screwdriver to pop the jet face. 3. Remove jet wrench and jet internal nozzle assy. -
Page 22: Glossary Of Terms
Stands for “Potential for Hydrogen” This is the term used to describe the acid (low pH) or alkalinity (high pH) condition of the water. The ideal pH for spa water is 7.5. SKIMMER The skimmer removes surface debris to the filter. The water level in the spa should be kept at the proper range for optimum skimmer operation. SUCTION DRAIN The fitting set into the footwell that drains water from the spa. - Page 23 MAINTENANCE NOTES...
-
Page 24: Warranty Registration
(check all that apply) Display ❏ Advertising ❏ Product Knowledge ❏ Referral ❏ Price ❏ Why did you buy the spa? (check all that apply) Recreation ❏ Health/Therapy ❏ Home Improvement ❏ Why did you choose this spa? (check all that apply) Quality ❏... - Page 26 000781 (07/07)
Need help?
Do you have a question about the Spa and is the answer not in the manual?
Questions and answers
My 400 series will not power up? Checked the two fuses.. they are fine. The control on top of hot tub doesn't work... nothing works?
If a Dream Maker Spas 400 series hot tub will not power up and the control does not work, possible issues include:
- No power or improper voltage to the spa control
- Control box fuse blown
- Faulty top control panel
Recommended action: Have a licensed electrician check the voltage to the spa or call the dealer for further assistance.
This answer is automatically generated
Will the hot tub (400) come on if it only has half the water in it,right below jets?
No, the Dream Maker Spas hot tub will not operate properly with only half the water level, just below the jets. The spa requires the water level to be within the proper range for optimal skimmer and suction drain operation. Low water levels can cause improper flow, damage the pump, or trigger safety shutoffs.
This answer is automatically generated
How to move spa x-400 from one garden to another?
To move a Dream Maker Spas X-400 from one garden to another, follow these general steps:
1. Turn off power: Unplug the electrical power cord and ensure no power is supplied during the move.
2. Drain the spa:
- Open the access panel.
- Pull out the drain pipe.
- Ensure the shut-off valve is closed.
- Remove the safety cap.
- Attach a garden hose to the drain pipe.
- Place the hose end in a suitable drain area.
- Open the shut-off valve and let the spa drain completely.
3. Prepare for transport:
- Once drained, disconnect any remaining hoses or accessories.
- Ensure the power cord is fully pulled out of its compartment.
- Secure all removable parts and close access panels.
4. Move the spa:
- Use proper lifting equipment or multiple people to lift and transport the spa carefully.
- Avoid tilting or dragging the unit to prevent damage.
5. Reinstall in new location:
- Place the spa on a stable, level surface with proper clearances.
- Refill with water.
- Reconnect power only after the spa is filled.
Make sure to follow safety instructions and local regulations during the move.
This answer is automatically generated
Do they have a service manual on line?
What type of cartridge do I need for a 2007 or 2006 eclipse spa
