- Page 1 User’s Manual Digital Media Converter Package Part #: DL-HDCAT-WP...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of Contents Welcome and Safety Notes Product Description and General Specifications Environmental Reliability Specifications Features Installation Mechanical Specifications Technical Specifications Warranty Information 1-10 Troubleshooting and Customer Service Information Digital Media Converter Package Part #: DL-HDCAT-WP... -
Page 3: Welcome And Safety Notes
Contents: Each DigitaLinx™ Digital Media Converter package contains the following items: 1 each DL-HDCAT-WP Digital Media Converter Set (TX and RX unit) 1 each 5 VDC Power Supply (UL) and C(UL) listed Class 2 C(UL)US 1 each Users Manual Safety Precautions: 1.) Please read all product manuals and safety notes prior to operating... -
Page 4: Product Description And General Specifications
Product Description and General Specifications This DigitaLinx™ Digital Media Converter is an externally powered digital HDMI and DVI Media Converter system to send HDMI and DVI over standard Category Cable, unshielded or shielded. The unit uses an included 5 VDC power source. The device is compliant with DVI 1.0 and supports HDMI 1.3 signals. -
Page 5: Environmental Reliability Specifications
Environmental Reliability Specifications The DigitaLinx™ Digital Media Converter recommended environmental operating limits are a temperature range from 10°C to 40°C, non-condensing humidity levels from 10-80% and an altitude ceiling of 3,000 meters (9,840 feet). Environmental limits for transportation are established as a temperature range of -25°C to 60°C, non-condensing humidity levels from 5-95%, and an altitude ceiling... -
Page 6: Features
HDMI connector and protect it from lateral, horizontal and vertical pulling. This ensures the HDMI cable remains secure in the receptacle. cable remains secure in the receptacle. Digital Media Converter Package Part #: DL-HDCAT-WP... -
Page 7: Installation
1.) Ensure the digital video/audio source and display is turned off. 2.) Connect the digital video/audio source to the input port of the DigitaLinx™ Digital Media Converter. 3.) Connect the digital display to the output port of the DigitaLinx™ Digital Media Converter. 4.) Power up the DigitaLinx™ Digital Media Converter. -
Page 8: Mechanical Specifications
Mechanical Specifications Page 1-6 Dimensions: Mechanical Specifications DL-HDCAT-WP: HxWxD 114.50mm x70.5mm x70.4mm (Unit drawing is showing the cable support bracket mounted) Dimensions: DL-HDCAT-WP: HxWxD 114.50mm x70.5mm x70.4mm (Unit drawing is showing the cable support bracket mounted) Front View Side View... - Page 9 TMDS Data 1 - TMDS Data 0 + TMDS Data 0 shield TMDS Data 0 - TMDS Clock + TMDS Clock shield TMDS Clock - RESERVED DDC DATA DDC/CEC GROUND +5VDC POWER HOT PLUG DETECT Digital Media Converter Package Part #: DL-HDCAT-WP...
- Page 10 Warranty Information 1 (One) Year Warranty Liberty Wire & Cable warrants this DigitaLinx™ Digital Media Converter to be free from defects in workmanship and materials, under normal use and service, for a period of one (1) year from the date of purchase from Liberty Wire & Cable or its authorized resellers.
-
Page 11: Troubleshooting
Troubleshooting The DigitaLinx™ Digital Media Converter is designed for years of trouble free service, please reference the troubleshooting chart below if experiencing issues with the device. Symptom Solution TX Unit RX unit Status Solution Green Light on Green light on... - Page 12 © 2008 Liberty Wire & Cable. All Rights Reserved. Liberty Wire & Cable 11675 Ridgeline Drive Colorado Springs, CO 80921 800-530-8998 www.libertycable.com...
