CONSTRUCTION
!
Indicates Warning,
Danger, and Caution
!
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUC-
TIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH,
SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE
FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION,
CARBON MONOXIDE POISONING, AND/OR ELECTRICAL
SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE
INSTRUCTIONS SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH
AS AN INSTRUCTIONS MANUAL, LABELS, ETC. CONTACT THE
MANUFACTURER.
OWNERS MANUAL
PROPANE
HEATER
Model HP35
Read all Safety, Operating,
and Maintenance
Instructions
Man Reading Icon
HSYMBOL2
®
FIRST EDITION
PART NO. 18994
Printed In U.S.A.
Price $1.00
Advertisement
Table of Contents
Related Manuals for Homelite HP35
Summary of Contents for Homelite HP35
- Page 1 INSTRUCTIONS SHOULD USE OR SERVICE THIS HEATER. IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS MANUAL, LABELS, ETC. CONTACT THE MANUFACTURER. PROPANE HEATER Model HP35 Man Reading Icon HSYMBOL2 Read all Safety, Operating, and Maintenance Instructions ®...
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION SECTION Safety Information ... 2 Product Identification ... 4 Unpacking ... 4 Theory of Operation ... 5 Propane Supply ... 5 Installation ... 6 Ventilation ... 7 Operation ... 7 Storage ... 9 Maintenance ... 9 Troubleshooting ... 10 Service Procedures ... -
Page 3: Safety Warnings
SAFETY INFORMATION Continued 099597 WARNINGS Propane Gas: Propane gas is odorless. An odor-making agent is added to propane gas. The odor helps you detect a propane gas leak. However, the odor added to propane gas may fade. Propane gas may be present even though no odor exists. Make certain you read and understand all warnings. -
Page 4: Product Identification
PRODUCT IDENTIFICATION UNPACKING Hot Air Outlet (Front) Heater Base Piezo Ignitor Button Automatic Control Valve Button Hose /Regulator Assembly Figure 1 - 35,000 BTU/Hr Model 1. Remove all packing items applied to heater for shipment. Keep plastic cover caps (attached to inlet connector and hose/regulator assembly) for storage. 2. -
Page 5: Theory Of Operation
THEORY OF OPERATION Clean Heated Air Out (Front) PROPANE SUPPLY 099597 The Fuel System: The hose/regulator assembly attaches to the propane gas supply. This provides fuel to the heater. The Air System: The motor turns the fan. The fan pushes air into and around the combustion chamber. -
Page 6: Installation
INSTALLATION Review and understand the warnings in the Safety Informa- tion Section, pages 2 and 3. They are needed to safely operate this heater. Follow all local codes when using this heater. Test all gas piping and connections for leaks after installa- tion or servicing. -
Page 7: Ventilation
VENTILATION OPERATION 099597 4. Open propane supply valve on propane tank(s) slowly. Note: If not opened slowly, excess-flow check valve on propane tank may stop gas flow. If this happens, close propane supply valve and open again slowly. 5. Check all connections for leaks. Apply mixture of liquid soap and water to gas joints. - Page 8 OPERATION Continued 5. Open propane supply valve on propane tank(s) slowly. Note: If not opened slowly, excess-flow check valve on propane tank may stop gas flow. If this happens, close propane supply valve and open again slowly. Be sure motor and fan are running before pushing in auto- matic control valve button.
-
Page 9: Storage
STORAGE MAINTENANCE 099597 Disconnect heater from propane supply tank(s). 1. Store propane tank(s) in safe manner. See Chapter 5 of Standard for Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 and/or CAN/CGA B149.2. Follow all local codes. Always store propane tanks outdoors. 2. -
Page 10: Troubleshooting
TROUBLE- SHOOTING Never service heater while it is plugged in, connected to propane supply, operating, or hot. Severe burns and electrical shock can occur. OBSERVED FAULT POSSIBLE CAUSE Fan does not turn No electrical power when heater is to heater plugged in. -
Page 11: Service Procedures
SERVICE PROCEDURES Electrical System The entire electrical system for this heater is contained within the motor. If any part of the electrical system is damaged, you must replace motor. Motor 1. Remove three screws that attach fan guard to heater shell. - Page 12 1. Remove three screws that attach fan guard to heater shell. 2. Remove motor and fan guard from heater shell (see Figure 10). 3. Use pliers to remove the fan nut from front of motor shaft (see Figure 11). 4a. If replacing fan, remove old fan and discard.
- Page 13 Ignitor 1. Remove motor and fan guard from heater (see Motor, page 11, steps 1 and 2. Remove black ignitor wire from piezo ignitor. Access ignitor wire through underside of heater base (see Figure 13). Push wire up through bushing in heater shell.
-
Page 14: Illustrated Parts List
ILLUSTRATED PARTS BREAKDOWN HP35 HEATER EXPLODED VIEW Rubber Washer Motor Motor Assembly 26 18 099597... -
Page 15: Parts List
PARTS LIST KEY PART 099597 DESCRIPTION 04754-01 Inner Shell (Combustion Chamber) 00529-10 Hex Tap Screw, #10-16 x 3/8" 04754-02 Outer Shell 00529-44 Handle 04754-03 Hex Tap Shoulder Screw 00529-12 Hex Tap Screw, #10-16 x 3/4" 04754-04 Hex Tap Screw, #12-14 x 1/2" 03327-31 Thermocouple Clip 04754-05... -
Page 16: Specifications
SPECIFICATIONS Output Rating (BTU/Hr) Fuel Fuel Consumption Gallons/Hour Pounds/Hour Supply Pressure To Regulator Minimum (for purposes of input adjustment) Maximum Regulator Outlet Pressure Manifold Pressure Hot Air Output (CFM Approx) Motor Electric Input Amperage Ignition Weight (Pounds) Heater Shipping Size - L x W x H (Inches) Heater Temperature Range for Heater Operation * When running heater in temperatures above 85°... - Page 17 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ __________________________________________________ 099597...
- Page 18 _______________________________________________________________ NOTES _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ 099597...
- Page 19 _______________________________________________________________ NOTES _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ 099597...
-
Page 20: Customer Assistance
FOR THE LOCATION OF YOUR NEAREST HOMELITE SERVICING DEALER IN THE UNITED STATES, PUERTO RICO, AND THE VIRGIN ISLANDS NOTE: DEALER INFORMATION, TECHNICAL ADVICE, AND PRODUCT INFORMATION CAN BE OBTAINED AT THIS NUMBER. OVERSEAS OFFICES NETHERLANDS HOMELITE ATLANTIC (HDQS. — Europe, Africa and Middle East)
