CONSTRUCTION
!
Indicates Warning,
Danger, and Caution
!
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUC-
TIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH,
SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE
FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION,
CARBON MONOXIDE POISONING, AND/OR ELECTRICAL
SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE
INSTRUCTIONS SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH
AS AN INSTRUCTIONS MANUAL, LABELS, ETC. CONTACT THE
MANUFACTURER.
OWNERS MANUAL
PROPANE
HEATER
Model HP155A
UT65052-A
Read all Safety, Operating,
and Maintenance
Instructions
Man Reading Icon
HSYMBOL2
®
SECOND EDITION
PART NO. 18584-A
Printed In U.S.A.
Price $1.00
Advertisement
Table of Contents
Related Manuals for Homelite HP155A
Summary of Contents for Homelite HP155A
- Page 1 INSTRUCTIONS SHOULD USE OR SERVICE THIS HEATER. IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS MANUAL, LABELS, ETC. CONTACT THE MANUFACTURER. PROPANE HEATER Model HP155A UT65052-A Man Reading Icon HSYMBOL2 Read all Safety, Operating, and Maintenance Instructions ®...
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION SECTION Safety Information ... 2 Product Identification ... 4 Unpacking ... 4 Theory of Operation ... 5 Propane Supply ... 6 Installation ... 6 Ventilation ... 7 Operation ... 8 Storage ... 9 Maintenance ... 9 Preventative Maintenance Schedule ... 9 Service Procedures ... -
Page 3: Safety Warnings
SAFETY INFORMATION Continued 101568 WARNINGS Propane Gas: Propane gas is odorless. An odor-making agent is added to propane gas. The odor helps you detect a propane gas leak. However, the odor added to propane gas may fade. Propane gas may be present even though no odor exists. Make certain you read and understand all warnings. -
Page 4: Product Identification
Inlet Connector Hose /Regulator Assembly Figure 1 - HP155A 1. Remove all packing items applied to heater for shipment. Keep plastic cover caps (attached to inlet connector and hose/regulator assembly) for storage. 2. Remove all items from carton. 3. Check all items for shipping damage. If heater is damaged, promptly inform dealer where you bought heater. -
Page 5: Theory Of Operation
THEORY OF OPERATION Clean Heated Air Out (Front) 101568 The Fuel System: The hose/regulator assembly attaches to the propane gas supply. The propane gas moves through the solenoid valve and out the nozzle. The Air System: The motor turns the fan. The fan pushes air into and around the combustion chamber. -
Page 6: Propane Supply
PROPANE SUPPLY INSTALLATION Propane gas and propane tank(s) are to be furnished by the user. Use this heater only with a propane vapor withdrawal supply system. See Chapter 5 of the Standard for Storage and Handling of Liquefied Petroleum Gas, ANSI/ NFPA 58 and/or CAN/CGA B149.2. -
Page 7: Ventilation
VENTILATION 101568 3. Connect hose to inlet connector. Tighten firmly using a wrench. IMPORTANT: Extra hose or piping may be used if needed. Install extra hose or piping between hose/regulator assembly and propane tank. You must use the regulator supplied with heater. Generic LP 155 Figure 4 - Hose and Inlet Connector 4. -
Page 8: Operation
OPERATION Review and understand the warnings in the Safety Information Section, pages 2 and 3. They are needed to safely operate this heater. Follow all local codes when using this heater. To Start Heater 1. Follow all installation, ventilation and safety information. 2. -
Page 9: Storage
STORAGE MAINTENANCE PREVENTATIVE MAINTENANCE SCHEDULE 101568 Disconnect heater from propane supply tank(s). 1. Store propane tank(s) in safe manner. See Chapter 5 of Standard for Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 and/or CAN/ CGA B149.2. Follow all local codes. 2. -
Page 10: Service Procedures
SERVICE PROCEDURES Upper Shell Removal 1. Remove screws along each side of heater using 5/16" nut-driver. These screws attach upper and lower shells together. 2. Lift or slide upper shell off. 3. Remove fan guard. IMPORTANT: Remove fan from motor shaft before removing motor from heater. -
Page 11: Specifications
SPECIFICATIONS WIRING DIAGRAM Thermal Switch Blue Insulated Connector Blue On/Off Switch Power Cord 120 VAC 101568 Output Rating (BTU/Hr) Fuel Fuel Consumption Gallons/Hour Pounds/Hour Supply Pressure To Regulator Minimum (for purposes of input adjustment) Maximum Regulator Outlet Pressure (Factory Preset) Manifold Pressure Hot Air Output (CFM Approx) Motor... -
Page 12: Illustrated Parts List
ILLUSTRATED PARTS BREAKDOWN HP155A Note: Screws are standard hardware items 101568... -
Page 13: Parts List
PARTS LIST PART NUMBER A-03326-45 A-03326-46 A-03326-16 A-03326-23 A-03326-08 A-03326-50 A-03326-51 101568 DESCRIPTION 01086-01 Upper Shell, Model HP155A 00529-16 Screw, #10-16 x 1/2" Combustion Chamber Kit 03326-37 Nozzle 03326-34 Ignitor 01086-32 Screw, #8-18 x 3/8" Fuel Tube Kit 03326-15 Ignitor Cable... - Page 14 NOTES _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ _______________________________________________________________ 101568...
