STEREO GUITAR RIG – Connect the left and right outputs of a stereo
processor to the inputs of two Reactor FRs to create a wide, 3D sound.
DUAL MONO
Connected as in the mono setup above, but with the THRU of the first
Reactor FR connected to the input of a second Reactor FR (XLR only.)
R I G D I A G R A M S
MONO GUITAR RIG - Guitar rack
(ex: Fractal Axe-FX Ultra) connected
to the balanced XLR input or the ¼"
unbalanced input of the Reactor FR
(whichever is convenient for you).
