- Page 1 Reactor 50-112 / 50-212 Owners Manual Copyright 2006 by G66 GmbH...
-
Page 2: Product Summary
Introduction Congratulations on your purchase of an Atomic Reactor 50 112/212, a major step in bringing vacuum tube analogue musicality to the digital world. The Reactor 50 112/212 is an extremely versatile musical instrument that provides a live performance platform for your modeling tools and instrument processors. The Reactor 50 112/212 is clearly different from other guitar amplifiers. -
Page 3: Getting Started
All other Modelers – especially all Floor Pedals – should be connected to the Return Jack of the Atomic Reactor amplifier, the guitar is then connected to the Input jack of the Modeler. The docking station DS-1 should then be closed with the blank template kit, on which no drinks or food should be placed, even though the temptation may be great. - Page 4 O u t“, so th at th e ri g h t sp eaker, b o x an d m i cro p h o n e m o d el s are acti va ted . The output signal of the Modelers can be sent direct to a Mixer via the Send Jacks (left/right) on the rear side of the Atomic Amps, for an absolute professional PA or Recording sound.
- Page 5 8, 12, 13, & 14. Installing a Modeler into the DS-1 In the large opening of the Atomic Amp, you will see three round cavities, like circles in a cornfield. This is where the mushroom heads of the locking screws fit.
- Page 6 Screw the 3 thumbscrews l ab e l ed “A ”, "B ” & ”C ”, i n to th e corresponding holes located on the bottom of the DS-1. Attach the 3 rounded mushroom heads caps to the ends of the locking screws.
- Page 7 Modeler sounds, making crisp and warm guitar amp sounds. The right Output Jack of the DS-1 connects the Modeler directly to the Send-R-Jack of the Atomic Reactor-Effect-Loop on the rear side. The signal is mono until a cable is put into the Send-R-Jack.
- Page 8 Modeler and you will hear those fantastic warm, crisp Guitar/Amp sounds blow your tootsies off! For Rich Kids: If you want a really professional stereo solution, buy a second Atomic Reactor amp. Connect the Send-R-Output from the first Atomic Amp (the one with the Modeler!) with the Return-Jack on the rear of the second Atomic Amp.
- Page 9 Turn on Reactor #2s power switch (it should light up). Later turn on stand by. MODEL REACTOR 112 Atomic Amplifiers LLC. Orange CT. 0101010101 FUSE Load the DS-1 into the docking bay located in the top of Reactor #1,...
- Page 10 MODEL REACTOR 112 Atomic Amplifiers LLC. Orange CT. 0101010101 FUSE Replace the DS-1 ’ s b ack into the docking bays located in the top of the Reactors making sure that the dock locks click into position.
- Page 11 Turn the Reactors power switches to the ON position (they should light up). MODEL REACTOR 112 Atomic Amplifiers LLC. Orange CT. 0101010101 FUSE Replace the DS-1 ’ s b ack into the docking bays located in the top of the...
- Page 12 Connecting an external Loudspeaker Box On the rear side of the Atomic Reactors 50 112/212/50 and the 212/50 is a Output Jack for an external Loudspeaker Box. The impedance should not exceed 8 Ohms, use a professional loudspeaker cable not a guitar cable which can melt and burn.
