Summary of Contents for N-Tron 102PC-SE
- Page 1 102PC-SE Industrial Serial - Ethernet Protocol Converter User Manual & Installation Guide 12/1/2006...
-
Page 2: Table Of Contents
Serial Auto Dial-in Using Telnet ...33 o Serial Auto Dial-in Using UDP ...34 o Serial Tunneling Mode ...35 Using E-mail Features...36 o Sending Text E-mails From the Command Prompt...37 o Receiving E-mails From the Command Prompt...38 KEY SPECIFICATIONS...39 N-Tron Limited Warranty...40 12/1/2006... -
Page 3: Applications
Industrial Serial to Ethernet Protocol Converter Installation Guide 102PC-SE The 102PC-SE will IP-enable any serial device to provide remote monitoring, control, and configuration of any serial device. This device is ideal for the following applications: Mounting legacy serial devices to the LAN... -
Page 4: Safety Warnings
Do not operate the equipment in a manner not specified by this manual. Safety Warnings GENERAL SAFETY WARNING: If the equipment is used in the manner not specified by N-Tron Corp., the protection provided by the equipment may be impaired. Contact Information N-Tron Corp. -
Page 5: Environmental Safety
ENVIRONMENTAL SAFETY WARNING: Disconnect the power and allow to cool 5 minutes before touching ELECTRICAL SAFETY WARNING: Disconnect the power cable before removing the enclosure top. WARNING: Do not operate the unit with the top cover removed. WARNING: Do not work on equipment or cables during periods of lightning activity. WARNING: Do not perform any services on the unit unless qualified to do so. -
Page 6: Package Contents
Stores 10,000 MAC addresses Automatically learns MAC addresses Command line interface The 102PC-SE operates on 10-30VDC Housed in a steel ruggedized DIN rail enclosure, designed to withstand the most demanding industrial applications, and have been fully tested and certified at industrial environmental extremes... - Page 7 15° upward angle to completely remove the unit. With the exception of the 524TX and 526FX2, all N-Tron™ products are designed to be mounted on industry standard 35mm DIN rail. However, DIN rail mounting may not be suitable for all applications.
-
Page 8: Front Panel
FRONT PANEL From Top to Bottom: Green LED lights when Power is connected RJ45 Ports Auto sensing 10/100 BaseTX Connections Serial RS232 serial port with DCE configuration NOTE: The RJ45 data port has two LED’s located at the left side of the connector. The top LED indicates Activity (ACT), and the lower LED indicates Link (LNK) status. -
Page 9: Applying Power (Top View)
DC Voltage sources. This device will draw current from both sources simultaneously. Use 16-28 gauge wire when connecting to the power supply. Recommended 24V DC Power Supplies, similar to: 100VAC/240VAC: N-Tron’s NTPS-24-1.3, DC 24V/1.3A, 12/1/2006... -
Page 10: Grounding Techniques
(i.e. CE) are obtained when the N-Tron switch chassis is connected to earth ground via a drain wire. Some N-Tron switches have metal din-rail brackets that can ground the switch if the din-rail is grounded. In some cases, N-Tron switches with metal brackets can be supplied with optional plastic brackets if isolation is required. -
Page 11: Connecting The Unit
CONNECTING THE UNIT For DCE serial devices (like a modem) use a null modem RS-232 cable to connect to the 102PC-SE. For a DTE serial device (like a computer) use a straight through RS-232 cable. For the 10/100 Base-TX port, plug a Category 5E twisted pair cable into the RJ45 connector. Connect the other end to a PC or a network through a hub or switch. -
Page 12: Serial Interface
SERIAL INTERFACE The 102PC-SE provides an EIA-232 interface accessed via a 9 pin male connector (labeled ‘COM’ on the unit). This is used to access the Command Line Interpreter (CLI), and to attach serial devices to the network over Ethernet. The... -
Page 13: Troubleshooting
6. Verify that a null-modem cable is being used to connect other DCE devices to the serial port, or that a straight through cable is being used to connect a PC to the serial port. SUPPORT Contact N-Tron Corp. at: TEL: 251-342-2164 FAX: 251-342-6353 www.n-tron.com... -
Page 14: Cli Tree Of Menus
(enable or disable the auto-dialout feature) (setup the default gateway in the format of xxx.xxx.xxx.xxx) (enable or disable the DNS features below) (setup the 102PC-SE’s hostname) (enable or disable the webpage options) (display the serial page or the default page) - Page 15 (set the smtp server name) (set the smtp server port number) (set the host name) (set the mail ID for the from address, ex. info@n-tron.com) (string associated with the mail ID, ex. N-Tron) (set the to mail address field) (set the cc mail address field)
- Page 16 (Delete a user) password (Set the password for a user) Save (Saves the configurations made and restarts the 102PC-SE) Dialout serial s0 (Used to dialout or look out the serial port over the Ethernet port) Send-mail (Sends mail, not available over telnet)
- Page 17 Socket (Actions to take over a UDP socket) close (closes a socket by its handle <socket_handle>) closeall (closes all the sockets) flush (flush out a socket by its handle <socket_handle>) flushall (flush out all the sockets) listall (lists all the sockets (TCP connect, TCP listen, and UDP sockets)) listlisten (lists all the TCP listen sockets) recv [-s <max_size>] <socket_handle>...
-
Page 18: Software Configuration
DHCP server on the network he will use that and acquire the next available IP address that the DHCP server has in its DHCP pool. You must know what the IP address is before you can configure the 102PC-SE through a web browser. If you need to you can configure a static IP address through the serial port. - Page 19 Both links should display the page below. Here you can configure every option that the 102PC-SE will support. Don’t forget to save the running configuration after making changes. Otherwise settings may not change after a power cycle on the switch.
-
Page 20: Web Management Tree Of Menus
Web Management Tree of Menus General Configuration Authentication: Enables/Disables Authentication (Login Prompt) for command line configuration/management via Serial and Ethernet Default: enable BootMessage: Enables/Disables the display of boot-messages during module boot-up Default: enable Autodialout: Enables/Disables Telnet Auto-Dialout authentication Default: enable Watch Dog: Enables/Disables the watchdog timer (6.5 seconds by default) Default: enable User Configuration... -
Page 21: Bridge Configuration
Dialout session is terminated when DTR signal on the serial port s0 toggles from High to Low none Dialout session is not dependant on the DTR signal Default: none Modem Configuration Connect String: Sets the Modem Connect string Default: CONNECT OK String: Sets the Modem OK string Default: OK Hangup String: Sets the Modem hang-up string... -
Page 22: Telnet Configuration
Default Gateway: Sets the IP default gateway address Default: 0.0.0.0 IP DNS: Enables/Disables DNS client on the module Default: disable Pri DNS: Sets the Primary DNS IP address Default: 0.0.0.0 Sec DNS: Sets the Secondary DNS IP address Default: 0.0.0.0 DHCP Client: Enables/Disables DHCP Client Note: DHCP info parameters DHCP netmask, Gateway, DNS and DHCP server will be set if the module obtains IP address from DHCP server... -
Page 23: Ftp Configuration
Inactivity: Enables/Disables the inactivity timeout feature. If this is enabled, the telnet/tcp session is terminated if there is no traffic for the configured timeout value Default: disable Inactivity Timeout: Sets the timeout (t seconds) value for the telnet session to be terminated if there is no traffic Default: 300 seconds Raw Mode: Enables/Disables the raw mode for Telnet Auto-Dialout and Serial Auto-Dialin features globally Default: disable... -
Page 24: Http Configuration
HTTP Configuration HTTP: Enables/Disables the HTTP server for the module/host device configuration/monitoring Default: disable HTTP Port: Sets the HTTP server port to listen for requests Default: 80 HTTP Page: Sets the HTTP server to give control on module configuration from the browser or give access to only serial device pages. If set to "default", the default HTML page (index.html) is launched. -
Page 25: Restore Defaults
SNTP General SNTP Client: Enables/Disables the SNTP Client to contact the configured server on UDP port 123 and set the local time Default: disable Server Name: Sets the NTP server name or IP address to which the SNTP Client has to contact to update the time Default: 127.0.0.1 Time Zone: Sets the time zone Default: UTC... -
Page 26: Ethernet To Serial Connectivity
Ethernet to Serial Connectivity Mandatory Configuration Settings The following items must be configured in order to use the manual dial-out feature: Disable the Host Interaction Mode to restrict Telnet-Dial-Out and PPP. # set serial <s0> host-interaction-mode disable Disable Auto dial-out globally on all the serial ports. # set ip auto-dialout disable Disable Auto dial-out on the serial port s0. -
Page 27: Manual Dialout
# set serial s0 flow-control rts-cts # save Once the above configuration is saved in the 102PC-SE, use a telnet client and connect to 192.168.1.202 on port 23. On successful login, at the 102PC-SE command prompt, invoke # dialout serial s0 The serial port now opens for use. -
Page 28: Auto Dialout Using Telnet
# set serial s0 flow-control rts-cts # save Once the above configuration is saved in the 102PC-SE, use a telnet client and connect to 192.168.1.202 on port 5000. This eventually establishes a telnet Auto dial-out session between the 102PC-SE and the serial device. -
Page 29: Auto Dialout Using Udp
Functionality When any UDP client connects to the 102PC-SE on the configured port, the 102PC-SE locks the serial port for that UDP-Client and latches to the UDP client address connected. The UDP-Client is now ready to send or receive data to or from the serial device. -
Page 30: Remote Bridging With Modem Connection
For simple AHDLC quoting on the serial port, the raw-mode has to be enabled on both the 102PC-SEs. Raw-mode is disabled by default 102PC-SE Module-1 is configured for modem dialing. 102PC-SE Module-2 is configured for modem answering. If you wish to have a complete control on the modem-dialing end, use the chat-scripts. By default the dialing-method is configuration. -
Page 31: Serial To Ethernet Connectivity
Serial to Ethernet Connectivity Mandatory Configuration Settings The following items must be configured in order to use the manual dial-in feature Disable Auto dial-in globally on all the serial ports. # set serial auto-dialin disable Disable Auto dial-in on the serial port s0. # set serial s0 auto-dial-in disable The following items must be configured in order to use the auto dial-in feature Enable Auto dial-in globally on all the serial ports. -
Page 32: Serial Manual Dial-In
# set serial s0 flow-control rts-cts # save Once the above configuration is saved on the 102PC-SE, login to the 102PC-SE through the serial port. At the command shell invoke: # telnet 192.168.2.10 23 The telnet client on board in the 102PC-SE establishes a virtual serial tunnel between the serial device and the Telnet Server. -
Page 33: Serial Auto Dial-In Using Telnet
# set serial s0 flow-control rts-cts # save When detecting either a DTR signal (or) any character received from the serial device connected to the serial port of 102PC-SE, the Telnet client in the 102PC-SE establishes a telnet session to 192.168.2.10 on port 23. -
Page 34: Serial Auto Dial-In Using Udp
You can switch from Command Prompt to Dial-in session using the restore session command. You can switch from Dial-in session to Command Prompt using <escape-monitor-string>. Commands to Setup Auto Dial-In in Telnet Mode with the 102PC-SE # set ip eth0 dhcp-client disable # set ip eth0 ip-address 192.168.2.1... -
Page 35: Serial Tunneling Mode
Scenario 4 – Serial Tunneling Mode This scenario shows a serial tunnel established between two serial devices (Serial Device-1, Serial Device-2) using two 102PC-SEs, which are geographically located apart. Commands for Module-1 (Configure for Serial Auto Dial-in). # set ip eth0 dhcp-client disable # set ip eth0 ip-address 192.168.2.1 # set ip telnet raw-mode enable # set serial auto-dialin enable... -
Page 36: Using E-Mail Features
Using E-Mail Features Mandatory Configuration Settings The following items must be configured in order to send e-mails Set the SMTP server address. # set send-mail smtp-server-name <smtp.servername.com> Set the port number the SMTP server is using. # set send-mail smtp-server-port <25> Set the host name that you are sending from. -
Page 37: Sending Text E-Mails From The Command Prompt
Cc address not given subject: testing Message body: Enter Ctrl+D to end mail, Ctrl+C to quit mail Testing the e-mail features on the 102PC-SE..." OK: Mail sent Notes: 1. The email is not sent to addresses pre-configured using set commands. -
Page 38: Receiving E-Mails From The Command Prompt
Content-Type: text/plain; charset=ISO-8859-1 Content-Transfer-Encoding: 7bit Message-Id: <20050525195053.PFXI1498.ibm61aec.bellsouth.net@adsl-220-163-81.mob.bellsouth.net> Testing the e-mail features on the 102PC-SE..." OK: Message 2 Received Notes: 1. You can receive 1 message at a time by specifying which message you want to look at in the <n> field. -
Page 39: Key Specifications
Switch Properties Number of MAC Addresses 10,000 Physical Height: 3.98" (10.11cm) Width: 2.01" (5.10 cm) Depth: 3.91" (9.931 cm) Weight: 0.75 lbs (0.3 kg) DIN rail: 35mm Electrical Redundant Input Voltage: 10-30 VDC (Regulated) Input Current: 40 mA @ 24VDC (Steady State) Inrush Current: 7.0 Amp / 0.5 ms @ 24VDC Environmental... -
Page 40: N-Tron Limited Warranty
N-TRON, Corp. warrants to the end user that this hardware product will be free from defects in workmanship and materials, under normal use and service, for the applicable warranty period from the data of purchase from N-TRON or its authorized reseller. If a...
