LG Multi V ARNU073B1G2 Svc Manual page 5

Type
Accessory
Model
Cooling Capacity
Heating Capacity
Casing
Dimensions(WxDxH) Body
Rows x Columns x FPI
Coil
Face Area
Type
Motor Output x Number
Running Current
Air Flow Rate(H/M/L)
(High Mode-factor set)
Fan External Static Pressure mmAq(Pa)
Air Flow Rate(H/M/L)
(Standard Mode)
External Static Pressure mmAq(Pa)
Drive
Motor type
Temperature Control
Sound Absorbing Thermal Insulation Material
Air Filter
Safety Device
Liquid Side
Pipe Connections Gas Side
Drain Pipe(Internal Dia.)
Net Weight
Noise Level(Sound Press, 1m, H/M/L)
Power Supply
Refrigerant Control
Power cable
Transmission cable
Notes:-
1. Capacities are based on the following conditions:
Cooling • Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
• Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
• Interconnecting Piping Length 7.5m(24.6ft)
• Level Difference of Zero
Heating • Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
• Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
• Interconnecting Piping Length 7.5m(24.6ft)
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. EEV: Electronic Expansion Valve
5. To be added for more available Models
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
PBSGB30/PBSC30
Unit ARNU153B1G2
kW 4.5
kcal/h 3,900
Btu/h 15,400
kW 5.0
kcal/h 4,300
Btu/h 17,100
Galvanized Steel Plate
mm 820 x 575 x 190
inch 32.3x22.6x7.5
2x11x21
m 2 (ft 2 ) 0.16(1.7)
Sirocco Fan
W 30
A 0.1
CMM 11/10/8
cfm 388/353/282
2(20)
CMM 11/10/8
cfm
388/353/282
0(0)
Direct
BLDC
Mi c roprocessor, Thermostat for cool i n g and heati n g Mi c roprocessor, Thermostat for cool i n g and heati n g Mi c roprocessor, Thermostat for cool i n g and heati n g
Foamed polystrene
-
Fuse, Thermal Fuse for Fan Motor Fuse, Thermal Fuse for Fan Motor Fuse, Thermal Fuse for Fan Motor
mm(inch) Ø6.35(1/4)
mm(inch) Ø12.7(1/2)
mm(inch) 25.4(1)
kg(lbs) 21(46.3)
dB(A) 41/40/37
Ø, V, Hz 1,208/230,60
EEV
mm 2 CV1.5 x 3C
mm 2 CVV-SB 1.25 x 2C
- 5 -
Ceiling Concealed Duct (Built-in)
PBSGB40/PBSC40
ARNU183B2G2
5.6
4,800
19,100
6.3
5,400
21,500
Galvanized Steel Plate
1,100 x 575 x 190
32.3x22.6x7.5
3x10x18
0.23(2.5)
Sirocco Fan
80
0.25
14/12/10
494/424/353
2(20)
14/12/10
494/424/353
0(0)
Direct
BLDC
Foamed polystrene
-
Ø6.35(1/4)
Ø12.7(1/2)
25.4(1)
26(57.3)
43/40/37
1,208/230,60
EEV
CV1.5 x 3C
CVV-SB 1.25 x 2C
PBSGB40/PBSC40
ARNU243B2G2
7.1
6,100
24,200
8.0
6,900
27,300
Galvanized Steel Plate
1,100 x 575 x 190
32.3x22.6x7.5
3x10x18
0.23(2.5)
Sirocco Fan
80
0.25
17/15/10
600/530/353
2(20)
17/15/10
600/530/353
0(0)
Direct
BLDC
Foamed polystrene
-
Ø9.52(3/8)
Ø15.88(5/8)
25.4(1)
26(57.3)
46/43/37
1,208/230,60
EEV
CV1.5 x 3C
CVV-SB 1.25 x 2C
Conversion Formula
kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m 3 /min x 35.3
l/s = CMM x 1000/60
LGE Internal Use Only
