QuickSpecs
Overview
HP Remote Monitoring Power Distribution Units (PDU) provide rack level power monitoring over the network. With billing grade accuracy
these PDUs are excellent choices for data centers wanting to make the most of circuit capacity or for co-location facilities needing to
precisely track power usage for billing purposes.
The low profile single piece design on these PDU's provides multiple mounting options and ease of access to rear devices for
maintenance. They are designed for HP racks but will also work in a large variety of third party racks as well using standard button and
keyhole mounting. They can be installed on either side of the rack with outlets facing the back of the rack for easy access and improved
clearance. Also for higher power density they can be installed side by side on both sides of the rack with the outlets facing in towards
the center of the rack. HP Remote Monitored PDUs are available in 1U and vertical form factors in single and 3-phase models and are
back by HP's limited 3-year warranty.
Monitored PDU, 1UModels (D9N46A shown)
Monitored PDU, Mid Height Models (D9N47A/D9N48A shown)
HP Remote Monitored Power Distribution Units (mPDU)
DA - 14669 North America — Version 7 — May 9, 2014
Monitored PDU, Half Height Models (D9N45A shown)
Monitored PDU, Full Height Models (D9N58A/D9N59A shown)
Page 1

Advertising

   Related Manuals for HP D9N46A

   Summary of Contents for HP D9N46A

  • Page 1

    The low profile single piece design on these PDU's provides multiple mounting options and ease of access to rear devices for maintenance. They are designed for HP racks but will also work in a large variety of third party racks as well using standard button and keyhole mounting.

  • Page 2

    Full Height Models HP 8.3kVA 208 Volt CS8265C Input (30xC13/3xC19) NA Monitored PDU D9N49A HP 16.6kVA 400 Volt IEC309 30A 3-Phase Input (30xC13/3xC19) NA Monitored PDU D9N61A HP 17.3kVA 208 Volt IEC309 60A 3-Phase Input (24xC13/3xC19) NA/JP Monitored PDU D9N54A HP 14.4kVA 208 Volt CS8365C 3-Phase Input (12xC13/12xC19)NA Monitored PDU...

  • Page 3

    Daisy chain up to 2 PDUs on the same IP address Optional environment sensor measures temperature and humidity Models range from 2.8kVA to 22kVA Billing grade accuracy All HP Remote Monitoring PDUs meet IEC 62053-21, Class 1 standards for ±1% or better accuracy in power monitoring of: Amperage Voltage...

  • Page 4

    Standard Features Multiple models for The HP Remote Monitoring PDUs are available in four form factors for a variety of racks and environments. All HP Remote Monitoring PDUs can be mounted to stay completely out of the critical rear maintenance flexible installation path needed to service IT equipment in the rack.

  • Page 5

    QuickSpecs HP Remote Monitored Power Distribution Units (mPDU) Standard Features Easy Installation and Standard button and keyhole mounting provides simple drop in installation in HP 11000 G2 Series racks, Intelligent Series Racks, and many third party racks. compatibility Warranty Upgrade HP Remote Monitoring PDUs are backed by a limited 3-year warranty.

  • Page 6: Service And Support

    30 mins for critical problems to 2 hours. System Management, Performance Services and Mission Critical Support Solution NOTE: For more information on HP Care Pack services, contact any of our worldwide sales offices or resellers or visit our worldwide Web site on the internet at: http://www.hp.com/hps/carepack...

  • Page 7

    Measures relative humidity from 10% to 90% with an accuracy of ±5% Supports normally open and normally closed contact devices NOTE: The HP Environmental Sensor comes with a 6 foot RJ45-RJ45 cable and can be mounted in various locations within the rack using the supplied Velcro strips or mounting screw.

  • Page 8

    NOTE: Allows HP Basic and Remote Monitored PDU vertical models to be mounted in HP 10000 G2 series racks and in the HP V142 rack. This bracket is not needed for mounting in the HP 11000G2 or Intelligent Series racks. PDUs may interfere with the rear maintenance zone when using these brackets.

  • Page 9

    QuickSpecs HP Remote Monitored Power Distribution Units (mPDU) Remote Monitoring PDU Family Information Model Selection Matrix - HP Remote Monitored PDUs HP Remote Monitoring PDUs 1U models Model Part Number Input Circuit Current Load capacity Input Output circuit Outlet Maximum...

  • Page 10

    QuickSpecs HP Remote Monitored Power Distribution Units (mPDU) Remote Monitoring PDU Family Information 11kVA PDU D9N55A 380-415V 16A/phase 11040VA 8ft(2.4m) cord 18 x IEC C13 @ 400V 3 Phase with attached 3 x IEC C19 3 Phase WYE IEC 516P6...

  • Page 11

    NEMA L22-30P (LS-26) * HP Remote Monitored PDU models D9N45A and D9N46A require an IEC 320-C19 to country specific plug inlet cord which is sold separately. NOTE: Please refer to the Power Cord Matrix for more information on power cords/cable part numbers, input/output descriptions.

  • Page 12: Technical Specifications

    To recycle your product, please go to: http://www.hp.com/go/green or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities.

  • Page 13

    The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
