- Page 1 HAND HELD METAL DETECTOR Model No.MD10 PART NO: 4500150 OPERATING & MAINTENANCE INSTRUCTIONS GC02/09...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Hand Held Metal Detector. Before attempting to use the product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
- Page 3 FEATURES OF THE MD10 The CLARKE MD10 is a portable, hand held metal detector intended to be used for security inspection in airports, schools, courthouses, prisons, stadiums and entertainment places. It can detect concealed weapons such as knives or other metal objects in baggage, postal parcels or under clothing.
- Page 4 PREPARATION FITTING THE BATTERY 1. Release the battery cover retaining screw before lifting the cover and pulling it backwards. Install one 9V alkaline battery type PP3 or equivalent, connecting it to the battery clip. 3. Replace the cover and tighten the screw. FUNCTIONS OF THE DETECTOR POWER SWITCH This is a rocker switch which has three positions:...
- Page 5 ADJUSTING THE SENSITIVITY Insert the tip of a small screwdriver though the Sensitivity Adjustment apperture. Slowly rotate the SENS control clockwise to increase (or counter- clockwise to decrease) the sensitivity until both audio and visual alarms signal continuously, before easing off slightly. Position a suitable target in front of the detector and adjust until the target is reliably detected.
- Page 6 • Remove the battery from its compartment if the metal detector is not going to be used for a long time. SPARE PARTS LIST The only spare part required for the MD10 unit is a single 9V alkaline battery, type PP3 or equivalent. SPECIFICATION...
- Page 7 DECLARATION OF CONFORMITY...
