Summary of Contents for Caple RIR178
- Page 1 Instruction manual for integrated fridge Model code:RIR178 Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk...
-
Page 2: Table Of Contents
Contents Cautions---------------------------------------------------------------------------------------1~2 Diagram----------------------------------------------------------------------------------------3 Preparation------------------------------------------------------------------------------------4~5 Operation--------------------------------------------------------------------------------------6 Instruction-------------------------------------------------------------------------------------7~10 Defrosting,cleaning and de-commissioning------------------------------------------11~12 Trouble shooting----------------------------------------------------------------------------13... - Page 3 Compression-type appliances which use flammable refrigerants shall be marked with the symbol “Caution: risk of fire”. Caution：risk of fire The height of the triangle in the symbol “Caution: risk of fire” shall be at least 15 mm. – WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
-
Page 4: Cautions
Cautions Disposal of the old appliance Before disposing an old appliance, please make sure it’s inoperative and safe. Unplug the appliance and remove or destroy all of the springs, latches, or bolt-locks in order to avoid the risk of child entrapment. It must be noted that the refrigeration system contains insulating gases and refrigerants, which require specialized waste disposal. - Page 5 is to be carried out in strict compliance...
-
Page 6: Diagram
Refrigerator Diagram 1.Freezing compartment 2.Temperature Controller 3.Shelves 4.Vegetable and fruit tray 5.Egg tray 6.Bottle racks This diagram may vary slightly with the layout of the refrigerator you have just purchased due to technical improvements. -
Page 7: Preparation
Preparation Unpacking Remove all packing materials. Check attachments and materials Checking should be conducted with reference to the Packing List. Contact the local distributor if discrepancies are found. Ensure proper location of the refrigerator. Clean the refrigerator before use. (See the following section “Cleaning”) Idle time After the refrigerator has been sited and cleaned, let it stand for more than 12 hours before connecting the power source. - Page 8 Preparation Installation（Figure 2） 1.Check that the kitchen unit door is in the correct operating position. 2.Run the mains cable through the unit such that it can be connected to the power supply after installing the appliance. Remove the cover (6) only if space is restricted. 3.Place the refrigerator into the kitchen unit.
-
Page 9: Operation
Caution: Some time will be required for the refrigerator to reach the set level when temperature adjustments are made. The length of this period is determined by difference in the existing and set temperatures, the ambient temperature, the frequency with which the door is opened and closed and the amount of food in storage. -
Page 10: Instruction
Instructions Cold storage is for short-term food Storage or for daily consumption. Although the temperature in most parts of the cold storage compartment can be regulated between 0 and 10 degrees Centigrade, extended periods of food storage is not recommended. Cold storage should only be used for short-term storage. - Page 11 Shelf cleaing Lamp & Replacement: Lamp: 240V, 10W Lamp holder: E14 (lamps exceeding 15W must not be used) * For replacement, unplug to disconnect the power * Remove the lamp by turning anti-clockwise...
- Page 13 Making ice cubes...
- Page 15 Prolonged power failure...
-
Page 16: Trouble Shooting
stays become damp. work Dry food... - Page 18 Installation guide for built-in refrigeration Please carefully read this guide before installing the appliance.
- Page 20 Model RI734 1773 - 1778 550 - 560 1774 - 1782 1773 - 1778 1774 - 1782 RI733 RIR177 1773 - 1778 550 - 560 1774 - 1782 RI555 1773 - 1778 550 - 560 1774 - 1782 RI554 1773 - 1778 550 - 560 1774 - 1782 RIL177...
