- Page 1 B u i l t i n 5 0 / 5 0 F r i d g e F r e e z e r I n s t r u c t i o n M a n u a l RI5 5 06 Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk...
-
Page 2: Table Of Contents
Product Overview Using The Appliance Caple Fresh Humidity Controlled Drawer Easy Adjustable Door Shelf Food Storage Cleaning And Maintenance Transport And Repositioning Troubleshooting Energy Saving Tips Caple Contact Details Instruction manual Ri5506 Please keep this instruction manual for future reference... - Page 3 They may only use it unsupervised if they have been shown how to use it in a safe manner. They must be able to recognise and understand the dangers of misuse. Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 4 T E C H N I C A L S A F E T Y : - Maintenance and repair work must be made only by authorised Caple service technicians. Installation and repair work that is carried out by unauthorised technicians may endanger you.
- Page 5 - To maintain the efficiency and safety of your appliance, we recommend you always use original spare parts and to call only our authorised Caple Service agents in case of need. - Multi-socket adapters and extension leads should not be used to connect the appliance to the mains electricity supply.
-
Page 6: Warnings
- During installation the appliance must be completely disconnected from the mains electricity supply. - Do not operate the appliance before it is fully installed. Instruction manual Ri5506 Please keep this instruction manual for future reference... - Page 7 - Clearance of at least 150 mm is required at the top of your appliance. Do not place anything on top of your appliance. - Caple is not responsible for any damage that may be caused by defective placement and installation by unauthorised persons.
- Page 8 WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged. If the supply cord is damaged, it must be replaced by a Caple service technician or similarly qualified persons in order to prevent a hazard. - Never touch the power cord/plug with wet hands. This may cause a short circuit or electric shock.
- Page 9 - If using the appliance to quickly cool drinks, do not leave bottles inside the freezer compartment for more than 1 hour, otherwise they could burst. Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 10 - Never use the door handles for lifting. - The appliance is heavy and could cause injury, it must be transported by two people. 10 Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 11 Injury or property damage risk pipework, scratching the surface coating. CAUTION: Operating the system correctly IMPORTANT: Symbol ISO 7010 W021 Warning; Risk of fire / flammable materials Instruction manual Ri5506 Please keep this instruction manual for future reference...
-
Page 12: Environmental Protection
(placed on the inside of the appliance storage drawer). Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase. -
Page 13: Electrical Connection
3. Replace fuse cover. fuse in this type of plug, follow the steps below: the fuse cover and fuse. ement 13A fuse, ASTA approved to BS nto the fuse cover. use cover. Instruction manual Ri5506 Please keep this instruction manual for future reference... -
Page 14: Ventilation Requirements
N OT E : Installation instructions are supplied with the appliance in a separate document. Only the solid metal fixing bracket is included (part 1a) for installation. 14 Instruction manual Ri5506 Please keep this instruction manual for future reference... -
Page 15: Product Overview
13) Egg tray This presentation is only for information This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model Instruction manual Ri5506 Please keep this instruction manual for future reference... -
Page 16: Using The Appliance
The coolant within the product needs time to settle after it has been transported and put into position, failure to do this will affect the cooling performance of your appliance. 16 Instruction manual Ri5506 Please keep this instruction manual for future reference... - Page 17 Therefore, your Frost free fridge allows ease of use, in addition to its huge capacity and stylish appearance. Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 18 D I S P L AY A N D C O N T R O L PA N E L max. 1) Temperature set button 2) Super cooling mode LED 3) Alarm indicator LED 4) Temperature setting indicator 18 Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 19 › Super cooling LED will light during this mode. › For optimal appliance performance in maximum cooling capacity, set the appliance to active Super Cooling mode 5 hours before you put the fresh food into the fridge. Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 20 Climate Ambient Temperature Class Between 16 and 43 (°C) Between 16 and 38 (°C) Between 16 and 32 (°C) Between 10 and 32 (°C) 20 Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 21 When making ice cubes, fill the ice tray with water and place in freezer compartment. After the water has completely turned into ice, you can twist the tray as shown below to release the ice cubes. Instruction manual Ri5506 Please keep this instruction manual for future reference...
-
Page 22: Caple Fresh
By this method, it maximises the fresh foods shelf life, especially green vegetables. Caple Fresh also blocks the bad smells produced in the refrigerator. › The Caple Fresh filter must be cleaned once a year. It can be cleaned by leaving in sunlight for one day. -
Page 23: Humidity Controlled Drawer
N OT E : The drawers are specifically designed to store fruit & vegetables only. We do not recommend storing meats and/or fish in these drawers. Humidity Control Instruction manual Ri5506 Please keep this instruction manual for future reference... -
Page 24: Easy Adjustable Door Shelf
(there are 6 height positions). Once set at the correct height, release the buttons to lock it into position. N OT E : Please ensure the shelf is empty before adjusting. 24 Instruction manual Ri5506 Please keep this instruction manual for future reference... -
Page 25: Food Storage
Potatoes, onions and garlic should not be stored in the refrigerator. The table below is a quick guide to show you the most efficient way to store the major food groups in your refrigerator compartment. Instruction manual Ri5506 Please keep this instruction manual for future reference... - Page 26 On the designated egg tray Cooked food 2 days All shelves These are guidelines only, always refer to the expiry date, or best before date recommended by the producer. 26 Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 27 If you attempt to open the freezer door immediately after closing it, you will find that it will not open easily. This is normal. Once equilibrium has been reached, the door will open easily. Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 28 The table below is a quick guide to show you the most efficient way to store the major food groups in your freezer compartment. 28 Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 29 N OT E : Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting, it must not be re-frozen. Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 30 Strawberry and Blackberry Wash and hull 8 - 12 Cooked fruits Add 10 % of sugar to the container Plum, cherry, raspberry Wash and hull the stems 8 - 12 30 Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 31 Original packaging may be Cheese - excluding used for short-term storage. In slices 6 - 8 white cheese Keep wrapped in foil for longer periods. Butter, margarine In its packaging Instruction manual Ri5506 Please keep this instruction manual for future reference...
-
Page 32: Cleaning And Maintenance
N OT E : Warning; Risk of fire / flammable materials The power supply must be disconnected during cleaning. Warning; Risk of fire / flammable materials 32 Instruction manual Ri5506 Please keep this instruction manual for future reference... - Page 33 Clean it with soapy water at specific time intervals. This will prevent odours from forming. the water collection spout, flows into • • soapy water at specific time interval Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 34 R E P L A C I N G L E D L I G H T I N G To replace any of the LEDs, please contact Caple service to arrange. This should only be performed by a qualified electrician.
-
Page 35: Transport And Repositioning
› Remove all movable parts (shelves, accessories, vegetable bins, and so on) or fix them into the appliance against shocks using bands/tape when re-positioning or transporting. › Always carry your appliance in the upright position. Instruction manual Ri5506 Please keep this instruction manual for future reference... -
Page 36: Troubleshooting
1 hour, call Caple service 1 hour, call Caple service for assistance The product has been plugged 1 hour for assistance. - Page 37 If the edges of fridge cabinet that the door joint contact are warm; especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the compressor, this is normal. If humidity builds up inside the fridge freezer. Instruction manual Ri5506 Please keep this instruction manual for future reference...
- Page 38 › If the appliance is switched off or unplugged, wait at least 5 minutes before plugging the appliance in or restarting it in order to prevent damage to the compressor. If the problem persists or more help is required, please contact our Caple service team on or via email 0117 938 7420 service@caple.co.uk...
-
Page 39: Energy Saving Tips
6. Keep the covers of the different temperature compartments ( such as the crisper and chiller) closed. 7. The door gasket must be clean and pliable. Replace gaskets if worn. Instruction manual Ri5506 Please keep this instruction manual for future reference... -
Page 40: Caple Contact Details
1770 (mm) 1770 (mm) 840,5 (mm) 840,5 (mm) 802 (mm) 802 (mm) 817 (mm) 817 (mm) 1770 - 1778 (mm) 1770 - 1790 (mm) 62 (mm) 62 (mm) (1 x) (1 x) (2 x) (17 x) (4 x) (1 x) (4 x) (4 x) 4 7 m... - Page 41 (1 x) (2 x) (1 x) (1 x) (2 x) 90° (5x) (1 x)
- Page 42 Caple Service Fourth Way Avonmouth T: 0117 938 1900 Bristol E: service@caple.co.uk BS11 8DW www.caple.co.uk...
