Freecom Data Tank Gateway
Example: Setting up a WEP connection
GB
1. Go to 'Connections' and then click 'Wireless' on the web interface. This window contains
the main settings options for WLAN.
5
2. Enter the name used to identify your Data Tank Gateway in the network under 'Network
Name(ESSID)' . You may choose any name. In the example provided here, we are using
'DataTank' .
3. Select 'enable WEP encryption' (refer to illustration) and enter any authentication
key of your choosing under 'WEP' 'hex key' . This key has to contain either 10 or 26
characters. Jot down the key that you just typed in. It needs to be entered on all of
the devices that will connect with your Data Tank Gateway via WLAN.
In this example, we are using the key 'FA1158CDA3' . For security reason, you should not
use this key. Please use WEP only if your WLAN devices do not support WPA. The WEP-
Standard is outdated and not secure!
