- Page 1 Digital Gateway ® Installation & Owners Manual Model DG1200 [Revision: April 15, 1998, 0-215-006, ©Rytec Corporation]...
-
Page 3: Table Of Contents
TABLE OF CONTENTS PAGE HOW TO USE MANUAL................. 1 INTRODUCTION ..................2 EXPLANATION OF DIGITAL GATEWAY CONTROLS TERMINAL STRIP ..................3 INPUT STATUS LEDS ................3 PUSHBUTTONS Open Jog/Reset ..................3 Close Jog ....................3 UP Arrow/DOWN Arrow ................3 Other Pushbuttoms .................. - Page 4 PAGE DC INPUTS ....................6 Photoeye—Terminal 15 ................6 Loop—Terminal 29, Three Terminal Plug..........6 PRIORITY OF INPUTS ................6 TIMERS ....................7 OPEN BACKUP TIMER ................7 CLOSE BACKUP TIMER ................7 ALTERNATE ACTION (A/A) CLOSE DELAY TIMER....... 7 AUTO CLOSE DELAY TIMER ..............
- Page 5 SETTING THE PROGRAM OPTIONS ........... 15 DEFAULT INPUT SETTING ..............17 FAST-SEAL DOOR ................... 17 FAST-FOLD DOOR ................... 17 PREDADOOR/TURBO-SEAL DOOR ............17 WIRING SCHEMATICS FAST-SEAL—ONE-SPEED DIGITAL GATEWAY ........18 FAST-FOLD—TWO-SPEED DIGITAL GATEWAY ........19 PREDADOOR—TWO-SPEED DIGITAL GATEWAY ........ 20...
- Page 6 This page intentionally left blank.
-
Page 7: How To Use Manual
HOW TO USE MANUAL HOW TO USE MANUAL Throughout this manual, the following key words are used to alert the reader of potential hazardous situations, or situations where additional information for successfully performing the procedure is pre- sented: WARNING is used to indicate the poten- tial for personal injury, if the procedure is not performed as described. -
Page 8: Introduction
Auto Close Switch Delay Timer A/A Close Delay Timer Input Connection Information Status LEDs: Display Message Explanation Light is ON When Remote Contact Has Been Activated A0500028 Figure 1 Digital Gateway® is a registered trademark of Control Associates & Mfg., Inc. -
Page 9: Explanation Of Digital Gateway Controls
The open jog/reset button will operate while the left side of the unit. The power, output and input the Digital Gateway is in the AJAr or EdGE alarm connections to the Digital Gateway are made through condition. (See Figure 1.) this terminal strip. -
Page 10: Inputs To The Digital Gateway
The LSO LED will be ON when the door has reached The door will remain open and the Digital Gateway the full open position. display will read EdGE until the system is reset. -
Page 11: Olr (Overload Relay)-Terminal 18
Activate the Stop input or push the Open Jog/Reset This input has various functions that are explained in button on the Digital Gateway. The system will reset the Programming section of this manual. (See OP- and the door will remain open. -
Page 12: Dc Inputs
If you require no closing delay, set the timer to 0. The input operates the same as the Auto input (terminal 14). PRIORITY OF INPUTS DC Inputs Various inputs to the Digital Gateway have priority over other inputs. The following paragraphs explain A0500027 how some inputs affect others: Figure 4 •... -
Page 13: Timers
To reset the system: Determine the reason for the door not reaching the limit switch and correct the problem. Then reset the Digital Gateway by pressing the Open Jog/Reset button or the Stop button. This timer should be set for 1–2 seconds longer than it takes the door to open. -
Page 14: Auto Close Delay Timer
(See INPUTS to 0. Setting and messages for this timer will be TO THE DIGITAL GATEWAY on page 4 for a displayed as "dEL =" plus time. description of the various inputs to the Digital Gateway.) -
Page 15: Alarm Conditions
OP = 0 present both the LSO and LSC LEDs will blink. If the limits are wired correctly and the Digital Gateway still shows a missing limit connection, check the limit settings. The limits may be set to trip at the same time. -
Page 16: Cl = 0, Close Time Exceeded
The display message CL = 0 and the LSC LED the problem that caused the overload relay to trip, will blink. Check the door for proper operation and reset the overload relay and reset the Digital Gateway. reset the Digital Gateway. (See Figure 10.) (See Figure 12.) -
Page 17: Non-Alarm Conditions
A0500027 Figure 13 NON-ALARM CONDITIONS HELLO, SAFE START-UP When power is applied to the Digital Gateway the door will not move regardless of the status of any activator. A0500027 The display will read HELLO. The system will reset Figure 15... -
Page 18: Loc, Idle State
LOC, IDLE STATE This message will be displayed when input 24 is The 3 triac outputs of the Digital Gateway share a common power source which is terminal 4. Terminal 4 activated, the door is fully closed (on the closed limit is internally connected to the 24 vac power source. -
Page 19: Replacement
OPTIONAL PROGRAMS REPLACEMENT TROUBLESHOOTING The Digital Gateway has diagnostic features that aid in troubleshooting door problems. There are status LEDs and alarm conditions that show you what the door is doing. The alarm condition explanations and The fused disconnect must be in the OFF... -
Page 20: Program 2, Input 24
Passage Entry—Position, P2 = PEP When this option is turned on PROGRAM 3, INPUT This input can be used to place the Digital Gateway 26—Passage Limit Switch, LSP will also be turned on. into an inactive condition, operate the door manually... -
Page 21: Program 4, Programmable Options
Reverse Delay, rdt = 00 The Digital Gateway is programmed to immediately SETTING THE PROGRAM OPTIONS reverse the door if an activator or safety input is operated while the door is closing. This option can be As described in the OPTIONAL PROGRAMS section, used to delay the reversal of the door. - Page 22 SETTING THE PROGRAM OPTIONS 1. To enter into the programming mode press and hold both the Open and Close Backup Time buttons for three seconds. The display will change to three 0's as shown in Figure 20. To continue the programming mode, you will have to enter the PrOG - 1 three digit security code.
-
Page 23: Default Input Setting
DEFAULT INPUT SETTING to scroll through the options. Use the UP and A number of the inputs on the Digital Gateway can be DOWN arrow keys to set the time or option and set to operate with a normally open (N.O.) or a the Set button to return to the Main Program normally closed (N.C.) contact connected to them. -
Page 24: Wiring Schematics
WIRING SCHEMATICS—FAST-SEAL—ONE-SPEED DIGITAL GATEWAY (E4200) WIRING SCHEMATICS FAST-SEAL—ONE-SPEED DIGITAL GATEWAY (E4200) MOTOR DATA VOLTAGE RECOMMENDED FUSE OVERLOAD RYTEC NO MOTOR 6.0 AMP 193-A1E1 0-011-592 3.5 AMP 193-A1D1 0-011-591 0.97 1 8/10 AMP 193-A1D1 0-011-591 FUSED DISCONNECT BRAKE BY OTHERS 1 8/10 AMP... -
Page 25: Fast-Fold-Two-Speed Digital Gateway
WIRING SCHEMATICS—FAST-FOLD—TWO-SPEED DIGITAL GATEWAY (E4100) FAST-FOLD—TWO-SPEED DIGITAL GATEWAY (E4100) A1500143 NOTE: This schematic is for general infor- mation only. Due to varying require- ments for individual customers, a schematic is prepared for each door installation. This schematic is shipped inside of the control box and must be used for that specific instal- lation. -
Page 26: Predadoor-Two-Speed Digital Gateway
WIRING SCHEMATICS—PREDADOOR—TWO-SPEED DIGITAL GATEWAY (E4900) PREDADOOR—TWO-SPEED DIGITAL GATEWAY (E4900) MOTOR DATA 0.5/1.0 HP, 850/1750 RPM, 1.15 SF MOTOR VOLTAGE RECOMMENDED FUSE OVERLOAD RYTEC NO BRAKE 3.6/3.8 6 AMP 193-A1E1/193-A1E1 0-011-592/0-011-592 OLRH 3.2/3.4 6 AMP 193-A1E1/193-A1E1 0-011-592/0-011-592 1.6/1.7 3 AMP 193-A1D1/193-A1D1...
