Connecting the Set-Top

To connect your set-top to your entertainment devices, complete these steps.
Determine if your TV is HD or SD
and whether it is wide screen (16:9)
or standard screen (4:3). See page
1
11 for more information.
Make the connections for your TV as follows:
• If you are using an HDTV, see page 6 and the connection diagrams at the end of this guide.
• If you are using an SDTV, see page 7 and the connection diagrams at the end of this guide.
2
Identify the additional devices you will
connect to the set-top and TV. See the
3
Connection Diagrams section
of this guide.
Plug the set-top and the TV into an AC power source that is not controlled by a switch.
4
POWER
Do not turn on the set-top or TV yet.
5
Wait until the POWER LED on the front panel of the set-top stops blinking to indicate that
the update is complete.
6
Note: If the POWER LED blinks eight times, pauses then repeats, your set-top is not authorized.
Call your service provider.
To begin watching TV, turn the TV on, and press POWER on the front panel of the set-top
or on the remote control.
7
16
9
DVD
VCR
Home Theater
4
or
3
D-VCR
Other
5
