- Page 1 NETWORK 1275 Danner Dr Tel:330-562-7070 TECHNOLOGIES Aurora, OH 44202 Fax:330-562-1999 INCORPORATED www.networktechinc.com ® RACKMUX Series RACKMUX-VS17-T RACKMUX-DS17-T Rackmount Drawer with SUN Keyboard, LCD Monitor and Trackball Installation and Operation Manual MAN083 Rev Date 11/15/2007...
- Page 2 RACKMUX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright © 2007 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Features and Functions..............................2 Installation ..................................3 Rack Mounting Instructions ............................3 Optional Telco 2-Post Mounting ..........................4 Connect to a CPU................................ 4 Connect Extra Device ..............................5 Connect Power ................................6 Power Up ..................................6 Display Functions ................................ -
Page 4: Introduction
Rackmounting kit for two-post Telco rack - order RL-T15-TEL • RACKMUX drawer with DVI support, instead of VGA- order RACKMUX- DS 17 - T. • Numeric keypad option- for a separate 17-key numeric keypad, add “-N” to the part number (i.e. RACKMUX-VS17-T N ) -
Page 5: Features And Functions
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Compose Front View RACKMUX-VS17-T - or - (RACKMUX-VS17-T) (RACKMUX-DS17-T) Rear View RACKMUX-VS17-T FEATURES AND FUNCTIONS Power Button- press to turn the LCD monitor ON and OFF Power LED - Indicates operation status... -
Page 6: Installation
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE INSTALLATION Rack Mounting Instructions The RACKMUX was designed to be mounted to a rack and includes mounting flanges to make attachment easy. 1. Determine the mounting height in the rack for the drawer. -
Page 7: Optional Telco 2-Post Mounting
Figure 3- Mount to Telco post with optional mounting brackets Connect to a CPU The RACKMUX-VS17-T may be connected to a USB CPU with a VGA video port using the USB-AB-2M and VEXT-6-MM cables provided as shown in Fig. 4. -
Page 8: Connect Extra Device
Connect Extra Device On the front of the RACKMUX-VS17-T is an additional USB Type A port to be used, if desired, for an extra accessory. Any low or full speed USB device may be connected to this port to be used. -
Page 9: Connect Power
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Connect Power Connect the IEC power cord to the power port as shown below. REAR VIEW OF RACKMUX-VS17-T NETWORK TECHNOLOGIES INCORPORATED 1275 Danner Dr Tel:330-562-7070 Aurora, OH 44202 Fax:330-562-1999 www.networktechinc.com... -
Page 10: Display Functions
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE DISPLAY FUNCTIONS Standard Controls The RACKMUX has 5 standard control buttons and a power LED. The 5 standard control buttons operate as follows: • The Power button turns the RACKMUX LCD and backlight ON and OFF as desired. -
Page 11: Brightness/Contrast Menu
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Brightness/Contrast Menu Selecting the Brightness/Contrast menu will bring up a screen in which the user can adjust the brightness and contrast levels of the LCD display. With either the BRIGHTNESS or CONTRAST sections highlighted, (use the Up or Down arrow to move between them), press the Select button to choose the option to adjust. -
Page 12: Setup Menu
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Setup Menu Selecting the Setup menu will bring up a screen in which the user can adjust OSD POSITION-the position of the OSD menus on the LCD display OSD TIME-the length of time the user can be idle before the OSD menu automatically exits (adjustable from 10... -
Page 13: Keyboard Functions
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE KEYBOARD FUNCTIONS The main keyboard on the RACKMUX-VS17-T is a standard condensed Windows format. To reduce the keyboard size, some keys have been assigned multiple functions, accessible via the "Fn" key. -
Page 14: Number Pad
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Number Pad The functionality of a Number Pad on a standard Windows keyboard has been incorporated into this keyboard. To substitute the keys of the Number Pad The functionality of a Number Pad on a standard Windows keyboard has been incorporated into the keyboard of the RACKMUX-VS17-T (see Fig. -
Page 15: Other Functions Of The "Fn" Key
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Other Functions of the "Fn" Key The Function ("Fn") key (page10) will enable other standard keyboard features in addition to the Number Pad keys (page 11) . Key Function when Fn key is Key Function when Fn key is not locked ("Fn"... -
Page 16: Numeric Keypad Option
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Numeric Keypad Option Models with the Numeric Keypad option ( -N ) (i.e. RACKMUX-VS17-TN) have a standard Windows keyboard with 17-key numeric keypad. Note: The “Fn” key is not an active key on this keyboard. -
Page 17: Safety
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE SAFETY This NTI product has been designed and fully tested with user safety of the utmost importance. As with all electronic devices, this NTI product should be handled and operated with care. In order to avoid possible injury and to reduce any risk of damage to this product, please read and follow each of these safety instructions. -
Page 18: Rackmux-Vs17 Drawer Standard Specifications
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE RACKMUX-VS17 DRAWER STANDARD SPECIFICATIONS General Specs Case Material..........Electro-galvanized steel black powdercoated Dimensions WxDxH (in.).......19 x 21.9 x 1.75 Supported Rack Depths………………………..Adjustable 22” – 39” Weight……………………………………………26 lbs. Input Power............AC 100-240V, 50 – 60 Hz LCD (plus controller) Current Draw…………..12V Supply: 3.75A... -
Page 19: Keyboard
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE Keyboard No. Of Keys ...........83 Keys (US), 84 keys (UK,German, French, Italian, Spanish)+ 14 Sun keys Key Switch Type ..........Membrane switch Keytop Style...........Rectangular Cylindrical Operating Force ..........50gf +/- 25gf Stroke ............3.0mm +/- .5mm... -
Page 20: Troubleshooting
NTI RACKMUX-VS17-T RACKMOUNT LCD MONITOR WITH SUN KEYBOARD AND TRACKBALL MOUSE TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise.
