- Page 1 NETWORK 1275 Danner Dr TECHNOLOGIES Aurora, OH 44202 INCORPORATED RACKMUX-US17 (Formerly RACKMUX-SUN-USB-17) Rack Mount KVM Drawer with SUN USB Installation and Operation Manual Tel:330-562-7070 Fax:330-562-1999 www.nti1.com ® RACKMUX Series KEYBOARD MAN005 Rev Date 2/14/2005...
-
Page 2: Warranty Information
A return authorization number is required for all repairs/returns. COPYRIGHT Copyright © 2005 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. -
Page 3: Table Of Contents
INTRODUCTION... 1 Features... 1 Keyboard/Trackball... 1 Monitor... 1 Hosts... 1 Materials ... 1 FEATURES AND FUNCTIONS... 2 INSTALLATION... 3 Rack Mounting Instructions ... 3 Connect The Cables ... 3 TROUBLESHOOTING ... 3 TECHNICAL SPECIFICATIONS... 4 TABLE OF CONTENTS MAN005 Rev Date 2/14/2005... -
Page 4: Introduction
NTI RACKMUX RACKMOUNT KVM DRAWER WITH SUN USB KEYBOARD INTRODUCTION The RACKMUX-US17 (formerly referred to as RACKMUX-SUN-USB-17) Rack Mount KVM Drawer with SUN USB Keyboard (RACKMUX) provides convenient, space-saving control. Combining a SUN USB keyboard, 3-button trackball and 17" LCD monitor in a low 1RU (1.75") profile saves space in server-intensive applications. -
Page 5: Features And Functions
NTI RACKMUX RACKMOUNT KVM DRAWER WITH SUN USB KEYBOARD FEATURES AND FUNCTIONS LCD Display- For viewing video signal from video source Keyboard- For user interface with CPU or attached KVM switch Trackball w/ 3 Buttons- For user interface with CPU or attached KVM switch USB Cable-w/ male Type A connector- for connection of trackball and keyboard to CPU or attached KVM switch Video Cable- w/ male 15HD connector- for connection of monitor to video source Power supply- Cable for attachment of power... -
Page 6: Installation
Rack Mounting Instructions The NTI RACKMUX was designed to be mounted to a rack and includes mounting flanges to make attachment easy. Follow the instructions included for the Accuride Model 2907 Electronic Enclosure Slide to mount the RACKMUX. mounting screws securely. -
Page 7: Technical Specifications
NTI RACKMUX RACKMOUNT KVM DRAWER WITH SUN USB KEYBOARD TECHNICAL SPECIFICATIONS DESCRIPTION SPECIFICATION Dimensions WxDxH (Inches) 19 x 25.5 x 1.75 Weight 40 lbs Operating Temperature 0°C - 40°C (32°F - 104°F) Operating Humidity 80% Maximum Storage Temperature -20°C - 60°C (-4°F - 140°F) Storage Humidity 95% Maximum Pixel Frequency...
