Page 1: Console Switch
NETWORK 1275 Danner Dr TECHNOLOGIES Aurora, OH 44202 INCORPORATED RACKMUX-T15-RS16/8 Rack Mount Console Terminal Drawer with Installation and Operation Manual Tel:330-562-7070 Fax:330-562-1999 www.networktechinc.com ® RACKMUX Series Console Switch MAN081 Rev Date 2/7/2007... - Page 2 Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. CHANGES The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the right to make changes in the product design without reservation and without notification to its users.
-
Page 3: Table Of Contents
3.2.3 Port List screen... 28 3.2.4 User Terse mode ... 29 3.2.4.1 Terse mode commands... 29 3.2.5 Initialize SERIMUX Console Switch to default settings ... 30 4. USING THE TERMINAL ... 32 4.1 How To Setup The TERMINAL ... 32 4.1.1 Entering TERMINAL Setup... - Page 4 F7- FKeys SET-UP Definition Setup Menu ... 35 F8- Ansbk SET-UP Menu ... 36 F9- Lan Setup Menu ... 36 F10- Colr1 Set-up Menu ... 36 F11- Colr2 Set-up Menu ... 37 4.3 Local Keyboard Commands ... 40 4.4 TERMINAL Command Guide ... 41 4.4.1 Commands Supported in ASCII Personalities...
- Page 5 TABLE OF FIGURES Figure 1- Mount RACKMUX to rack ... 5 Figure 2- Distinction of connections between TERMINAL and SERIMUX ... 6 Figure 3- Connect serial devices, printer, and power supply ... 6 Figure 4- Connect to a Local Area Network (LAN)... 7 Figure 5- Fields in the Setup menu display which function keys to press for submenus ...
-
Page 6: Introduction
The LCD monitor terminal drawer eliminates the need for an external laptop or table-top dumb terminal. The Console Switch delivers control of up to 16 serial devices via Ethernet, LAN or dial-up modem connections. It enables unlimited access to remote network management, providing optimum system performance and availability. -
Page 7: Console Switch
The Console Switch (SERIMUX) is a serial port router that allows links (or connections) between multiple pairs of RS-232 asynchronous serial ports. The main purpose of the switch is to enable users to manage several serial devices from local or remote locations (using external modems). -
Page 8: Materials
CD and Quick Start Guide Materials Not Supplied, but REQUIRED: Serial cable with at least one RJ45 male end for connection to the Console Switch from each device to be connected. See Interconnection Cable Wiring Method on page 29 for cable pinout. -
Page 9: Features And Functions
13. Key Lock- to secure the keyboard in a closed position preventing unauthorized use 14. Auto Shut OFF Switch- automatically shuts OFF the LCD display when the monitor is folded down 15. 12VDC- Power Socket- for connection of 12VDC AC adapter 16. -
Page 10: Installation
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 1. INSTALLATION 1.1 Rack Mounting Instructions The RACKMUX was designed to be mounted to a rack and includes mounting flanges to make attachment easy. 1. Determine the mounting height in the rack for the drawer. -
Page 11: Terminal Vs. Serimux Cable Connections
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 1.2 TERMINAL vs. SERIMUX Cable Connections The connectors on the rear of the RACKMUX are split between those for the TERMINAL connections, and those for the SERIMUX connections (see Fig. 2). ETHERNE... -
Page 12: Connect The Serimux And Terminal To A Network
To control the SERIMUX and TERMINAL through a network connected PC, connect a CAT5 Ethernet network cable to the connector marked "ETHERNET". Then connect the other end of the Ethernet cable to a Local Area Network (LAN) through a 10/100 BaseT switch or hub. (See Fig. 4.) Ethernet cable... -
Page 13: Getting Started
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 2. GETTING STARTED Introduction This chapter covers basic configuration topics. Included is information on setting up the TERMINAL to control the SERIMUX. Using the instruction under “Setup The Terminal” below (or more detailed instruction on page 31), setup the TERMINAL to make connection to the SERIMUX. -
Page 14: F2- Genrl Setup Menu
"Port00" will be displayed (see Fig 6). By default, all ports are configured as Host ports and all are accessible. NOTE: If the user menu does not display re-initialize the SERIMUX following the "Initialize SERIMUX Console Switch to default settings"... -
Page 15: Figure 6- Startup- Accessible Host List
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH To connect to an attached CPU, enter the number of the port the CPU is connected to and press [Enter]. Figure 6- Startup- Accessible host list... -
Page 16: Using The Serimux Console Switch
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3. USING THE SERIMUX CONSOLE SWITCH The SERIMUX Console Switch is controlled using the TERMINAL and menu-driven integrated software. The SERIMUX can be easily configured using the TERMINAL with a keyboard-controlled menu to modify various parameters and options for each port to be connected to a device. -
Page 17: Administrator Controls
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.1 Administrator Controls 3.1 1 Login as the administrator The TERMINAL must first be configured (and is typically delivered preconfigured) as described on page 8 under "Getting Started”. Note: The administrator can only login from the TERMINAL connection (serially). Be sure that the Ethernet Mode is set to OFF (page 9) before trying to login as administrator. -
Page 18: Port List
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.1.2 Port List From the Administrator main menu, press [1] to display the Port List. Figure 8- The Port list displays the status of all ports The Port list displays the following information:... -
Page 19: Port Settings
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH FYI: RE: DscTime ( Disconnect Time) The value shown in the Port list is derived from various sources depending on the type of connection active at the time. - If a user is logged into a port as just a user, the time shown will be the remaining time based on the user's timeout setting. -
Page 20: Figure 10- Control Codes For In-Band Disconnect Sequence
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH From the Port settings menu, the configuration of each port can be viewed and changed. Setting Description Port name Change the port name Port type Host or User In-band disconnect Select characters to use for in-... -
Page 21: Port Serial Settings
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.1.3.1 Port serial settings From the "Port settings" menu, press [5] to display the "Port serial settings" menu. Using this menu, the administrator can adjust the serial settings of each port, or copy the current port serial settings and paste them to another port or to all ports. - Page 22 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Flow control None RTS/CTS (hardware) Xon/Xoff (software) Both disable flow control (not necessary) Consult your modem user manual or the modem AT command manual to find the suitable command. 3.1.3.1.6 Xon or Xoff Characters Any non-printable character (ASCII codes between 0 and 31) can be used as flow control Xon or Xoff character.
-
Page 23: Modem Settings
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.1.3.1.10 Copy Port Serial Settings – Press [+] to select the current port as source in a port settings copy-paste process (except port 0). – Then, press [*] to paste the port settings. -
Page 24: Port Data Buffer
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Display modem settings for different port number Press [>] (greater than symbol) to display the next port (next higher port index) modem settings, or press [<] (less than symbol) to display the previous port modem settings. -
Page 25: User List
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.1.4 User List From the administrator main menu, press [4] to display the User list. Column Heading Description User User Index number User Name User name associated with the index number User status- "Y" = enabled " -" = not enabled Displays if user has administrative rights "Y"... -
Page 26: User Settings
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.1.5 User Settings From the "Administrator main menu", press [5], enter the user index number, then press [Enter]. The screen will show the current user number and name and the user settings menu:... -
Page 27: Port Access
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Figure 16- Port access list for User 01 3.1.5.1 Port access To quickly grant/deny user access to multiple ports, the use of a dash (-) and/or comma may be used in conjunction with the [1] (to grant) or [0] (to deny) command. -
Page 28: Advanced Settings
For security purposes the administrator should change the factory default administrator password to a unique password. This will prevent unauthorized access to switch functions and CPUs. The password is needed to log in from any device, connected to any SERIMUX port in buffer mode. -
Page 29: Firmware
3.1.6.2.1 Load new firmware To upgrade the firmware that controls the Console Switch, as soon as improved versions become available, download the firmware file (from the NTI website at www.networktechinc.com) to a local CPU, and follow the instructions under "Firmware Upgrade"... -
Page 30: Figure 19- The Serimux Is Waiting To Save Its Firmware
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Figure 19- The SERIMUX is waiting to save its firmware Using the terminal program, configured for Xmodem protocol, receive the binary file (for example the HyperTerminal for Windows Transfer -> Receive File command) to transfer the SERIMUX firmware to a binary file. -
Page 31: User Controls
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.2. User Controls Users can connect only to accessible ports as defined by the administrator. A list of those ports will be displayed with a successful login. Connection can be made using the TERMINAL, or a serial terminal with an emulator (e.g. Windows HyperTerminal) connected to the SERIMUX at an allowed user port To login, press the [Spacebar] or [Enter] key. -
Page 32: User Main Menu
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.2.2 User main menu The User main menu includes: • user index number and name • index number and name of the login port • user command list From the "User main menu" the following functions are possible:... -
Page 33: Port List Screen
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.2.3 Port List screen From the "User main menu", press [3] to display the list of user accessible ports and information about these ports. Only the administrator can change the communication settings. -
Page 34: User Terse Mode
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 3.2.4 User Terse mode This mode is especially useful when the SERIMUX is directly controlled by external software from a serial console (as a user without administrative privileges), rather than being controlled by a user from a keyboard interface. -
Page 35: Initialize Serimux Console Switch To Default Settings
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Verbose mode Send or type in: [V] [Enter] The answer will be: OK [CR][LF] and the Terse mode will be terminated. The “Accessible host list” or the “User main menu” will be displayed. -
Page 36: Table 2- Serimux Port Characteristics
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Every port is defined through the following parameters: Table 2- SERIMUX Port Characteristics Description Number Name Type – port 0 Type – except port 0 Baud rate – port 0 Baud rate – except port 0 Data bits per character –... -
Page 37: Using The Terminal
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4. USING THE TERMINAL 4.1 How To Setup The TERMINAL The TERMINAL is compatible with most CPUs and application packages. A menu driven setup system is provided to select and save the settings required by the CPU and application. To control the CPU, or in this case the SERIMUX, a user must be familiar with the requirements of the SERIMUX in order to setup the TERMINAL. -
Page 38: Changing The Terminal Operating Parameters
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.2 Changing The TERMINAL Operating Parameters To select one of the setup menus shown, press the indicated function key. - The screen for that menu appears with the name highlighted. - The fields at the middle of the screen indicate the parameters that can be changed in that menu. -
Page 39: F3- Keybd Setup Menu
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Monitor causes the terminal to display symbols for escape sequences and control codes without acting on them (test feature). Status Line sets the top line of the screen as the status line. -
Page 40: F5- Misc Setup Menu
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Multiple Sessions defines whether an Ethernet connection supports multiple sessions function. ON : indicates the terminal supports multiple sessions. Each session only has one display page. In 80 or 132 column mode, 8 simultaneous sessions are supported. -
Page 41: F8- Ansbk Set-Up Menu
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 4- Programmable Keys Enhanced PC-Style Keyboard Enhanced PC-Style Keyboard F1 through F12 ENTER (Both ENTER keys are programmable) (UP ARROW) ESCAPE (DOWN ARROW) HOME (LEFT ARROW) INSERT (RIGHT ARROW) PAGE DOWN... -
Page 42: F11- Colr2 Set-Up Menu
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH F11- Colr2 Set-up Menu The color functionality differs with emulation. In general VT100, VT220 and ANSI Console work with applications, which control the color directly. The remaining personalities associate colors based on existing monochrome video attributes. This section will define parameter selection based on personality selected. -
Page 43: Table 6- Color Palettes
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 6- Color Palettes Palette Display Attribute Normal Reverse (or blank) Intensity Intensity and reverse (or blank) Underline Underline and reverse(or blank) Underline and intensity Underline, intensity, Normal Reverse (or blank) Intensity... - Page 44 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 6- Color Palettes (Cont'd) Palette Display Attribute Normal Reverse (or blank) Intensity Intensity and reverse (or blank) Underline Underline and reverse (or blank) Underline and intensity Underline, intensity, Normal Reverse (or blank)
-
Page 45: Local Keyboard Commands
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.3 Local Keyboard Commands Table 7 lists local keyboard commands in the terminal's native mode. Table 7- Local Keyboard Commands in Native Mode Key Sequence by keyboard Style Command Toggle CAPS LOCK on/off... -
Page 46: Terminal Command Guide
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.4 TERMINAL Command Guide 4.4.1 Commands Supported in ASCII Personalities Table 8 lists all the ASCII commands recognized by the terminal. The native mode code for the command is given in the second column. - Page 47 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 8- Commands Supported in ASCII Personalities (Cont'd) ----------------------------------------------------------------------------------------------------------------------------------------------------------- Command ------------------------------------------------------------------------------------------------------------------- Native FUNCTION Mode ------------------------------------------------------------------------------------------------------------------------------------------------------------------- ACK mode off ESC e 6 ACK mode on ESC e 7 Full-duplex mode on ESC C ESC D F...
- Page 48 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 8- Commands Supported in ASCII Personalities (Cont'd) ----------------------------------------------------------------------------------------------------------------------------------------------------------- Command -------------------------------------------------------------------------------------------------------------------- Native FUNCTION Mode -------------------------------------------------------------------------------------------------------------------------------------------------------------------- Program function key definition ESC z fkey sequence DEL Program key direction and ESC Z dir definition...
- Page 49 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 8- Commands Supported in ASCII Personalities (Cont'd) ----------------------------------------------------------------------------------------------------------------------------------------------------------- Command -------------------------------------------------------------------------------------------------------------------- Native FUNCTION Mode -------------------------------------------------------------------------------------------------------------------------------------------------------------------- Display Memory/Split Screen Divide memory into pages ESC w length Display previous page ESC w B or ESC J...
- Page 50 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 8- Commands Supported in ASCII Personalities (Cont'd) ----------------------------------------------------------------------------------------------------------------------------------------------------------- Command -------------------------------------------------------------------------------------------------------------------- Native FUNCTION Mode -------------------------------------------------------------------------------------------------------------------------------------------------------------------- Graphics Characters Graphics mode on ESC H Graphics mode off ESC H Display graphics character ESC H ldraw...
- Page 51 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 8- Commands Supported in ASCII Personalities (Cont'd) ----------------------------------------------------------------------------------------------------------------------------------------------------------- Command -------------------------------------------------------------------------------------------------------------------- Native FUNCTION Mode -------------------------------------------------------------------------------------------------------------------------------------------------------------------- Editing (Cont'd) Insert line of spaces ESC E Delete cursor character ESC W Delete cursor line ESC R...
- Page 52 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH Table 8- Commands Supported in ASCII Personalities (Cont'd) --------------------------------------------------------------------------------------------------------------------------------------------------- Command -------------------------------------------------------------------------------------------------------------------- Native FUNCTION Mode -------------------------------------------------------------------------------------------------------------------------------------------------------------------- Print Functions Print formatted page ESC P Print formatted unprotected page ESC @ Print unformatted page ESC p or ESC L...
-
Page 53: Variable Values For Table 8 Commands
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 5.4.2 Variable Values for Table 8 Commands answer Up to 20 characters to define answerback message attr Display Attributes SPACE Space character Normal Blank Blink Blink and Blank Reverse Reverse and invisible... - Page 54 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ----------------------------------------------------------------------------------------------------------------------------------------------------- Variable Values for Table 8 Commands (Cont'd) ------------------------------------------------------------------------------------------------------------------------------------------------------ fcolor Foreground Color Black Blue Green Cyan field field Unshifted shifted Function fkey fkey Unshifted Shifted hndshk Handshaking Protocol Receive None (default) XON/XOFF...
- Page 55 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Variable Values for Table 8 Commands (Cont'd) ------------------------------------------------------------------------------------------------------------------------------------------------------ length Multiple Length of Page 1xlines Equal to the number of data lines 2xlines Double the number of data lines 4xlines Four times the number of data lines *b Available only in WY-50+ personality.
- Page 56 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Variable Values for Table 8 Commands (Cont'd) ------------------------------------------------------------------------------------------------------------------------------------------------------ Function Key Direction Remote Local Normal ------------------------------------------------------------------------------------------------------------------------------------------------------ page Page page 0 In the 80 columns mode: There have 4 pages of display memory.
-
Page 57: Ansi Command Guide
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Variable Values for Table 8 Commands (Cont'd) ------------------------------------------------------------------------------------------------------------------------------------------------------ wnd/page Window or Page Page 0 or upper window Page 1 or lower window word Data Word 7 bits 8 bits wpca Write-Protected Display Attribute... -
Page 58: Table 9 -Supported Vt100,Vt220 And Console Ansi Commands
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Table 9- Supported VT100, VT220 and Console ANSI Commands, Cont'd ------------------------------------------------------------------------------------------------------------------------------------------------------ Command ---------------------------------------------------------------------- FUNCTION ------------------------------------------------------------------------------------------------------------------------------------------------------ 132-column display 80-column display Smooth scrolling on Jump scrolling on Reverse screen video on Normal screen video on... - Page 59 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Table 9- Supported VT100, VT220 and Console ANSI Commands, Cont'd ------------------------------------------------------------------------------------------------------------------------------------------------------ final Final character Designating UK ANSI character set Designating ASCII character set Designating DEC special graphics * DSCS can consist of zero, one or two intermediate character and a final character. Intermediate characters are in the range of 2/0 to 2/15.
- Page 60 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Table 9- Supported VT100, VT220 and Console ANSI Commands, Cont'd ------------------------------------------------------------------------------------------------------------------------------------------------------ FUNCTION ------------------------------------------------------------------------------------------------------------------------------------------------------ Color Color Black Blue Magenta Green Brown Cyan White Access alternate graphic set Define erasable character Define non-erasable character...
- Page 61 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Table 9- Supported VT100, VT220 and Console ANSI Commands, Cont'd ------------------------------------------------------------------------------------------------------------------------------------------------------ FUNCTION ------------------------------------------------------------------------------------------------------------------------------------------------------ Editing Functions (Cont'd) Erase erasable characters from start of display to cursor Erase erasable characters in entire display...
- Page 62 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Table 9- Supported VT100, VT220 and Console ANSI Commands, Cont'd ------------------------------------------------------------------------------------------------------------------------------------------------------ FUNCTION ------------------------------------------------------------------------------------------------------------------------------------------------------ Program function keys 1. VT100 mode (cont'd): Unshifted function key hc Hexadecimal representation of character string assigned to the function key.
- Page 63 NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Table 9- Supported VT100, VT220 and Console ANSI Commands, Cont'd ------------------------------------------------------------------------------------------------------------------------------------------------------ FUNCTION ------------------------------------------------------------------------------------------------------------------------------------------------------ Transmission/Printer Control Transmit through cursor position Transmit to end of line or end of display Send form feed after print screen operation...
-
Page 64: Vt52 Command Guide
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH ------------------------------------------------------------------------------------------------------------------------------------------------------ Table 9- Supported VT100, VT220 and Console ANSI Commands, Cont'd ------------------------------------------------------------------------------------------------------------------------------------------------------ FUNCTION ------------------------------------------------------------------------------------------------------------------------------------------------------ Request keyboard status report Respond with keyboard language Keyboard Language U. S. U. K. Danish German French ------------------------------------------------------------------------------------------------------------------------------------------------------ *1. -
Page 65: Using Printer Server Via Ethernet Connection
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.6 Using Printer Server via Ethernet Connection Introduction In order to send print jobs to a network-based printer, the Ethernet Print Terminal function in the TERMINAL must be used. To use this function, the Telnet Terminal communication option described on page 1 is available. For this option to work, an Ethernet cable must be connected as described on page 6. -
Page 66: Setup For Lpd
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.6.2 Setup for LPD Follow those steps from step 1 to step 2 described in Basic Setup. The following steps are dependent on the operating system. Please refer to the UNIX administration guide. The following illustrated steps are under BSD system. -
Page 67: Lpd Printing
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.6.3 LPD printing LPD protocol is built-in to most of the UNIX system. However, detailed implementation of LPD differs among UNIX systems. Please refer to the UNIX administration guide for reference. The following illustrated printing command is under BSD system or System V version. -
Page 68: On-Screen Display (Osd)
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.7 On-Screen Display (OSD) 4.7.1 Standard Controls The RACKMUX LCD has 5 standard control buttons and a power LED. The 5 standard control buttons operate as follows: • The Power button turns the RACKMUX LCD and backlight ON and OFF as desired. -
Page 69: Brightness/Contrast Menu
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.7.2.2 Brightness/Contrast Menu Selecting the Brightness/Contrast menu will bring up a screen in which the user can adjust the brightness and contrast levels of the LCD display. With either the BRIGHTNESS or CONTRAST sections highlighted, (use the Up or Down arrow to move between them), press the Select button to choose the option to adjust. -
Page 70: Setup Menu
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.7.2.5 Setup Menu Selecting the Setup menu will bring up a screen in which the user can adjust OSD POSITION-the position of the OSD menus on the LCD display OSD TIME-the length of time the user can be idle before the OSD menu automatically exits (adjustable from 10... -
Page 71: Keyboard Functions
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.8 Keyboard Functions The keyboard on the RACKMUX has a standard condensed Windows format. To reduce the keyboard size, some keys have been assigned multiple functions, accessible via the "Fn" key. and how to enable them. -
Page 72: Number Pad
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 4.8.1 Number Pad The functionality of a Number Pad on a standard Windows keyboard has been incorporated into this keyboard. To substitute the keys of the Number Pad Press the "NumLock" key. -
Page 73: Hardware Information
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 5. HARDWARE INFORMATION Introduction This chapter provides information on hardware specifications, pinouts for the Ethernet cable, pinouts for port connectors, and pinouts for the cable adapters. 5.1 Hardware Specifications: TERMINAL Physical Size (In.) WxDxH 19x18.4x1.75... -
Page 74: Cpu-To-Rackmux Ethernet Crossover Cable
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 5.3 CPU-to-RACKMUX Ethernet Crossover Cable In order to make a direct connection between a CPU and the ETHERNET connector of the RACKMUX, a crossover cable must be used. The cable is made with CAT5 cable terminated with RJ45 connectors and wired according to the chart below. -
Page 75: Cable Adapters
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 5.6 Cable Adapters The SERIMUX comes with four cable adapters. The following illustrations show cable adapter pin outs. Additional adapters can be purchased from NTI. DB-25 Male Console Adapter (NTI P/N DB25M-RJ45F-T) -
Page 76: Serimux Ethernet Pinouts
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH DB-25 Female Console Adapter (NTI P/N DB25F-RJ45F) DB-25 Female to RJ45 Pin Assignments RJ45 Signal Connected to Connected to Connected to Connected to Connected to Connected to Connected to DB-25 Male Modem Adapter (NTI P/N DB25M-RJ45F-C) -
Page 77: Terminal Connector Pin Assignments
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 5.8 TERMINAL Connector Pin Assignments Serial Port (Serial 2) Connector Pin Assignments (RS232C 9-pin connector) Signal Data carrier detect Receive data Transmit data Data terminal ready Signal ground Data set ready Request to send... -
Page 78: Dimensional Drawings
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH 5.9 Dimensional Drawings 2 1 .9 IN . PARALLEL SERIAL ETHERNET 12VDC CONNECTOR RJ45 SERIAL DEVICE CONNECTORS Rear View of RACKMUX-T15-RS16 Overhead View of RACKMUX-T15-RS16 Keyboard Wristpad 1 9 .0 0 IN . -
Page 79: Index
NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH INDEX access to ports, 22 Administrator password, 23 ASCII commands, 41 BSD UNIX system, 62 cable adapters, 70 cabling, 69 change administrator password, 23 Configure the terminal, 8 connect to SERIMUX. connectors, 6...
