Network Receiver
M-CR510
You can print more than one page of a PDF onto a single sheet of paper.
Owner's Manual
Front panel
Rear panel
Remote
Index

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-CR510 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marantz M-CR510

  • Page 1 Contents Connections Playback Settings Tips Appendix Network Receiver M-CR510 You can print more than one page of a PDF onto a single sheet of paper. Owner’s Manual Front panel Rear panel Remote Index...
  • Page 2: Table Of Contents

    Contents Connections Playback Settings Tips Appendix Contents Playback Accessories ························································································ 5 Inserting the batteries ······································································ 6 Basic operation ·············································································· 25 Operating range of the remote control unit ····································· 6 Turning the power on ····································································· 25 Features ······························································································ 7 Selecting the input source ····························································· 25 Multiple music formats are supported, all in a compact form factor ···7 Adjusting the master volume ·························································...
  • Page 3 Contents Connections Playback Settings Tips Appendix Settings Playing iPod ···················································································· 42 Listening to music on an iPod ························································ 43 Menu map Setting operation mode (Remote iPod Mode) ······························· 44 ························································································ 62 Charging the iPod ··········································································· 45 Menu operation ·············································································· 64 Playing a USB memory device Inputting characters ··················································...
  • Page 4 Contents Connections Playback Settings Tips Appendix Tips Contents ··························································································· 75 Tips ································································································· 76 Troubleshooting ············································································· 77 Resetting factory settings ··························································· 87 Appendix Playing back USB memory devices ·············································· 88 Playing back Internet Radio ··························································· 89 Playing back files stored on PC or NAS ·······································...
  • Page 5: Accessories

    Settings Tips Appendix Thank you for purchasing this Marantz product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading this manual, be sure to keep it for future reference. Accessories Check that the following parts are supplied with the product.
  • Page 6: Inserting The Batteries

    Contents Connections Playback Settings Tips Appendix Inserting the batteries Operating range of the remote control unit q Remove the rear lid in the direction of the arrow and remove it. Point the remote control unit at the remote sensor when operating it. w Load the two batteries properly as R03/AAA Approx.
  • Page 7: Features

    Android z smartphone • DLNA ver. 1.5 support for audio networks “Marantz Remote App” is application software that allows you to perform basic operations with an iPad, iPhone, Android smartphone or • Supports online music, including Last.fm, Spotify Android tablet such as turning the unit ON/OFF, controlling the volume, and switching the source.
  • Page 8: Front Panel

    Contents Connections Playback Settings Tips Appendix Part names and functions Front panel Front panel Rear panel Remote Index...
  • Page 9 Contents Connections Playback Settings Tips Appendix Q2 Q1 Headphones jack (PHONES) Used to connect headphones. When the headphones are plugged into this jack, audio will no longer be output from the connected speakers. NOTE • To prevent hearing loss, do not raise the volume level excessively when using headphones.
  • Page 10: Rear Panel

    Contents Connections Playback Settings Tips Appendix Rear panel Front panel Rear panel Remote Index...
  • Page 11 Contents Connections Playback Settings Tips Appendix USB port (Rear) Used to connect iPod or USB memory devices (vpage 19). DIGITAL IN connector Used to connect devices equipped with digital audio connector (vpage 18). Wi-Fi CONNECT button Used to connect to the wireless LAN. (See the separate “Quick Setup Guide”.) AC inlet (AC IN) Used to connect the power cord (vpage 23).
  • Page 12: Remote Control Unit

    Contents Connections Playback Settings Tips Appendix Remote control unit Remote control signal transmitter This transmits signals from the remote control unit (vpage 6). CLOCK button The current time appear on the unit (vpage 67). SLEEP button This sets the sleep timer (vpage 61). Input source select buttons These select the input source (vpage 25).
  • Page 13 Contents Connections Playback Settings Tips Appendix FAVORITES ADD / CALL buttons • To add radio stations or files to the favorite list, press ADD. • To call up a radio station or file registered in the favorite list, press CALL (vpage 40). TOP MENU button To back to the top of the menu (vpage 64).
  • Page 14 Contents Connections Playback Settings Tips Appendix DBB/TONE button Adjusting the tone (vpage 60). VOLUME buttons (df) These adjust the volume level (vpage 26). Information button (INFO) This switches display items such as the album name and title name in the playback screen (vpage 32, 34, 44, 46). SETUP button This displays the setup menu on the display (vpage 64).
  • Page 15: Cables Used For Connections

    Contents Connections Playback Settings Tips Appendix Connections 2 Cables used for connections Speaker connection (vpage 16) Provide necessary cables according to the devices you want to connect. Connecting an analog device (vpage 18) Speaker cable Connecting a digital device (vpage 18) Connecting an iPod or USB memory device to the USB Subwoofer cable port (vpage 19) Optical cable...
  • Page 16: Speaker Connection

    Contents Connections Playback Settings Tips Appendix Speaker connection Here we connect the speakers in the room to this unit. Connecting the speaker cables This section explains how to connect them using typical examples. Carefully check the left (L) and right (R) channels and + (red) and – (black) NOTE polarities on the speakers being connected to this unit, and be sure to • Disconnect this unit’s power plug from the power outlet before connecting the...
  • Page 17: Connection The Subwoofer

    Contents Connections Playback Settings Tips Appendix Connection the subwoofer Speaker connection Use a subwoofer cable to connect the subwoofer. Front panel Rear panel Remote Index...
  • Page 18: Connecting An Analog Device

    Contents Connections Playback Settings Tips Appendix Connecting an analog device Connecting a digital device Analog Digital device device AUDIO AUDIO OPTICAL AUDIO Front panel Rear panel Remote Index...
  • Page 19: Connecting An Ipod Or Usb Memory Device To The Usb Port

    Front Rear device • Marantz does not guarantee that all USB memory devices will operate or receive power. When using a portable USB hard disk drive (HDD) which came with an AC adapter, use that device’s supplied AC adapter. NOTE • USB memory devices will not work via a USB hub.
  • Page 20 Contents Connections Playback Settings Tips Appendix 2 Supported iPod / iPhone models • iPod classic • iPod nano • iPod touch • iPhone Front panel Rear panel Remote Index...
  • Page 21: Connecting To A Home Network (Lan)

    Contents Connections Playback Settings Tips Appendix Connecting to a home network (LAN) You can connect this unit to your home network (LAN) to perform various Wired LAN types of playbacks and operations as follows. • Playback of network audio such as Internet Radio and from your media server(s) (Network Attached • Playback of music content from online streaming services...
  • Page 22: Wireless Lan

    Contents Connections Playback Settings Tips Appendix Wireless LAN • With this unit, it is possible to use the DHCP and Auto IP functions to make the network settings automatically. • When using this unit with the broadband router’s DHCP function enabled, this unit automatically performs the IP address setting and other settings.
  • Page 23: Connecting The Power Cord

    Contents Connections Playback Settings Tips Appendix Connecting the power cord After completing all the connections, insert the power plug into the power outlet. Power cord (supplied) To household power outlet (AC 230 V, 50/60 Hz) Front panel Rear panel Remote Index...
  • Page 24 Contents Connections Playback Settings Tips Appendix Playback Turning the power on (vpage 25) Playing a USB memory device (vpage 46) Selecting the input source (vpage 25) Listening to ANALOG IN (vpage 48) Listening to DIGITAL IN (vpage 48) Adjusting the master volume (vpage 26) Turning off the sound temporarily (vpage 26) AirPlay function (vpage 49) Listening to Internet Radio (vpage 27) Remote play function (vpage 52)
  • Page 25: Basic Operation

    Contents Connections Playback Settings Tips Appendix Basic operation Turning the power on POWER X Press POWER X to turn on power to the unit. Input source select buttons • You can also switch the power to standby by pressing on the main unit. Selecting the input source Press the input source select button to be played back.
  • Page 26: Adjusting The Master Volume

    Contents Connections Playback Settings Tips Appendix Adjusting the master volume Use VOLUME df to adjust the volume. The volume level is displayed. • You can also adjust the master volume by turning VOLUME df on the main unit. Turning off the sound temporarily Press MUTE The “MUTING”...
  • Page 27: Listening To Internet Radio

    Contents Connections Playback Settings Tips Appendix Listening to Internet Radio • Internet Radio refers to radio broadcasts distributed over the Internet. Internet Radio stations from around the world can be received. • The broad cast station types and specifications supported by this unit for INTERNET playback are as follows.
  • Page 28: Listening To Internet Radio

    Contents Connections Playback Settings Tips Appendix Listening to Internet Radio Recently Played : • Displays recently played Internet Radio stations. Up to 20 stations This unit memorizes the last played Internet Radio station. If you press can be stored in “Recently Played”. INTERNET RADIO to switch to the Internet Radio function from another Search by Keyword : input source, the last Internet Radio station you listened to is played.
  • Page 29: Playing The Last Played Internet Radio Station

    Contents Connections Playback Settings Tips Appendix Playing the last played Internet Radio Enter the MAC address of this unit, then click “Go”. station Enter your E-mail address and a password of your choice. Press INTERNET RADIO. The source switches to “Internet Radio” and the last played radio Select the search criteria (genre, region, language, etc.) station plays.
  • Page 30: Playing Back Files Stored On A Pc And Nas

    Contents Connections Playback Settings Tips Appendix Playing back files stored on a PC and NAS • This unit can play back music files and playlists (m3u, wpl) stored on a PC and on Network Attached Storage (NAS) that supports DLNA. • The network audio playback function of this unit connects to the server using technologies shown below.
  • Page 31: Applying Media Sharing Settings

    Select “More streaming options...” in the “Stream”. Click the “Share my media” check box, select Select “Allowed” in the drop-down list for “M-CR510”. “M-CR510”, and then click “Allow”. As you did in step 3, select the icon of the device (other Select “Allowed”...
  • Page 32: Playing Back Files Stored On A Pc And Nas

    Contents Connections Playback Settings Tips Appendix Playing back files stored on a PC and Operation buttons Function Playback / Pause (Press and hold) Stop Use this procedure to play music files or playlists. Previous / Next Prepare for playback. (Press and hold) q Check the network environment, then turn on this unit’s power Fast-reverse / Fast-forward (vpage 21 “Connecting to a home network (LAN)”).
  • Page 33 Contents Connections Playback Settings Tips Appendix • WMA Lossless files can be played when using a server supporting transcoding, such as Windows Media Player Ver. 11 or later. NOTE • When playing back music files with your PC or NAS connected through wireless LAN, audio may be interrupted depending on your wireless LAN environment.
  • Page 34: Listening To Last.fm

    Listening to Last.fm • Last.fm learns what you love... and it’s a great way to discover new music. Your new Marantz Network Receiver is very clever. You can create a free ONLINE Last.fm profile when you start using your Marantz Network Receiver and magically keep track of all the songs you hear.
  • Page 35: Listening To Last.fm

    Contents Connections Playback Settings Tips Appendix Listening to Last.fm Use ui to select menu and then press ENTER. Prepare for playback. Popular Stations : • Check the network environment, then turn on this unit’s power • Play popular artists and tags in your area. (vpage 21 “Connecting to a home network (LAN)”).
  • Page 36 Contents Connections Playback Settings Tips Appendix Log Out Use ui to select a station, and press ENTER to start playback. Disassociate this unit from your Last.fm account. Playback starts. While the Last.fm top menu is displayed, use ui to When you press p during playback, the following menu select “Log Out”, then press ENTER.
  • Page 37: Listening To Spotify

    Tips Appendix Listening to Spotify Introduce your Marantz Network Receiver to a whole new world of music. With Spotify, you can enjoy instant access to millions of songs. A Spotify Premium subscription is required. For details, see the Spotify homepage.
  • Page 38 Contents Connections Playback Settings Tips Appendix Input “Username” and “Password”. Use ui to select menu and then press ENTER. • For character input, see page 65. Search : The types of characters that can be input are as shown below. • Searches for tracks, artists and albums by entering keywords. GLower case charactersH What’s New : abcdefghijklmnopqrstuvwxyz...
  • Page 39 Contents Connections Playback Settings Tips Appendix Operation buttons Function When you press p during playback, the following menu Playback / Pause appears. (Press and hold) Star this track : Stop • Adds a star to the selected track. Previous / Next Unstar this track : (Press and hold) • Unregister a star to the selected track.
  • Page 40: Favorite Function

    Contents Connections Playback Settings Tips Appendix Favorite function This section provides information on the Favorite function. • The Favorite function allows you to register your favorite broadcast stations and files in the Favorite List in advance so that you can call and listen to the stations or files right away, whenever you want.
  • Page 41: Registering Stations Or Files To The Favorites List

    Contents Connections Playback Settings Tips Appendix Registering stations or files to the Deleting stations or files from the favorites list favorite list Press FAVORITES ADD while the Internet radio station Press FAVORITES CALL. or file to register is played back. Use ui to select the station or file that you want to Use ui to select a number to register the station or file, delete, and press CLEAR.
  • Page 42: Playing Ipod

    Contents Connections Playback Settings Tips Appendix Playing iPod • You can use the USB cable provided with the iPod to connect the iPod with the unit's Front and Rear USB port and enjoy music stored on the iPod. • For information on the iPod models that can be played back with this FRONT USB unit, see “Supported iPod / iPhone models”...
  • Page 43: Listening To Music On An Ipod

    Operate iPod itself directly while seeing the iPod screen • Note that Marantz will accept no responsibility whatsoever for any problems arising to play back music. with the data on an iPod when using this unit in conjunction with the iPod.
  • Page 44: Setting Operation Mode (Remote Ipod Mode)

    NOTE Active (This unit) buttons • Marantz will accept no responsibility whatsoever for any loss of iPod data. • Depending on the type of iPod and the software version, some functions may not iPod operate. z Only the sound is played.
  • Page 45: Charging The Ipod

    Contents Connections Playback Settings Tips Appendix Charging the iPod You can charge your iPhone/iPod by connecting it to USB port. 2 Standby charging If the unit enters power standby mode while the iPhone/iPod is charging, the unit will switch to standby charging mode, and the iPhone/iPod will continue to be charged.
  • Page 46: Playing A Usb Memory Device

    Contents Connections Playback Settings Tips Appendix Playing a USB memory device • Playing back music stored on a USB memory device. • Only USB memory devices conforming to mass storage class and MTP (Media Transfer Protocol) standards can be played on this unit. • This unit is compatible with USB memory devices in “FAT16”...
  • Page 47: Playing Files Stored On Usb Memory Devices

    This function is available while an MP3 / WAV / AAC / FLAC file is being played back. NOTE • Note that Marantz will accept no responsibility whatsoever for any problems arising with the data on a USB memory device when using this unit in conjunction with the USB memory device.
  • Page 48: Listening To Analog In

    Contents Connections Playback Settings Tips Appendix Listening to ANALOG IN Prepare for playback. Check the connection, then turn on this units. Press AUX to select “Analog In”. Play the component connected to this unit. Listening to DIGITAL IN Prepare for playback. Check the connection, then turn on this units.
  • Page 49: Airplay Function

    • For details, see your device’s manual. Router Startup iPhone, iPod touch, or iPad music. is displayed on the iPhone, iPod touch or iPad screen. Tap the AirPlay icon '. Select the speaker you want to use. Marantz M-CR510 Cancel Front panel Rear panel Remote Index...
  • Page 50: Playing Itunes Music With This Unit

    Launch iTunes and click the AirPlay icon ' displayed the window and select this unit from the list. My Computer Marantz M-CR510 NOTE Choose a song and click play in iTunes. • In playback using the AirPlay function, the sound is output at the iPhone, iPod The music will stream to this unit.
  • Page 51: Of This Unit

    Contents Connections Playback Settings Tips Appendix Perform iTunes playback operations Devices Preferences with the remote control unit of this unit General Playback Sharing Store Parental Devices Advanced With this unit’s remote control unit, you can perform iTunes song play, Device backups: pause, and auto search (cue) operations.
  • Page 52: Remote Play Function

    • For some mobile phones, you must install an application for DLNA music playback. (Digital Media • Portable audio player DMC can also play back Controller) • Marantz Remote music files stored on these devices. • PC Stores music files. • NAS Music files stored on these...
  • Page 53: Settings Required For Each Device

    DMS and this unit (DMR) with your mobile phone. The applicable application differs according to your • The default friendly name of this unit is “Marantz M-CR510”. mobile phone. Start playing back a music file on DMC.
  • Page 54: Web Control Function

    Contents Connections Playback Settings Tips Appendix Web control function You can control this unit from a web control screen on a web browser. Controlling the unit from a web control Switch the “Network Control” (vpage  71) setting to “On”. Check the IP address of this unit with “Network Information”...
  • Page 55 Contents Connections Playback Settings Tips Appendix Enter the IP address of this unit in browser’s address When the top menu is displayed, click on the menu item box. you want to operate. For example, if the IP address of this unit is “192.168.0.2”, enter “http://192.168.0.2”.
  • Page 56 GExample 1H Network Setting 1 GExample 2H Network Setting 2 NETWORK NETWORK NETWORK NETWORK FIRMWARE FIRMWARE Friendly Name Friendly Name Marantz M-CR510 Set Default Marantz M-CR510 Set Default Network Connection Network Connection Select Connection Select Connection Select Connection Wi-Fi [+]DHCP or Proxy...
  • Page 57 Contents Connections Playback Settings Tips Appendix 2 Update on web screen n Network connection settings Firmware can be updated using the “Web control function” Q0 Various items will be displayed if you selected “Wi-Fi” in (vpage 54). Example 1. Select or input items as necessary, and then click “Web control function”...
  • Page 58 Contents Connections Playback Settings Tips Appendix When the following screen is displayed by the PC, click When the following screen is displayed, updating is the “Choose File” (q) button, select the update file, and complete. click the “Upload” (w) button. Firmware Firmware New Firmware:...
  • Page 59: Other Functions

    Contents Connections Playback Settings Tips Appendix Other functions Adjusting the tone (vpage 60) SLEEP DIMMER Sleep timer function (vpage 61) CLOCK Checking the current time (vpage 61) Switching the display’s brightness (vpage 61) DBB/ TONE uio p ENTER SETUP Front panel Rear panel Remote Index...
  • Page 60: Adjusting The Tone

    Contents Connections Playback Settings Tips Appendix Adjusting the tone n Treble Adjusts the treble sound. –10dB – +10dB (Default : 0dB) Press DBB/TONE to select the tone parameter to be adjusted. n Balance Use ui to adjust the “Dynamic Bass Boost”, “Bass”, Use o p to adjust the left/right volume balance.
  • Page 61: Sleep Timer Function

    Contents Connections Playback Settings Tips Appendix Sleep timer function Checking the current time You can have the power automatically switched to standby once a set 2 Checking the current time when the power is time has elapsed. This is convenient for listening while going to sleep. Press SLEEP and display the time you want to set.
  • Page 62: Menu Map

    Sets the unit power to standby when the unit is not in use. Firmware Set whether or not to check for firmware update, update the firmware, and display update and upgrade notifications. Update Update the firmware of Marantz Network Receiver. Notifications Set the Update, Upgrade and Alerts notification on/off. Add New Feature Display new features that can be downloaded to this unit and perform an upgrade.
  • Page 63 Contents Connections Playback Settings Tips Appendix 2 Network Setting items Description Page Network Information Displays various information about the network. Network Control Performs the ON/OFF settings for the network function when in standby mode. Friendly Name Edits a name displayed on the Internet. Last.fm Display Disables the display of Last.fm on the menu.
  • Page 64: Menu Operation

    Contents Connections Playback Settings Tips Appendix Menu operation Press SETUP. The menu is displayed. Use uio p to select the menu to be set or operated, then press ENTER. Use ui to change to desired setting. Press ENTER to enter the setting. • To return to the previous item, press o.
  • Page 65: Inputting Characters

    Contents Connections Playback Settings Tips Appendix Inputting characters On this unit, you can change the name displayed on the following menu to the names that you prefer. • Character Search (vpage 28, 32, 47) • Friendly Name (vpage 71) • Character input for the network functions (vpage 28, 35, 37) Using the number buttons Using the cursor buttons Display the menu for inputting characters.
  • Page 66: General

    Contents Connections Playback Settings Tips Appendix General Make various other settings. 2 Edit Alarm Alarm Edit the once alarm and everyday alarm. Set the once alarm and everyday alarm. Use ui to select the alarm mode, then press ENTER. 2 Once Use ui to setting for the alarm start time, then press Time display : Set the once alarm to on.
  • Page 67: Clock

    Contents Connections Playback Settings Tips Appendix Clock Speaker Response Set the output frequency characteristics. 2 Set the current time Flat (Default) : Properties are flat. You can automatically adjust the clock of this unit using the Internet. Response 1 : Cuts low frequencies 60 Hz or under by –12 dB/oct. Response 2 : Cuts low frequencies 100 Hz or under by –12 dB/oct.
  • Page 68: Language

    English (Default) / Deutsch / Français / Italiano / Nederlands / Español / Svenska / / Polski 2 Update Update the firmware of Marantz Network Receiver. Auto Standby Check for Update : Check for firmware updates. You can also check approximately how long it will take to complete When this unit is in the stop state and there is no input signal and operation an update.
  • Page 69 • When the procedure is complete, “Registered” is displayed in this menu and popup menu. upgrades can be carried out. If the procedure has not been carried out, “Not Off : Does not display notification messages from Marantz in the popup Registered” is displayed. menu.
  • Page 70 If the error continues despite this, check the network environment. • Information regarding the “Update” function and “Add New Feature” will be announced on the Marantz web site each time related plans are defined. Front panel Rear panel...
  • Page 71: Network

    Off (Default) : Suspend network function during standby. • The default Friendly Name on first use is “Marantz M-CR510”. • Up to 63 characters can be input. • Set to “On” when using the web control function or a network compatible • For character input, see page 65.
  • Page 72: Settings

    Contents Connections Playback Settings Tips Appendix n Subnet Mask Settings When connecting an xDSL modem or connector adapter directly to this You can make detailed settings for the network. unit, input the subnet mask indicated in the documentation supplied by To change the network environment, perform “Quick Setup”.
  • Page 73 When the network you want to connect to is not detected, select Press ENTER. “Rescan”. Make the following settings. Select Wi-Fi network called “Marantz M-CR510” from your Wi-Fi device. Default Key : Select the default key. The IP address appears on the unit.
  • Page 74 Contents Connections Playback Settings Tips Appendix n Manual Sets the wireless connection manually. SSID : Input the name of the wireless network (SSID). Security : Select the encryption method according to the encryption setting of the access point you are using. Password : Input the password.
  • Page 75: Contents

    Contents Connections Playback Settings Tips Appendix Tips Contents 2 Tips ..............(76) 2 Troubleshooting ..........(77) Simple operations in the power off state .........(76) Power does not turn on / Power is turned off ........(77) Simple operations for iPod/USB ............(76) Indicator is flashing ................(77) I only want to recharge my iPod ............(76) Operations cannot be performed through the remote control unit ................(78)
  • Page 76: Tips

    Contents Connections Playback Settings Tips Appendix Tips Simple operations in the power off state • When a input source select buttons or FAVORITES CALL button is pressed, the operation is performed at the same time as the unit switches on (vpage 25, 40). • When the Network Control function is set to “On”, you can perform playback, or other operations through AirPlay, App or the web control function (vpage 49, 54, 71).
  • Page 77: Troubleshooting

    Contents Connections Playback Settings Tips Appendix Troubleshooting If a problem should arise, first check the following: 1. Are the connections correct? 2. Is the set being operated as described in the owner’s manual? 3. Are the other devices operating properly? If this unit does not operate properly, check the items listed in the table below.
  • Page 78: Display On This Unit Shows Nothing

    Contents Connections Playback Settings Tips Appendix 2 Operations cannot be performed through the remote control unit Symptom Cause/Solution Page Operations cannot be performed • Batteries are worn out. Replace with new batteries. through the remote control unit. • Operate the remote control unit within a distance of about 7 m from this unit and at an angle of within 30°.
  • Page 79: No Sound Comes Out

    Contents Connections Playback Settings Tips Appendix 2 No sound comes out Symptom Cause/Solution Page No sound comes out of speakers. • Check the connections for all devices. 18, 19 • Insert connection cables all the way in. • Check that input connectors and output connectors are not reversely connected. • Check cables for damage.
  • Page 80: Desired Sound Does Not Come Out

    Contents Connections Playback Settings Tips Appendix 2 Desired sound does not come out Symptom Cause/Solution Page Left/right volume balance is • Press the DBB/TONE button on the remote control to adjust the balance. unbalanced No sound from the sub woofer. • Check the sub woofer connections. • Switch the sub woofer power on.
  • Page 81: Ipod Cannot Be Played Back

    Contents Connections Playback Settings Tips Appendix 2 iPod cannot be played back Symptom Cause/Solution Page iPod cannot be connected. • When using iPod by connecting it to the USB port, some iPod variations are not supported. • When iPod is connected by using a USB cable other than the genuine cable, iPod may not be –...
  • Page 82: Usb Memory Devices Cannot Be Played Back

    Contents Connections Playback Settings Tips Appendix 2 USB memory devices cannot be played back Symptom Cause/Solution Page “No Connection” is displayed. • The set cannot recognize a USB memory device. Disconnect and reconnect the USB memory device. • USB memory devices of a mass storage class or those compatible with MTP are supported. –...
  • Page 83: The Internet Radio Cannot Be Played Back

    Contents Connections Playback Settings Tips Appendix 2 File names on the iPod/USB memory device are not displayed properly Symptom Cause/Solution Page The file names are not displayed • Characters that cannot be displayed are used. This is not a malfunction. On this unit, characters –...
  • Page 84: An Error Message Is Displayed By Last.fm

    Contents Connections Playback Settings Tips Appendix 2 An Error message is displayed by Last.fm Symptom Cause/Solution Page Cannot login to Last.fm. • Login authentication error. (“Subscription required” is displayed.) • If a nonsubscriber user accesses it. Or when the listening limitation exceeds it. –...
  • Page 85: Music Files On Pc Or Nas Cannot Be Played Back

    Contents Connections Playback Settings Tips Appendix 2 Music files on PC or NAS cannot be played back Symptom Cause/Solution Page Files stored on a computer cannot be • Files are stored in a non-compatible format. Record in a compatible format. played. • You are attempting to play a file that is copyright protected.
  • Page 86: Cannot Connect By Wi-Fi

    Contents Connections Playback Settings Tips Appendix 2 Cannot connect by Wi-Fi Symptom Cause/Solution Page Cannot connect to the network. • The network name and password (WEP, etc.) settings are wrong. Configure the network settings according to the setting details of this unit. • Reduce the distance between the wireless LAN access point and this unit, remove any –...
  • Page 87: Resetting Factory Settings

    Contents Connections Playback Settings Tips Appendix Resetting factory settings Pull the power cord out of the power outlet. Perform this procedure if the display is abnormal or if operations cannot Plug the power cord into a power outlet while pressing be performed.
  • Page 88: Playing Back Usb Memory Devices

    Contents Connections Playback Settings Tips Appendix Appendix Playing back USB memory devices z1 Copyright-protected files can be played on certain portable players compatible with MTP. z2 Only files that are not protected by copyright can be played on this unit. • This unit is compatible with MP3 ID3-Tag (Ver. 2) standard.
  • Page 89: Playing Back Internet Radio

    Contents Connections Playback Settings Tips Appendix Playing back Internet Radio 2 Maximum Number of Playable Files and Folder The limits on the number of folders and files that can be displayed by this unit are as follows. 2 Playable broadcast station specifications Media Sampling frequency Bit rate...
  • Page 90: Playing Back Files Stored On Pc Or Nas

    Contents Connections Playback Settings Tips Appendix Playing back files stored on PC or z1 Only files that are not protected by copyright can be played on this unit. Content downloaded from pay sites on the Internet are copyright protected. Also, files encoded in WMA format when ripped from a CD, etc. on a computer may be copyright protected, depending on the computer’s settings.
  • Page 91: Explanation Of Terms

    Contents Connections Playback Settings Tips Appendix Explanation of terms DLNA DLNA and DLNA CERTIFIED are trademarks and/or service marks of Digital Living Network Alliance. AES (Advanced Encryption Standard) Some contents may not be compatible with other DLNA CERTIFIED ® This is a next generation standard encryption method replacing the current products.
  • Page 92 Contents Connections Playback Settings Tips Appendix iTunes THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, iTunes is the name of the multimedia player provided by Apple Inc. It INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF enables management and playback of multimedia contents including MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE music and movies.
  • Page 93 Contents Connections Playback Settings Tips Appendix Protection circuit vTuner This is a function to prevent damage to devices within the power supply This is a free online content server for Internet Radio. Note that usage fees when an abnormality such as an overload, excess voltage occurs or over are included in upgrade costs.
  • Page 94 Contents Connections Playback Settings Tips Appendix Windows Media DRM WPA2 (Wi-Fi Protected Access 2) This is a copyright protection technology developed by Microsoft. This is a new version of the WPA established by the Wi-Fi Alliance, Content providers are using the digital rights management technology compatible with more secure AES encryption.
  • Page 95: Trademark Information

    Contents Connections Playback Settings Tips Appendix Trademark information “Made for iPod” and “Made for iPhone” mean that an electronic Windows Media and the Windows logo are trademarks or registered accessory has been designed to connect specifically to iPod, or iPhone, trademarks of Microsoft Corporation in the United States and/or other respectively, and has been certified by the developer to meet Apple countries.
  • Page 96: Specifications

    Contents Connections Playback Settings Tips Appendix Specifications 2 Audio section • Audio amplifier Rated output: 2-channel driving 50 W + 50 W (6 Ω/ohms, 1 kHz, THD+N 0.7 %) Dynamic power: 60 W + 60 W (6 Ω/ohms, 1 kHz, THD+N 10 %) Output terminals: Speaker 6 –...
  • Page 97: Wireless Lan

    Contents Connections Playback Settings Tips Appendix 2 Wireless LAN Network type (wireless LAN standards): Conforming to IEEE 802.11b Conforming to IEEE 802.11g (Conforming to Wi-Fi®) Transfer rate: DS-SS: 11 / 5.5 / 1 Mbps (Automatic switching) OFDM: 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6 Mbps (Automatic switching) Security: SSID (Network name) WEP key (network key) (64/128 bits)
  • Page 98 Contents Connections Playback Settings Tips Appendix 2 Clock/Alarm Clock type: Power line frequency synchronized method (Within ±60 seconds per month) Alarm: Everyday alarm / Once alarm : One system each Sleep timer : Max. 90 minutes 2 General Power supply: AC 230 V, 50/60 Hz Power consumption: 55 W...
  • Page 99: Index

    Contents Connections Playback Settings Tips Appendix Index Cable ······································································ 15 Firmware ································································ 68 Audio cable ·························································· 15 FLAC ······································································ 91 LAN cable ···························································· 15 Friendly Name ························································ 71 Accessories ······························································ 5 Optical cable ························································ 15 Front panel ······························································· 8 Add New Feature ··················································· 69 Speaker cable ················································...
  • Page 100: Playback Settings

    Contents Connections Playback Settings Tips Appendix Network Control ····················································· 71 Random playback ································· 32, 39, 44, 47 vTuner ······························································ 29, 93 Network Information ·············································· 71 Rear panel ······························································ 10 Network Names (SSID) ·········································· 92 Remote control unit ··············································· 12 Network settings···················································· 71 Inserting the batteries ···········································...
  • Page 101: License

    Contents Connections Playback Settings Tips Appendix License n Expat n FastDelegate http://www.jclark.com/xml/expat.html http://www.codeproject.com/KB/cpp/FastDelegate. aspx This section describes software license used for Expat License. Copyright (c) 1998, 1999, 2000 Thai this unit. To maintain the correct content, the Open Source Software Center Ltd THE WORK (AS DEFINED BELOW) IS PROVIDED original (English) is used.
  • Page 102 Contents Connections Playback Settings Tips Appendix g. “Standard Version” refers to such a Work if it has not e. The Articles discussing the Work published in e. You may distribute the Executable Files and Source been modified, or has been modified in accordance any form by the author may not be distributed or Code only under the terms of this License, and You with the consent of the Author, such consent being...
  • Page 103 Contents Connections Playback Settings Tips Appendix 6. Representations, Warranties and Disclaimer. THIS 9. Termination. 11. Miscellaneous WORK IS PROVIDED “AS IS”, “WHERE IS” AND a. This License and the rights granted hereunder will a. This License shall be governed by the laws of the “AS AVAILABLE”, WITHOUT ANY EXPRESS terminate automatically upon any breach by You location of the head office of the Author or if the...
  • Page 104 Contents Connections Playback Settings Tips Appendix • Redistributions in binary form must reproduce the • Redistributions of source code must retain the Redistribution and use in source and binary forms, with or without modification, are permitted provided that the above copyright notice, this list of conditions and above copyright notice, this list of conditions and the following conditions are met: the following disclaimer in the documentation and/or...
  • Page 105 Contents Connections Playback Settings Tips Appendix n Tremor THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT 2. Redistributions in binary form must reproduce the HOLDERS AND CONTRIBUTORS “AS IS” AND ANY above copyright notice, this list of conditions and http://wiki.xiph.org/index.php/Tremor EXPRESS OR IMPLIED WARRANTIES, INCLUDING, the following disclaimer in the documentation and/ BUT NOT LIMITED TO, THE IMPLIED WARRANTIES or other materials provided with the distribution.
  • Page 106 Contents Connections Playback Settings Tips Appendix n zlib n cURL n c-ares http://www.zlib.net/ http://curl.haxx.se http://c-ares.haxx.se zlib.h -- interface of the ‘zlib’ general purpose COPYRIGHT AND PERMISSION NOTICE Copyright 1998 by the Massachusetts Institute of compression library version 1.2.3, July 18th, 2005 Technology.
  • Page 107 GPL/ LGPL software that is used in the product. Marantz provides the source code based on the GPL and LPGL licenses at the actual cost upon your request to our customer service center. However, note that we make no guarantees concerning the source code.
  • Page 108 Contents Connections Playback Settings Tips Appendix 2 Dimensions Unit : mm 2 Weight : 2.7 kg Front panel Rear panel Remote Index...
  • Page 109 D&M Holdings Inc. 3520 10259 02AM...
