Rear Suspension; Front Brake - PIAGGIO 633823 Service Station Manual

Characteristics
Name
Engine arm bolt - frame arm
Swinging arm buffer nut
Engine-swinging arm bolt
Frame-swinging arm bolt
Centre stand bolt
Name
Shock absorber lower clamp
Upper shock absorber clamp
Front wheel fixing screws
Steering arm bolt nut
Tilt calliper fixing screws
Front wheel shaft
Arm coupling screws
Screws fixing arms to side headstocks
Screws fixing arms to central headstock
Screws fixing the half-arm coupling flange
Fixing screws for tilt locking disc section
Side headstock upper ring nut
Side headstock lower ring nut
Screw fixing sliding stem to shock absorber
Clamp for sliding stem locking device
Fixing nuts for constant-velocity universal joints
Potentiometer to anti-tilting device clamp
Electric motor to anti-tilting device clamp
Clamp fixing pump bolt to anti-tilting device
Pump to anti-tilting device clamp
Pressure switch to distribution frame
Sensor to tilt gripper clamp
Pipe terminals to fifth wheel check spring
Joint to anti-tilting device pump
Lower fitting for shock absorber sliding locking
clamp pipes
Upper fitting for shock absorber sliding locking
clamp pipes
Name
Upper shock absorber clamp
Shock absorber lower clamp
Shock absorber-crankcase attachment bracket
Rear wheel axle
Muffler arm clamping screws
Name
Oil bleed screw
Disc tightening screw (°)
Brake fluid pump - hose fitting
Brake fluid pipe-calliper fitting
CHAR - 6
FRAME
FRONT SUSPENSION

REAR SUSPENSION

FRONT BRAKE

MP3 250 i.e.
Torque in Nm
33 ÷ 41
64 - 72
55 ÷ 61
55 ÷ 61
31 ÷ 39
Torque in Nm
19 ÷ 26
19 ÷ 29
19 ÷ 24
20 ÷ 25
20 ÷ 25
74 ÷ 88
45 ÷ 50
45 ÷ 50
45 ÷ 50
20 ÷ 25
20 ÷ 25
20 - 24
12 ÷ 15
45 ÷ 50
6.5 ÷ 10.5
18 ÷ 20
8 ÷ 10
11 ÷ 13
11 ÷ 13
11 ÷ 13
18 ÷ 20
2.5 ÷ 2.9
7 ÷ 11
20 ÷ 25
20 ÷ 25
20 ÷ 25
Torque in Nm
33 ÷ 41
33 ÷ 41
20 ÷ 25
104 ÷ 126
27 ÷ 30
Torque in Nm
8÷12
5 - 6
16 ÷ 20
20 ÷ 25
