EM 500 G3
FEATURES
Sturdy metal housing

42 MHz bandwidth: 1680 tunable UHF

frequencies for interference-free reception
Enhanced frequency bank system with up

to 12 compatible frequencies
High-quality true diversity reception

Pilot tone squelch for eliminating RF inter-

ference when transmitter is turned off
Automatic frequency scan feature

searches for available frequencies
Enhanced AF frequency range

Wireless synchronization of transmitters

via infrared interface
User-friendly menu operation with more

control options
Illuminated graphic display

Auto-Lock function avoids accidental

changing of settings
HDX compander for crystal-clear sound

Receiver features transmitter battery

indicatation in 4 steps
Integrated Equalizer, Soundcheck mode

and guitar tuner
Wide range of accessories adapts the

system to any requirement
Optimized PLL synthesizer and micro-

processor technology
Rack-mount receiver
In every respect, this professional receiver from the new Sennheiser G3 line
provides the most features and performance the evolution series has to offer.
It begins with an especially high number of presets possible per frequency bank
(32), making setup of many wireless systems a breeze. The built-in Ethernet port
allows computer control and monitoring with a PC running Sennheiser's Wireless
System Manager software. The large graphic display provides a great deal of
additional information at a glance. One-touch sync function automatically links
up a G3 transmitter
with this receiver.
Lastly, the switching
power supply is ideal
for touring acts and
rental companies who
need a wireless that
can be powered from
worldwide sources.

TECHNICAL DATA

Modulation ...............................................................wideband FM
Frequency ranges.................................................... 516 – 558, 566 – 608, 626 – 668,
Receiving frequencies ............................................ 1,680 frequencies, tuneable in steps
Switching bandwidth .............................................42 MHz
Nominal/peak deviation .......................................± 24 kHz/± 48 kHz
Receiver principle ....................................................true diversity
Sensitivity (with HDX, peak deviation) .............< 2 μV for 52 dBA rms S/N
Adjacent channel rejection ...................................typ. ≥ 75 dB
Intermodulation attenuation ...............................typ. ≥ 70 dB
Blocking .....................................................................≥ 75 dB
Squelch ...................................................................... Off, 5 to 25 dBμV,
Pilot tone squelch ...................................................can be switched off
Antenna inputs........................................................2 BNC sockets, 50 Ohm
Compander system .................................................Sennheiser HDX
EQ presets
Preset 1: "Flat"
Preset 2: "Low Cut" ................................................−3 dB at 180 Hz
Preset 3: "Low Cut/High boost" .......................... −3 dB at 180 Hz
734 –776, 780 – 822, 823 – 865 MHz
of 25 kHz
20 frequency banks, each with
up to 32 factory-preset channels,
intermodulation-free
6 frequency banks with up to 32
user programmable channels
adjustable in steps of 2 dB
+6 dB at 10 kHz
Continued on page 2
