Ryobi P120 Operator's Manual

18 volt dual port charger
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Your battery charger has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
18 VOLT DUAL PORT CHARGER
P120
BATTERIES
SOLD SEPARATELY

Advertisement

Table of Contents
loading

Related Manuals for Ryobi P120

Summary of Contents for Ryobi P120

  • Page 1 OPERATOR’S MANUAL 18 VOLT DUAL PORT CHARGER P120 BATTERIES SOLD SEPARATELY Your battery charger has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®...

  • Page 3: Safety Rules For Charger

    SAFETY RULES FOR CHARGER  An extension cord should not be used unless absolutely necessary. Use of improper extension WARNING! cord could result in a risk of fire and electric shock. If READ AND UNDERSTAND ALL INSTRUCTIONS. extension cord must be used, make sure: Failure to follow all instructions listed below, may result in a.

  • Page 4: Features

    FEATURES PRODUCT SPECIFICATIONS Charger Voltage ..............................18 Volt DC Charger Input ............................120 V, 60 Hz, AC only Charge Rate ..................................1 hour Cord Length ..................................6 ft. EVALUATING (YELLOW / GREEN LED) DUAL PORT CHARGER FULLY CHARGED (GREEN LED) QUICK CHARGE CORD WRAP (RED LED) 3 IN.

  • Page 5: Assembly

     Yellow and Green LEDs on = Evaluating, possible You may use this tool for the following purposes: deeply discharged or defective battery pack.  Charging compatible Ryobi 18 volt battery packs  No LED on = Defective charger or battery pack.

  • Page 6: Operation

    OPERATION THE FOLLOWING BATTERY PACKS MAY BE EVALUATING USED WITH THE P120 DUAL PORT CHARGER: (YELLOW / GREEN LED) 1322401, 1322701, 1323303, 1323701, 1324101, 1400672, 130224007, 130224028, 130227002, FULLY 130255004, 130256001. CHARGED (GREEN LED) CHARGING THE BATTERY PACK Battery packs, sold separately, are shipped in a low charge condition to prevent possible problems.

  • Page 7: Maintenance

    MAINTENANCE The batteries in this tool have been designed to provide WARNING: maximum trouble-free life. However, like all batteries, they will eventually wear out. Do not disassemble battery pack When servicing, use only identical replacement parts. and attempt to replace the batteries. Handling of these Use of any other parts may create a hazard or cause batteries, especially when wearing rings and jewelry, could product damage.

  • Page 8: Parts Ordering / Service

    When ordering repair parts, always give the following information: P120 • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi Limited used under license. ® ONE WORLD TECHNOLOGIES, INC. 1428 Pearman Dairy Road, Anderson, SC 29625 Phone 1-800-525-2579 www.ryobitools.com...
