User Guide
[ENGLISH/08-12]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kunai and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Saitek Kunai

Summary of Contents for Saitek Kunai

  • Page 1 User Guide [ENGLISH/08-12]...

  • Page 2: Table Of Contents

    Table of Contents Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Connecting the Microphone .

  • Page 3: Package Contents

    Package Contents In-line Audio Controller with Breakaway Kunai Headset Removable Microphone Quick Start Guide...

  • Page 4: Connecting The Microphone

    Connecting the Microphone 1 . Line up the arrows on the microphone and the headset .
  • Page 5 Connecting the Microphone 2 . Insert the microphone into the port on the left earcup of the headset . Firmly push it into place, and then twist it clockwise to lock it in place . 3 . Reverse the above steps to remove the microphone . 4 .

  • Page 6: In-Line Controls

    In-line Controls Game Audio Volume: Use to adjust Voice Communication Volume: the volume of the game audio . Use to adjust the volume of the voices of other players . Mic Mute: Slide the mic mute switch so that others cannot hear you . The orange area behind the switch will show when the mic is muted .

  • Page 7: Connect To Ps Vita

    Connect to PS Vita Plug the 3 .5mm stereo audio connector into the 3 .5mm headset jack located on the bottom of the PS Vita .

  • Page 8: Playstation ® 3

    Connect to PlayStation 3...
  • Page 9 On the PS3 go to Settings > Accessory Settings > Audio Device Settings, and set both the input and output to “TRITTON KUNAI Headset .” You can see a visual confirmation that the microphone is functioning if the bar graph moves .

  • Page 10: Speaker Tags

    Speaker Tags 1 . The speaker tags are held in place with magnets . Remove them by pulling on the slots located at the top of the speaker plates . 2 . To replace the speaker tags, line up the tabs on the speaker tag with the holes at the bottom of the earcup, and then tilt the speaker tag forward so that the magnets hold it in place .

  • Page 11: Troubleshooting

    Troubleshooting Microphone isn’t working: • Make sure that the microphone is properly inserted into the microphone port. • Check that the 3.5mm stereo audio connector is firmly plugged into the headset jack on the PS Vita . • Make sure that the mic mute switch is not set to mute. •...

  • Page 12: Warranty

    WARRANTY 2-YEAR LIMITED WARRANTY Mad Catz warrants this product to be free from defects in materials and workmanship for the warranty period . This non-transferable, two- (2) year limited warranty is only to you, the first end-user purchaser . If a defect covered by this warranty occurs AND you provide proof of purchase, Mad Catz, at its option, will repair or replace the product at no charge .

  • Page 13: Technical Support

    TECHNICAL SUPPORT Online Support: http://support.madcatz.com North American telephone, available Monday through Friday (excluding holidays): 1-800-659-2287 (USA only) or 1-619-683-2815 (outside USA). United Kingdom telephone, available Monday through Friday (excluding bank holidays): 08450 508418. European telephone (outside UK), available Monday through Friday (excluding bank holidays): +44(0) 1633 883110.
  • Page 14 CAUTIONS • Long-term exposure to loud music or other sounds in headphones may cause hearing damage. It is best to avoid extreme volume levels when using headphones, especially for extended periods . • Use this unit only as intended. • To prevent fire or shock hazard, do not expose this unit to rain or moisture. Do not use within 30’ of any water such as swimming pools, bathtubs, or sinks .
  • Page 15 CAUTIONS Exposure to Radio Frequency Radiation: The radiated output power of the headset is well within FCC radio frequency exposure limits for this type of device when unaltered and used as described in our instructions and the controller operates within guidelines found in radio frequency safety standards, which reflect the consensus of the scientific community and therefore, the manufacturer believes the device’s internal wireless radio is safe for use by consumers .
  • Page 16 WWW .TRITTONAUDIO .COM ©2012 Mad Catz, Inc . 7480 Mission Valley Road, Suite 101, San Diego, CA 92108 U .S .A . Mad Catz, TRITTON, Kunai, the Mad Catz logo and the TRITTON logo are trademarks or registered trademarks of Mad Catz, Interactive, Inc ., its subsidiaries and affiliates . The shape and design of this product are a trade dress of Mad Catz Interactive, Inc ., its subsidiaries and affiliates .
