Hitachi CP-WX625 Specification Sheet

CP-WX625 series
My Image / Campus Notification System

Key Features

• 4,000 ANSI Lumens
• Native WXGA Resolution
• 15.8 lbs.
• 1 RGB / 1 BNC / 1 HDMI input
1 RGB out
• 16W speaker output
• Lamp door on the top
• 29 dB (Whisper Mode)
Screen Size 16:10 Throw Distance
Diagonal* Width*
30 25
60 51
80 68
100 85
120 102
150 127
200 170
300 254
Throw Ratio: 1.5 - 1.8:1 (distance : width)
*Measured in inches
For sales information, please call 800.225.1741
Printed 06.08
Closed Captioning
• Horizontal & Vertical lens shift
• Side-Mounted High Effciency Filter
• Component / Composite / S-Video
• Approx. 3,000 hrs. Lamp (whisper Mode)
• Security Bar & Transition Detector
• Network Control, Maintenance & Security
• Instant On/Off
• Picture by Picture
Min* Max*
36 44
74 90
100 120
125 151
150 181
188 227
252 303
379 455

Specifications

Model Name
Liquid Crystal Panel Structure
Number of Pixels
Resolution Video
RGB
Colors
Aspect Ratio
Lens
Throw Ratio (distance : width)
Lamp
Brightness
Expected lamp Life
Contrast Ratio
Speaker Output
Power Supply
Power Consumption
Operating Temperature
Input Signals RGB
Composite Video
Component Video
Acoustic Noise Level
H-Sync
V-Sync
Vertical Keystone
Horizontal Keystone
Approvals
RGB Input Analog RGB
RGB Output RGB
Digital Input RGB
Video Input S-Video
Composite Video
Component Video
Audio Input
Output
Ethernet
Control Terminals
Dimensions (W x D x H)
Weight
Additional Features
Supplied Accessories
Lamp
Remote Control
Filter
CP-WX625 Series
0.75" Polysilicon Active-matrix TFT x 3
1,024,000 Pixels
540 TV lines
1280 dots x 800 lines
16.7 million colors
Native 16:10 / 4:3 compatible
F1.7 - 1.9, manual zoom x 1.2
1.5 - 1.8 : 1
275W UHB
4,000 ANSI lumens
Approximately 2,000 hours (normal) 3,000 hours (whisper)
1000 : 1 (using Active Iris)
16W (4 speakers)
AC100 - 120V / AC220 - 240V 50/60 Hz Power
460W
5˚C - 35˚C (41˚F - 95˚F)
VGA, SVGA, XGA, SXGA, SXGA+, UXGA, MAC13", MAC16"
NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N
480i, 576i, 480p, 720p, 1080i
35 dB (29 dB in whisper mode)
15 kHz - 106 kHz
50 kHz - 120 kHz
+ / - 40˚
+ / - 20˚
UL60950 / C-UL, FCC Part15, Class B, EN60950
15-pin D-sub connector x 1, BNC Terminal x 1
15-pin D-sub connector x 1
HDMI X1
Mini DIN 4-pin connector x 1
RCA jack x 1
RCA jack x 3, BNC Terminals (Shared with Analog RGB)
Stereo mini jack x 2, RCA (L/R) x 2 pairs
Stereo mini jack x 1
RJ-45 port / 100 base-T
9-pin D-sub connector x 1 (RS-232 control)
USB Type-B x 1 (Remote Mouse)
16.5" x 12.6" x 5.5"
15.8 lbs.
Kensington Slot, MyMemory / MyScreen / MyButtons
Digital Gamma Correction, Whiteboard/Blackboard Mode,
Input Source Naming, Wired Remote
Remote Control, Batteries (AA), RGB cable, US Power Cord, Multiple
language operator / Safety Manual, Security Label
CPWX625LAMP (DT00873)
HL02196
MU05661
All specifications subject to change without notice
